SRC/place_and_route.c File Reference

#include <stdio.h>
#include <sys/types.h>
#include "util.h"
#include "vpr_types.h"
#include "vpr_utils.h"
#include "globals.h"
#include "place_and_route.h"
#include "mst.h"
#include "place.h"
#include "read_place.h"
#include "route_export.h"
#include "draw.h"
#include "stats.h"
#include "check_route.h"
#include "rr_graph.h"
#include "path_delay.h"
#include "net_delay.h"
#include "timing_place.h"
#include <assert.h>

Include dependency graph for place_and_route.c:

Go to the source code of this file.

Functions
static int	binary_search_place_and_route (struct s_placer_opts placer_opts, char *place_file, char *net_file, char *arch_file, char *route_file, boolean full_stats, boolean verify_binary_search, struct s_annealing_sched annealing_sched, struct s_router_opts router_opts, struct s_det_routing_arch det_routing_arch, t_segment_inf *segment_inf, t_timing_inf timing_inf, t_subblock_data *subblock_data_ptr, t_chan_width_dist chan_width_dist, t_mst_edge **mst)
static float	comp_width (t_chan *chan, float x, float separation)
void	post_place_sync (IN int num_blocks, INOUT const struct s_block block_list[], INOUT t_subblock_data *subblock_data_ptr)
void	free_subblock_data (t_subblock_data *subblock_data_ptr)
void	place_and_route (enum e_operation operation, struct s_placer_opts placer_opts, char *place_file, char *net_file, char *arch_file, char *route_file, struct s_annealing_sched annealing_sched, struct s_router_opts router_opts, struct s_det_routing_arch det_routing_arch, t_segment_inf *segment_inf, t_timing_inf timing_inf, t_subblock_data *subblock_data_ptr, t_chan_width_dist chan_width_dist)
void	init_chan (int cfactor, t_chan_width_dist chan_width_dist)

---

Function Documentation

static int binary_search_place_and_route	(	struct s_placer_opts	placer_opts,
		char *	place_file,
		char *	net_file,
		char *	arch_file,
		char *	route_file,
		boolean	full_stats,
		boolean	verify_binary_search,
		struct s_annealing_sched	annealing_sched,
		struct s_router_opts	router_opts,
		struct s_det_routing_arch	det_routing_arch,
		t_segment_inf *	segment_inf,
		t_timing_inf	timing_inf,
		t_subblock_data *	subblock_data_ptr,
		t_chan_width_dist	chan_width_dist,
		t_mst_edge **	mst
	)			[static]

Definition at line 250 of file place_and_route.c.

{

/* This routine performs a binary search to find the minimum number of      *
 * tracks per channel required to successfully route a circuit, and returns *
 * that minimum width_fac.                                                  */

    struct s_trace **best_routing;      /* Saves the best routing found so far. */
    int current, low, high, final;
    int max_pins_per_fb, i;
    boolean success, prev_success, prev2_success, Fc_clipped = FALSE;
    char msg[BUFSIZE];
    float **net_delay, **net_slack;
    struct s_linked_vptr *net_delay_chunk_list_head;
    int try_w_limit;
    t_ivec **fb_opins_used_locally, **saved_clb_opins_used_locally;

    /* [0..num_blocks-1][0..num_class-1] */
    int attempt_count;
    int udsd_multiplier;
    int warnings;

        t_graph_type graph_type;

/* Allocate the major routing structures. */

        if(router_opts.route_type == GLOBAL) {
                graph_type = GRAPH_GLOBAL;
        } else {
                graph_type = (det_routing_arch.directionality ==
                    BI_DIRECTIONAL ? GRAPH_BIDIR : GRAPH_UNIDIR);
        }

    max_pins_per_fb = 0;
    for(i = 0; i < num_types; i++)
        {
            max_pins_per_fb =
                max(max_pins_per_fb, type_descriptors[i].num_pins);
        }

    fb_opins_used_locally = alloc_route_structs(*subblock_data_ptr);
    best_routing = alloc_saved_routing(fb_opins_used_locally,
                                       &saved_clb_opins_used_locally);

    if(timing_inf.timing_analysis_enabled)
        {
            net_slack =
                alloc_and_load_timing_graph(timing_inf, *subblock_data_ptr);
            net_delay = alloc_net_delay(&net_delay_chunk_list_head);
        }
    else
        {
            net_delay = NULL;   /* Defensive coding. */
            net_slack = NULL;
        }

    /* UDSD by AY Start */
    if(det_routing_arch.directionality == BI_DIRECTIONAL)
        udsd_multiplier = 1;
    else
        udsd_multiplier = 2;
    /* UDSD by AY End */

    if(router_opts.fixed_channel_width != NO_FIXED_CHANNEL_WIDTH)
        {
            current = router_opts.fixed_channel_width + 5 * udsd_multiplier;
            low = router_opts.fixed_channel_width - 1 * udsd_multiplier;
        }
    else
        {
            current = max_pins_per_fb + max_pins_per_fb % 2;    /* Binary search part */
            low = -1;
        }

    /* Constraints must be checked to not break rr_graph generator */
    if(det_routing_arch.directionality == UNI_DIRECTIONAL)
        {
            if(current % 2 != 0)
                {
                    printf
                        ("Error: place_and_route.c: tried odd chan width (%d) for udsd architecture\n",
                         current);
                    exit(1);
                }
        }

    else
        {
            if(det_routing_arch.Fs % 3)
                {
                    printf("Fs must be three in bidirectional mode\n");
                    exit(1);
                }
        }

    high = -1;
    final = -1;
    try_w_limit = 0;

    attempt_count = 0;

    while(final == -1)
        {

            printf("low, high, current %d %d %d\n", low, high, current);
            fflush(stdout);

/* Check if the channel width is huge to avoid overflow.  Assume the *
 * circuit is unroutable with the current router options if we're    *
 * going to overflow.                                                */
            if(router_opts.fixed_channel_width != NO_FIXED_CHANNEL_WIDTH)
                {
                    if(current > router_opts.fixed_channel_width * 4)
                        {
                            printf
                                ("This circuit appears to be unroutable with the current "
                                 "router options. Last failed at %d\n", low);
                            printf("Aborting routing procedure.\n");
                            exit(1);
                        }
                }
            else
                {
                    if(current > 305)
                        {
                            printf
                                ("This circuit appears to be unroutable with the current "
                                 "router options. Last failed at %d\n", low);
                            printf("Aborting routing procedure.\n");
                            exit(1);
                        }
                }

            if((current * 3) < det_routing_arch.Fs)
                {
                    printf
                        ("width factor is now below specified Fs. Stop search.\n");
                    final = high;
                    break;
                }

            if(placer_opts.place_freq == PLACE_ALWAYS)
                {
                    placer_opts.place_chan_width = current;
                    try_place(placer_opts, annealing_sched, chan_width_dist,
                              router_opts, det_routing_arch, segment_inf,
                              timing_inf, subblock_data_ptr, &mst);
                }
            success =
                try_route(current, router_opts, det_routing_arch, segment_inf,
                          timing_inf, net_slack, net_delay, chan_width_dist,
                          fb_opins_used_locally, mst, &Fc_clipped);
            attempt_count++;
            fflush(stdout);
#if 1
            if(success && (Fc_clipped == FALSE))
                {
#else
            if(success
               && (Fc_clipped == FALSE
                   || det_routing_arch.Fc_type == FRACTIONAL))
                {
#endif
                    high = current;

                    /* If Fc_output is too high, set to full connectivity but warn the user */
                    if(Fc_clipped)
                        {
                            printf
                                ("Warning: Fc_output was too high and was clipped to full (maximum) connectivity.\n");
                        }

/* If we're re-placing constantly, save placement in case it is best. */
#if 0
                    if(placer_opts.place_freq == PLACE_ALWAYS)
                        {
                            print_place(place_file, net_file, arch_file);
                        }
#endif

                    /* Save routing in case it is best. */
                    save_routing(best_routing, fb_opins_used_locally,
                                 saved_clb_opins_used_locally);

                    if((high - low) <= 1 * udsd_multiplier)
                        final = high;

                    if(low != -1)
                        {
                            current = (high + low) / 2;
                        }
                    else
                        {
                            current = high / 2; /* haven't found lower bound yet */
                        }
                }
            else
                {               /* last route not successful */
                    if(success && Fc_clipped)
                        {
                            printf
                                ("Routing rejected, Fc_output was too high.\n");
                            success = FALSE;
                        }
                    low = current;
                    if(high != -1)
                        {

                            if((high - low) <= 1 * udsd_multiplier)
                                final = high;

                            current = (high + low) / 2;
                        }
                    else
                        {
                            if(router_opts.fixed_channel_width !=
                               NO_FIXED_CHANNEL_WIDTH)
                                {
                                    /* FOR Wneed = f(Fs) search */
                                    if(low <
                                       router_opts.fixed_channel_width + 30)
                                        {
                                            current =
                                                low + 5 * udsd_multiplier;
                                        }
                                    else
                                        {
                                            printf
                                                ("Aborting: Wneed = f(Fs) search found exceedingly large Wneed (at least %d)\n",
                                                 low);
                                            exit(1);
                                        }
                                }
                            else
                                {
                                    current = low * 2;  /* Haven't found upper bound yet */
                                }
                        }
                }
            current = current + current % udsd_multiplier;
        }

/* The binary search above occassionally does not find the minimum    *
 * routeable channel width.  Sometimes a circuit that will not route  *
 * in 19 channels will route in 18, due to router flukiness.  If      *
 * verify_binary_search is set, the code below will ensure that FPGAs *
 * with channel widths of final-2 and final-3 wil not route           *
 * successfully.  If one does route successfully, the router keeps    *
 * trying smaller channel widths until two in a row (e.g. 8 and 9)    *
 * fail.                                                              */

    if(verify_binary_search)
        {

            printf
                ("\nVerifying that binary search found min. channel width ...\n");

            prev_success = TRUE;        /* Actually final - 1 failed, but this makes router */
            /* try final-2 and final-3 even if both fail: safer */
            prev2_success = TRUE;

            current = final - 2;

            while(prev2_success || prev_success)
                {
                    if((router_opts.fixed_channel_width !=
                        NO_FIXED_CHANNEL_WIDTH)
                       && (current < router_opts.fixed_channel_width))
                        {
                            break;
                        }
                    fflush(stdout);
                    if(current < 1)
                        break;
                    if(placer_opts.place_freq == PLACE_ALWAYS)
                        {
                            placer_opts.place_chan_width = current;
                            try_place(placer_opts, annealing_sched,
                                      chan_width_dist, router_opts,
                                      det_routing_arch, segment_inf,
                                      timing_inf, subblock_data_ptr, &mst);
                        }

                    success =
                        try_route(current, router_opts, det_routing_arch,
                                  segment_inf, timing_inf, net_slack,
                                  net_delay, chan_width_dist,
                                  fb_opins_used_locally, mst, &Fc_clipped);

                    if(success && Fc_clipped == FALSE)
                        {
                            final = current;
                            save_routing(best_routing, fb_opins_used_locally,
                                         saved_clb_opins_used_locally);

                            if(placer_opts.place_freq == PLACE_ALWAYS)
                                {
                                    print_place(place_file, net_file,
                                                arch_file);
                                }
                        }


                    prev2_success = prev_success;
                    prev_success = success;
                    current--;
                        if(det_routing_arch.directionality == UNI_DIRECTIONAL) {
                                current--; /* width must be even */
                        }
                }
        }



    /* End binary search verification. */
    /* Restore the best placement (if necessary), the best routing, and  *
     * * the best channel widths for final drawing and statistics output.  */
    init_chan(final, chan_width_dist);
#if 0
    if(placer_opts.place_freq == PLACE_ALWAYS)
        {
            printf("Reading best placement back in.\n");
            placer_opts.place_chan_width = final;
            read_place(place_file, net_file, arch_file, placer_opts,
                       router_opts, chan_width_dist, det_routing_arch,
                       segment_inf, timing_inf, subblock_data_ptr, &mst);
        }
#endif
    free_rr_graph();

    build_rr_graph(graph_type,
                   num_types, type_descriptors, nx, ny, grid,
                   chan_width_x[0], NULL,
                   det_routing_arch.switch_block_type, det_routing_arch.Fs,
                   det_routing_arch.num_segment, det_routing_arch.num_switch, segment_inf,
                   det_routing_arch.global_route_switch,
                   det_routing_arch.delayless_switch, timing_inf,
                   det_routing_arch.wire_to_ipin_switch,
                   router_opts.base_cost_type, &warnings);

    restore_routing(best_routing, fb_opins_used_locally,
                    saved_clb_opins_used_locally);
    check_route(router_opts.route_type, det_routing_arch.num_switch,
                fb_opins_used_locally);
    get_serial_num();
    if(Fc_clipped)
        {
            printf
                ("Warning: Best routing Fc_output too high, clipped to full (maximum) connectivity.\n");
        }
    printf("Best routing used a channel width factor of %d.\n\n", final);

    routing_stats(full_stats, router_opts.route_type,
                  det_routing_arch.num_switch, segment_inf,
                  det_routing_arch.num_segment,
                  det_routing_arch.R_minW_nmos,
                  det_routing_arch.R_minW_pmos,
                  det_routing_arch.directionality,
                  timing_inf.timing_analysis_enabled, net_slack, net_delay,
                  *subblock_data_ptr);

    print_route(route_file);

#ifdef CREATE_ECHO_FILES
    /* print_sink_delays("routing_sink_delays.echo"); */
#endif /* CREATE_ECHO_FILES */

    init_draw_coords(max_pins_per_fb);
    sprintf(msg, "Routing succeeded with a channel width factor of %d.",
            final);
    update_screen(MAJOR, msg, ROUTING, timing_inf.timing_analysis_enabled);

    free_subblock_data(subblock_data_ptr);

    if(timing_inf.timing_analysis_enabled)
        {
            free_timing_graph(net_slack);
            free_net_delay(net_delay, &net_delay_chunk_list_head);
        }

    free_route_structs(fb_opins_used_locally);
    free_saved_routing(best_routing, saved_clb_opins_used_locally);
    fflush(stdout);

    return (final);
}

Here is the call graph for this function:

Here is the caller graph for this function:

static float comp_width	(	t_chan *	chan,
		float	x,
		float	separation
	)			[static]

Definition at line 735 of file place_and_route.c.

{

/* Return the relative channel density.  *chan points to a channel   *
 * functional description data structure, and x is the distance      *
 * (between 0 and 1) we are across the chip.  separation is the      *
 * distance between two channels, in the 0 to 1 coordinate system.   */

    float val;

    switch (chan->type)
        {

        case UNIFORM:
            val = chan->peak;
            break;

        case GAUSSIAN:
            val = (x - chan->xpeak) * (x - chan->xpeak) / (2 * chan->width *
                                                           chan->width);
            val = chan->peak * exp(-val);
            val += chan->dc;
            break;

        case PULSE:
            val = (float)fabs((double)(x - chan->xpeak));
            if(val > chan->width / 2.)
                {
                    val = 0;
                }
            else
                {
                    val = chan->peak;
                }
            val += chan->dc;
            break;

        case DELTA:
            val = x - chan->xpeak;
            if(val > -separation / 2. && val <= separation / 2.)
                val = chan->peak;
            else
                val = 0.;
            val += chan->dc;
            break;

        default:
            printf("Error in comp_width:  Unknown channel type %d.\n",
                   chan->type);
            exit(1);
            break;
        }

    return (val);
}

Here is the caller graph for this function:

void free_subblock_data

(

t_subblock_data *

subblock_data_ptr

)

Definition at line 879 of file place_and_route.c.

{
        int i, j;

        /* Frees all the subblock data structures.                                 */
        for(i = 0; i < num_blocks; i++) {
                if(subblock_data_ptr->subblock_inf[i] != NULL) {
                        for(j = 0; j < subblock_data_ptr->num_subblocks_per_block[i]; j++) {
                                free(subblock_data_ptr->subblock_inf[i][j].name);
                                free(subblock_data_ptr->subblock_inf[i][j].outputs);
                                free(subblock_data_ptr->subblock_inf[i][j].inputs);
                        }
                        free(subblock_data_ptr->subblock_inf[i]);

                }
        }
    free(subblock_data_ptr->subblock_inf);
    free(subblock_data_ptr->num_subblocks_per_block);

        /* Mark as freed. */
    subblock_data_ptr->num_subblocks_per_block = NULL;
    subblock_data_ptr->subblock_inf = NULL;
}

Here is the caller graph for this function:

void init_chan	(	int	cfactor,
		t_chan_width_dist	chan_width_dist
	)

Definition at line 653 of file place_and_route.c.

{

/* Assigns widths to channels (in tracks).  Minimum one track          *
 * per channel.  io channels are io_rat * maximum in interior          *
 * tracks wide.  The channel distributions read from the architecture  *
 * file are scaled by cfactor.                                         */

    float x, separation, chan_width_io;
    int nio, i;
    t_chan chan_x_dist, chan_y_dist;

    chan_width_io = chan_width_dist.chan_width_io;
    chan_x_dist = chan_width_dist.chan_x_dist;
    chan_y_dist = chan_width_dist.chan_y_dist;

/* io channel widths */

    nio = (int)floor(cfactor * chan_width_io + 0.5);
    if(nio == 0)
        nio = 1;                /* No zero width channels */

    chan_width_x[0] = chan_width_x[ny] = nio;
    chan_width_y[0] = chan_width_y[nx] = nio;

    if(ny > 1)
        {
            separation = 1. / (ny - 2.);        /* Norm. distance between two channels. */
            x = 0.;             /* This avoids div by zero if ny = 2. */
            chan_width_x[1] = (int)floor(cfactor * comp_width(&chan_x_dist, x,
                                                              separation) +
                                         0.5);

            /* No zero width channels */
            chan_width_x[1] = max(chan_width_x[1], 1);

            for(i = 1; i < ny - 1; i++)
                {
                    x = (float)i / ((float)(ny - 2.));
                    chan_width_x[i + 1] =
                        (int)floor(cfactor *
                                   comp_width(&chan_x_dist, x,
                                              separation) + 0.5);
                    chan_width_x[i + 1] = max(chan_width_x[i + 1], 1);
                }
        }

    if(nx > 1)
        {
            separation = 1. / (nx - 2.);        /* Norm. distance between two channels. */
            x = 0.;             /* Avoids div by zero if nx = 2. */
            chan_width_y[1] = (int)floor(cfactor * comp_width(&chan_y_dist, x,
                                                              separation) +
                                         0.5);

            chan_width_y[1] = max(chan_width_y[1], 1);

            for(i = 1; i < nx - 1; i++)
                {
                    x = (float)i / ((float)(nx - 2.));
                    chan_width_y[i + 1] =
                        (int)floor(cfactor *
                                   comp_width(&chan_y_dist, x,
                                              separation) + 0.5);
                    chan_width_y[i + 1] = max(chan_width_y[i + 1], 1);
                }
        }
#ifdef VERBOSE
    printf("\nchan_width_x:\n");
    for(i = 0; i <= ny; i++)
        printf("%d  ", chan_width_x[i]);
    printf("\n\nchan_width_y:\n");
    for(i = 0; i <= nx; i++)
        printf("%d  ", chan_width_y[i]);
    printf("\n\n");
#endif

}

Here is the call graph for this function:

Here is the caller graph for this function:

void place_and_route	(	enum e_operation	operation,
		struct s_placer_opts	placer_opts,
		char *	place_file,
		char *	net_file,
		char *	arch_file,
		char *	route_file,
		struct s_annealing_sched	annealing_sched,
		struct s_router_opts	router_opts,
		struct s_det_routing_arch	det_routing_arch,
		t_segment_inf *	segment_inf,
		t_timing_inf	timing_inf,
		t_subblock_data *	subblock_data_ptr,
		t_chan_width_dist	chan_width_dist
	)

Definition at line 56 of file place_and_route.c.

{

/* This routine controls the overall placement and routing of a circuit. */

    char msg[BUFSIZE];
    int width_fac, inet, i;
    boolean success, Fc_clipped;
    float **net_delay, **net_slack;
    struct s_linked_vptr *net_delay_chunk_list_head;
    t_ivec **fb_opins_used_locally;     /* [0..num_blocks-1][0..num_class-1] */
    t_mst_edge **mst = NULL;    /* Make sure mst is never undefined */
    int max_pins_per_fb;

        Fc_clipped = FALSE;

    max_pins_per_fb = 0;
    for(i = 0; i < num_types; i++)
        {
            if(type_descriptors[i].num_pins > max_pins_per_fb)
                {
                    max_pins_per_fb = type_descriptors[i].num_pins;
                }
        }

    if(placer_opts.place_freq == PLACE_NEVER)
        {
            /* Read the placement from a file */
            read_place(place_file, net_file, arch_file, nx, ny, num_blocks,
                       block);
            sync_grid_to_blocks(num_blocks, block, nx, ny, grid);
        }
    else
        {
            assert((PLACE_ONCE == placer_opts.place_freq) ||
                   (PLACE_ALWAYS == placer_opts.place_freq));

            try_place(placer_opts, annealing_sched, chan_width_dist,
                      router_opts, det_routing_arch, segment_inf,
                      timing_inf, subblock_data_ptr, &mst);
            print_place(place_file, net_file, arch_file);
        }
    post_place_sync(num_blocks, block, subblock_data_ptr);


    fflush(stdout);
    if(operation == PLACE_ONLY)
        return;

    width_fac = router_opts.fixed_channel_width;

    /* If channel width not fixed, use binary search to find min W */
    if(NO_FIXED_CHANNEL_WIDTH == width_fac)
        {
            binary_search_place_and_route(placer_opts, place_file,
                                          net_file, arch_file, route_file,
                                          router_opts.full_stats, router_opts.verify_binary_search,
                                          annealing_sched, router_opts,
                                          det_routing_arch, segment_inf,
                                          timing_inf, subblock_data_ptr,
                                          chan_width_dist, mst);
        }
    else
        {
            if(det_routing_arch.directionality == UNI_DIRECTIONAL)
                {
                    if(width_fac % 2 != 0)
                        {
                            printf
                                ("Error: place_and_route.c: given odd chan width (%d) for udsd architecture\n",
                                 width_fac);
                            exit(1);
                        }
                }
            /* Other constraints can be left to rr_graph to check since this is one pass routing */


            /* Allocate the major routing structures. */

            fb_opins_used_locally = alloc_route_structs(*subblock_data_ptr);

            if(timing_inf.timing_analysis_enabled)
                {
                    net_slack =
                        alloc_and_load_timing_graph(timing_inf,
                                                    *subblock_data_ptr);
                    net_delay = alloc_net_delay(&net_delay_chunk_list_head);
                }
            else
                {
                    net_delay = NULL;   /* Defensive coding. */
                    net_slack = NULL;
                }

            success =
                try_route(width_fac, router_opts, det_routing_arch,
                          segment_inf, timing_inf, net_slack, net_delay,
                          chan_width_dist, fb_opins_used_locally, mst,
                          &Fc_clipped);

            if(Fc_clipped)
                {
                    printf
                        ("Warning: Fc_output was too high and was clipped to full (maximum) connectivity.\n");
                }

            if(success == FALSE)
                {
                    printf
                        ("Circuit is unrouteable with a channel width factor of %d\n\n",
                         width_fac);
                    sprintf(msg,
                            "Routing failed with a channel width factor of %d.  ILLEGAL routing shown.",
                            width_fac);
                }

            else
                {
                    check_route(router_opts.route_type,
                                det_routing_arch.num_switch,
                                fb_opins_used_locally);
                    get_serial_num();

                    printf
                        ("Circuit successfully routed with a channel width factor of %d.\n\n",
                         width_fac);

                        routing_stats(router_opts.full_stats, router_opts.route_type,
                                  det_routing_arch.num_switch, segment_inf,
                                  det_routing_arch.num_segment,
                                  det_routing_arch.R_minW_nmos,
                                  det_routing_arch.R_minW_pmos,
                                  det_routing_arch.directionality,
                                  timing_inf.timing_analysis_enabled,
                                  net_slack, net_delay, *subblock_data_ptr);

                    print_route(route_file);

#ifdef CREATE_ECHO_FILES
                    /*print_sink_delays("routing_sink_delays.echo"); */
#endif /* CREATE_ECHO_FILES */

                    sprintf(msg,
                            "Routing succeeded with a channel width factor of %d.\n\n",
                            width_fac);
                }
            free_subblock_data(subblock_data_ptr);

            init_draw_coords(max_pins_per_fb);
            update_screen(MAJOR, msg, ROUTING,
                          timing_inf.timing_analysis_enabled);

            if(timing_inf.timing_analysis_enabled)
                {
                    assert(net_slack);
                    free_timing_graph(net_slack);

                    assert(net_delay);
                    free_net_delay(net_delay, &net_delay_chunk_list_head);
                }

            free_route_structs(fb_opins_used_locally);
            fflush(stdout);
        }

    /*WMF: cleaning up memory usage */
    if(mst)
        {
            for(inet = 0; inet < num_nets; inet++)
                {
                    assert(mst[inet]);
                    free(mst[inet]);
                }
            free(mst);
            mst = NULL;
        }

}

Here is the call graph for this function:

Here is the caller graph for this function:

void post_place_sync	(	IN int	num_blocks,
		INOUT const struct s_block	block_list[],
		INOUT t_subblock_data *	subblock_data_ptr
	)

Definition at line 796 of file place_and_route.c.

{
    int iblk, j, k, inet;
    t_type_ptr type;
    int max_num_block_pins;
    t_subblock **subblock_inf;

    subblock_inf = subblock_data_ptr->subblock_inf;


    /* Go through each block */
    for(iblk = 0; iblk < num_blocks; ++iblk)
        {
            type = block[iblk].type;
            assert(type->num_pins % type->capacity == 0);
            max_num_block_pins = type->num_pins / type->capacity;
            /* Logical location and physical location is offset by z * max_num_block_pins */
            /* Sync blocks and nets */
            for(j = 0; j < max_num_block_pins; j++)
                {
                    inet = block[iblk].nets[j];
                    if(inet != OPEN && block[iblk].z > 0)
                        {
                            assert(block[iblk].
                                   nets[j +
                                        block[iblk].z * max_num_block_pins] ==
                                   OPEN);
                            block[iblk].nets[j +
                                             block[iblk].z *
                                             max_num_block_pins] =
                                block[iblk].nets[j];
                            block[iblk].nets[j] = OPEN;
                            for(k = 0; k < type->num_pins; k++)
                                {
                                    if(net[inet].node_block[k] == iblk)
                                        {
                                            assert(net[inet].
                                                   node_block_pin[k] == j);
                                            net[inet].node_block_pin[k] =
                                                j +
                                                block[iblk].z *
                                                max_num_block_pins;
                                            break;
                                        }
                                }
                        }
                }

            /* Shift subblock pins to point to synced block pins */
            for(j = 0; j < subblock_data_ptr->num_subblocks_per_block[iblk];
                j++)
                {
                    for(k = 0; k < type->max_subblock_inputs; k++)
                        {
                            if(subblock_inf[iblk][j].inputs[k] != OPEN)
                                {
                                    subblock_inf[iblk][j].inputs[k] =
                                        subblock_inf[iblk][j].inputs[k] +
                                        block[iblk].z * max_num_block_pins;
                                }
                        }
                    for(k = 0; k < type->max_subblock_outputs; k++)
                        {
                            if(subblock_inf[iblk][j].outputs[k] != OPEN)
                                {
                                    subblock_inf[iblk][j].outputs[k] =
                                        subblock_inf[iblk][j].outputs[k] +
                                        block[iblk].z * max_num_block_pins;
                                }
                        }
                    if(subblock_inf[iblk][j].clock != OPEN)
                        {
                            subblock_inf[iblk][j].clock =
                                subblock_inf[iblk][j].clock +
                                block[iblk].z * max_num_block_pins;
                        }
                }
        }
}

Here is the caller graph for this function:
