SRC/vpr_utils.c File Reference

#include <assert.h>
#include "util.h"
#include "vpr_types.h"
#include "globals.h"
#include "vpr_utils.h"

Include dependency graph for vpr_utils.c:

Functions
void	sync_grid_to_blocks (IN int num_blocks, IN const struct s_block block_list[], IN int nx, IN int ny, INOUT struct s_grid_tile **grid)
void	sync_nets_to_blocks (IN int num_blocks, IN const struct s_block block_list[], IN int num_nets, INOUT struct s_net net_list[])
boolean	is_opin (int ipin, t_type_ptr type)
void	get_class_range_for_block (IN int iblk, OUT int class_low, OUT int class_high)
void	load_one_fb_fanout_count (t_subblock subblock_inf, int num_subblocks, int num_uses_of_fb_ipin, int **num_uses_of_sblk_opin, int iblk)

Function Documentation

void get_class_range_for_block	(	IN int	iblk,
		OUT int *	class_low,
		OUT int *	class_high
	)

Definition at line 200 of file vpr_utils.c.

00203 {
00204 /* Assumes that the placement has been done so each block has a set of pins allocated to it */
00205     t_type_ptr type;
00206
00207     type = block[iblk].type;
00208     assert(type->num_class % type->capacity == 0);
00209     *class_low = block[iblk].z * (type->num_class / type->capacity);
00210     *class_high =
00211         (block[iblk].z + 1) * (type->num_class / type->capacity) - 1;
00212 }

Here is the caller graph for this function:

boolean is_opin	(	int	ipin,
		t_type_ptr	type
	)

Definition at line 183 of file vpr_utils.c.

00185 {
00186
00187 /* Returns TRUE if this clb pin is an output, FALSE otherwise. */
00188
00189     int iclass;
00190
00191     iclass = type->pin_class[ipin];
00192
00193     if(type->class_inf[iclass].type == DRIVER)
00194         return (TRUE);
00195     else
00196         return (FALSE);
00197 }

Here is the caller graph for this function:

void load_one_fb_fanout_count	(	t_subblock *	subblock_inf,
		int	num_subblocks,
		int *	num_uses_of_fb_ipin,
		int **	num_uses_of_sblk_opin,
		int	iblk
	)

Definition at line 216 of file vpr_utils.c.

00222 00223 00224 00225 00226 00227 00228 00229 00230         { 00231 00232         } 00233 00234 00235 00236         { 00237 00238 00239 00240 00241         } 00242 00243 00244         { 00245 00246 00247 00248 00249 00250 00251 00252 00253 00254 00255 00256 00257 00258 00259 00260 00261 00262 00263 00264 00265 00266 00267 00268 00269 00270 00271 00272 00273 00274 00275 00276 00277 00278 00279 00280 00281 00282 00283 00284 00285 00286 00287 00288 00289 00290 00291 00292 00293 00294 00295 00296 00297 00298 00299 00300 00301 00302 00303 00304 00305 00306 00307 00308 00309 00310 }

class="fragment">00221 { /* Loads the fanout counts for one block (iblk). */ t_type_ptr type = block[iblk].type; int isub, ipin, conn_pin, opin; int internal_sub, internal_pin; /* Reset ipin counts */ for(ipin = 0; ipin < type->num_pins; ipin++) num_uses_of_fb_ipin[ipin] = 0; /* First pass, reset fanout counts */ for(isub = 0; isub < num_subblocks; isub++) for(opin = 0; opin < type->max_subblock_outputs; opin++) { num_uses_of_sblk_opin[isub][opin] = 0; } for(isub = 0; isub < num_subblocks; isub++) /* Is the subblock output connected to a FB opin that actually goes * * somewhere? Necessary to check that the FB opin connects to * * something because some logic blocks result in netlists where * * subblock outputs being automatically hooked to a FB opin under * * all conditions. */ for(opin = 0; opin < type->max_subblock_outputs; opin++) { conn_pin = subblock_inf[isub].outputs[opin]; if(conn_pin != OPEN) { if(block[iblk].nets[conn_pin] != OPEN) { /* FB output is used */ num_uses_of_sblk_opin[isub][opin]++; } } } for(ipin = 0; ipin < type->max_subblock_inputs; ipin++) { conn_pin = subblock_inf[isub].inputs[ipin]; if(conn_pin != OPEN) { if(conn_pin < type->num_pins) { /* Driven by FB ipin */ num_uses_of_fb_ipin[conn_pin]++; } else { /* Driven by sblk output in same fb */ internal_sub = (conn_pin - type->num_pins) / type->max_subblock_outputs; internal_pin = (conn_pin - type->num_pins) % type->max_subblock_outputs; num_uses_of_sblk_opin[internal_sub] [internal_pin]++; } } } /* End for each sblk ipin */ conn_pin = subblock_inf[isub].clock; /* Now do clock pin */ if(conn_pin != OPEN) { if(conn_pin < type->num_pins) { /* Driven by FB ipin */ num_uses_of_fb_ipin[conn_pin]++; } else { /* Driven by sblk output in same clb */ internal_sub = (conn_pin - type->num_pins) / type->max_subblock_outputs; internal_pin = (conn_pin - type->num_pins) % type->max_subblock_outputs; num_uses_of_sblk_opin[internal_sub] [internal_pin]++; } } } /* End for each subblock */

Here is the caller graph for this function:

void sync_grid_to_blocks	(	IN int	num_blocks,
		IN const struct s_block	block_list[],
		IN int	nx,
		IN int	ny,
		INOUT struct s_grid_tile **	grid
	)

Definition at line 15 of file vpr_utils.c.

00020 {
00021     int i, j, k;
00022
00023     /* Reset usage and allocate blocks list if needed */
00024     for(j = 0; j <= (ny + 1); ++j)
00025         {
00026             for(i = 0; i <= (nx + 1); ++i)
00027                 {
00028                     grid[i][j].usage = 0;
00029                     if(grid[i][j].type)
00030                         {
00031                             /* If already allocated, leave it since size doesn't change */
00032                             if(NULL == grid[i][j].blocks)
00033                                 {
00034                                     grid[i][j].blocks =
00035                                         (int *)my_malloc(sizeof(int) *
00036                                                          grid[i][j].type->
00037                                                          capacity);
00038
00039                                     /* Set them as unconnected */
00040                                     for(k = 0; k < grid[i][j].type->capacity;
00041                                         ++k)
00042                                         {
00043                                             grid[i][j].blocks[k] = OPEN;
00044                                         }
00045                                 }
00046                         }
00047                 }
00048         }
00049
00050     /* Go through each block */
00051     for(i = 0; i < num_blocks; ++i)
00052         {
00053             /* Check range of block coords */
00054             if(block[i].x < 0 || block[i].x > (nx + 1) ||
00055                block[i].y < 0
00056                || (block[i].y + block[i].type->height - 1) > (ny + 1)
00057                || block[i].z < 0 || block[i].z > (block[i].type->capacity))
00058                 {
00059                     printf(ERRTAG
00060                            "Block %d is at invalid location (%d, %d, %d)\n",
00061                            i, block[i].x, block[i].y, block[i].z);
00062                     exit(1);
00063                 }
00064
00065             /* Check types match */
00066             if(block[i].type != grid[block[i].x][block[i].y].type)
00067                 {
00068                     printf(ERRTAG "A block is in a grid location "
00069                            "(%d x %d) with a conflicting type.\n", block[i].x,
00070                            block[i].y);
00071                     exit(1);
00072                 }
00073
00074             /* Check already in use */
00075             if(OPEN != grid[block[i].x][block[i].y].blocks[block[i].z])
00076                 {
00077                     printf(ERRTAG
00078                            "Location (%d, %d, %d) is used more than once\n",
00079                            block[i].x, block[i].y, block[i].z);
00080                     exit(1);
00081                 }
00082
00083             if(grid[block[i].x][block[i].y].offset != 0)
00084                 {
00085                     printf(ERRTAG
00086                            "Large block not aligned in placment for block %d at (%d, %d, %d)",
00087                            i, block[i].x, block[i].y, block[i].z);
00088                     exit(1);
00089                 }
00090
00091             /* Set the block */
00092             for(j = 0; j < block[i].type->height; j++)
00093                 {
00094                     grid[block[i].x][block[i].y + j].blocks[block[i].z] = i;
00095                     grid[block[i].x][block[i].y + j].usage++;
00096                     assert(grid[block[i].x][block[i].y + j].offset == j);
00097                 }
00098         }
00099 }

Here is the call graph for this function:

Here is the caller graph for this function:

void sync_nets_to_blocks	(	IN int	num_blocks,
		IN const struct s_block	block_list[],
		IN int	num_nets,
		INOUT struct s_net	net_list[]
	)

Definition at line 103 of file vpr_utils.c.

00107 {
00108     int i, j, k, l;
00109     t_type_ptr cur_type;
00110
00111     /* Count the number of sinks for each net */
00112     for(i = 0; i < num_nets; ++i)
00113         {
00114             for(j = 0; j < num_blocks; ++j)
00115                 {
00116                     cur_type = block_list[j].type;
00117                     for(k = 0; k < cur_type->num_pins; ++k)
00118                         {
00119                             if(block_list[j].nets[k] == i)
00120                                 {
00121                                     if(RECEIVER ==
00122                                        cur_type->class_inf[cur_type->
00123                                                            pin_class[k]].type)
00124                                         {
00125                                             ++net_list[i].num_sinks;
00126                                         }
00127                                 }
00128                         }
00129                 }
00130         }
00131
00132     /* Alloc and load block lists of nets */
00133     for(i = 0; i < num_nets; ++i)
00134         {
00135             /* The list should be num_sinks + 1 driver. Re-alloc if already allocated. */
00136             if(net_list[i].node_block)
00137                 {
00138                     free(net_list[i].node_block);
00139                 }
00140             net_list[i].node_block =
00141                 (int *)my_malloc(sizeof(int) * (net_list[i].num_sinks + 1));
00142             if(net_list[i].node_block_pin)
00143                 {
00144                     free(net_list[i].node_block_pin);
00145                 }
00146             net_list[i].node_block_pin =
00147                 (int *)my_malloc(sizeof(int) * (net_list[i].num_sinks + 1));
00148
00149             l = 1;              /* First sink goes at position 1, since 0 is for driver */
00150
00151             for(j = 0; j < num_blocks; ++j)
00152                 {
00153                     cur_type = block_list[j].type;
00154                     for(k = 0; k < cur_type->num_pins; ++k)
00155                         {
00156                             if(block_list[j].nets[k] == i)
00157                                 {
00158                                     if(RECEIVER ==
00159                                        cur_type->class_inf[cur_type->
00160                                                            pin_class[k]].type)
00161                                         {
00162                                             net_list[i].node_block[l] = j;
00163                                             net_list[i].node_block_pin[l] = k;
00164                                             ++l;
00165                                         }
00166                                     else
00167                                         {
00168                                             assert(DRIVER ==
00169                                                    cur_type->
00170                                                    class_inf[cur_type->
00171                                                              pin_class[k]].
00172                                                    type);
00173                                             net_list[i].node_block[0] = j;
00174                                             net_list[i].node_block_pin[0] = k;
00175                                         }
00176                                 }
00177                         }
00178                 }
00179         }
00180 }

Here is the call graph for this function:

Here is the caller graph for this function:
