SRC/route_timing.c File Reference

#include <stdio.h>
#include <math.h>
#include "util.h"
#include "vpr_types.h"
#include "globals.h"
#include "mst.h"
#include "route_export.h"
#include "route_common.h"
#include "route_tree_timing.h"
#include "route_timing.h"
#include "heapsort.h"
#include "path_delay.h"
#include "net_delay.h"

Include dependency graph for route_timing.c:

Go to the source code of this file.

Defines
#define	ROUND_UP(x)   (ceil (x - 0.001))
#define	ERROR_TOL   0.0001
Functions
static int	get_max_pins_per_net (void)
static void	add_route_tree_to_heap (t_rt_node *rt_node, int target_node, float target_criticality, float astar_fac)
static void	timing_driven_expand_neighbours (struct s_heap *current, int inet, float bend_cost, float criticality_fac, int target_node, float astar_fac)
static float	get_timing_driven_expected_cost (int inode, int target_node, float criticality_fac, float R_upstream)
static int	get_expected_segs_to_target (int inode, int target_node, int *num_segs_ortho_dir_ptr)
static void	update_rr_base_costs (int inet, float largest_criticality)
static void	timing_driven_check_net_delays (float **net_delay)
boolean	try_timing_driven_route (struct s_router_opts router_opts, float **net_slack, float **net_delay, t_ivec **fb_opins_used_locally)
void	alloc_timing_driven_route_structs (float **pin_criticality_ptr, int **sink_order_ptr, t_rt_node ***rt_node_of_sink_ptr)
void	free_timing_driven_route_structs (float *pin_criticality, int *sink_order, t_rt_node **rt_node_of_sink)
boolean	timing_driven_route_net (int inet, float pres_fac, float max_criticality, float criticality_exp, float astar_fac, float bend_cost, float *net_slack, float *pin_criticality, int *sink_order, t_rt_node **rt_node_of_sink, float T_crit, float *net_delay)

---

Define Documentation

#define ERROR_TOL   0.0001

Definition at line 766 of file route_timing.c.

#define ROUND_UP

(

x

)

(ceil (x - 0.001))

Definition at line 612 of file route_timing.c.

---

Function Documentation

static void add_route_tree_to_heap	(	t_rt_node *	rt_node,
		int	target_node,
		float	target_criticality,
		float	astar_fac
	)			[static]

Definition at line 408 of file route_timing.c.

{

/* Puts the entire partial routing below and including rt_node onto the heap *
 * (except for those parts marked as not to be expanded) by calling itself   *
 * recursively.                                                              */

    int inode;
    t_rt_node *child_node;
    t_linked_rt_edge *linked_rt_edge;
    float tot_cost, backward_path_cost, R_upstream;

/* Pre-order depth-first traversal */

    if(rt_node->re_expand)
        {
            inode = rt_node->inode;
            backward_path_cost = target_criticality * rt_node->Tdel;
            R_upstream = rt_node->R_upstream;
            tot_cost =
                backward_path_cost +
                astar_fac * get_timing_driven_expected_cost(inode,
                                                            target_node,
                                                            target_criticality,
                                                            R_upstream);
            node_to_heap(inode, tot_cost, NO_PREVIOUS, NO_PREVIOUS,
                         backward_path_cost, R_upstream);
        }

    linked_rt_edge = rt_node->u.child_list;

    while(linked_rt_edge != NULL)
        {
            child_node = linked_rt_edge->child;
            add_route_tree_to_heap(child_node, target_node,
                                   target_criticality, astar_fac);
            linked_rt_edge = linked_rt_edge->next;
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void alloc_timing_driven_route_structs	(	float **	pin_criticality_ptr,
		int **	sink_order_ptr,
		t_rt_node ***	rt_node_of_sink_ptr
	)

Definition at line 186 of file route_timing.c.

{

/* Allocates all the structures needed only by the timing-driven router.   */

    int max_pins_per_net;
    float *pin_criticality;
    int *sink_order;
    t_rt_node **rt_node_of_sink;

    max_pins_per_net = get_max_pins_per_net();

    pin_criticality =
        (float *)my_malloc((max_pins_per_net - 1) * sizeof(float));
    *pin_criticality_ptr = pin_criticality - 1; /* First sink is pin #1. */

    sink_order = (int *)my_malloc((max_pins_per_net - 1) * sizeof(int));
    *sink_order_ptr = sink_order - 1;

    rt_node_of_sink = (t_rt_node **) my_malloc((max_pins_per_net - 1) *
                                               sizeof(t_rt_node *));
    *rt_node_of_sink_ptr = rt_node_of_sink - 1;

    alloc_route_tree_timing_structs();
}

Here is the call graph for this function:

Here is the caller graph for this function:

void free_timing_driven_route_structs	(	float *	pin_criticality,
		int *	sink_order,
		t_rt_node **	rt_node_of_sink
	)

Definition at line 216 of file route_timing.c.

{

/* Frees all the stuctures needed only by the timing-driven router.        */

    free(pin_criticality + 1);  /* Starts at index 1. */
    free(sink_order + 1);
    free(rt_node_of_sink + 1);
    free_route_tree_timing_structs();
}

Here is the call graph for this function:

Here is the caller graph for this function:

static int get_expected_segs_to_target	(	int	inode,
		int	target_node,
		int *	num_segs_ortho_dir_ptr
	)			[static]

Definition at line 616 of file route_timing.c.

{

/* Returns the number of segments the same type as inode that will be needed *
 * to reach target_node (not including inode) in each direction (the same    *
 * direction (horizontal or vertical) as inode and the orthogonal direction).*/

    t_rr_type rr_type;
    int target_x, target_y, num_segs_same_dir, cost_index, ortho_cost_index;
    int no_need_to_pass_by_clb;
    float inv_length, ortho_inv_length, ylow, yhigh, xlow, xhigh;

    target_x = rr_node[target_node].xlow;
    target_y = rr_node[target_node].ylow;
    cost_index = rr_node[inode].cost_index;
    inv_length = rr_indexed_data[cost_index].inv_length;
    ortho_cost_index = rr_indexed_data[cost_index].ortho_cost_index;
    ortho_inv_length = rr_indexed_data[ortho_cost_index].inv_length;
    rr_type = rr_node[inode].type;

    if(rr_type == CHANX)
        {
            ylow = rr_node[inode].ylow;
            xhigh = rr_node[inode].xhigh;
            xlow = rr_node[inode].xlow;

            /* Count vertical (orthogonal to inode) segs first. */

            if(ylow > target_y)
                {               /* Coming from a row above target? */
                    *num_segs_ortho_dir_ptr =
                        ROUND_UP((ylow - target_y + 1.) * ortho_inv_length);
                    no_need_to_pass_by_clb = 1;
                }
            else if(ylow < target_y - 1)
                {               /* Below the FB bottom? */
                    *num_segs_ortho_dir_ptr = ROUND_UP((target_y - ylow) *
                                                       ortho_inv_length);
                    no_need_to_pass_by_clb = 1;
                }
            else
                {               /* In a row that passes by target FB */
                    *num_segs_ortho_dir_ptr = 0;
                    no_need_to_pass_by_clb = 0;
                }

            /* Now count horizontal (same dir. as inode) segs. */

            if(xlow > target_x + no_need_to_pass_by_clb)
                {
                    num_segs_same_dir =
                        ROUND_UP((xlow - no_need_to_pass_by_clb -
                                  target_x) * inv_length);
                }
            else if(xhigh < target_x - no_need_to_pass_by_clb)
                {
                    num_segs_same_dir =
                        ROUND_UP((target_x - no_need_to_pass_by_clb -
                                  xhigh) * inv_length);
                }
            else
                {
                    num_segs_same_dir = 0;
                }
        }

    else
        {                       /* inode is a CHANY */
            ylow = rr_node[inode].ylow;
            yhigh = rr_node[inode].yhigh;
            xlow = rr_node[inode].xlow;

            /* Count horizontal (orthogonal to inode) segs first. */

            if(xlow > target_x)
                {               /* Coming from a column right of target? */
                    *num_segs_ortho_dir_ptr =
                        ROUND_UP((xlow - target_x + 1.) * ortho_inv_length);
                    no_need_to_pass_by_clb = 1;
                }
            else if(xlow < target_x - 1)
                {               /* Left of and not adjacent to the FB? */
                    *num_segs_ortho_dir_ptr = ROUND_UP((target_x - xlow) *
                                                       ortho_inv_length);
                    no_need_to_pass_by_clb = 1;
                }
            else
                {               /* In a column that passes by target FB */
                    *num_segs_ortho_dir_ptr = 0;
                    no_need_to_pass_by_clb = 0;
                }

            /* Now count vertical (same dir. as inode) segs. */

            if(ylow > target_y + no_need_to_pass_by_clb)
                {
                    num_segs_same_dir =
                        ROUND_UP((ylow - no_need_to_pass_by_clb -
                                  target_y) * inv_length);
                }
            else if(yhigh < target_y - no_need_to_pass_by_clb)
                {
                    num_segs_same_dir =
                        ROUND_UP((target_y - no_need_to_pass_by_clb -
                                  yhigh) * inv_length);
                }
            else
                {
                    num_segs_same_dir = 0;
                }
        }

    return (num_segs_same_dir);
}

Here is the caller graph for this function:

static int get_max_pins_per_net

(

void

)

[static]

Definition at line 231 of file route_timing.c.

{

/* Returns the largest number of pins on any non-global net.    */

    int inet, max_pins_per_net;

    max_pins_per_net = 0;
    for(inet = 0; inet < num_nets; inet++)
        {
            if(net[inet].is_global == FALSE)
                {
                    max_pins_per_net =
                        max(max_pins_per_net, (net[inet].num_sinks + 1));
                }
        }

    return (max_pins_per_net);
}

Here is the caller graph for this function:

static float get_timing_driven_expected_cost	(	int	inode,
		int	target_node,
		float	criticality_fac,
		float	R_upstream
	)			[static]

Definition at line 546 of file route_timing.c.

{

/* Determines the expected cost (due to both delay and resouce cost) to reach *
 * the target node from inode.  It doesn't include the cost of inode --       *
 * that's already in the "known" path_cost.                                   */

    t_rr_type rr_type;
    int cost_index, ortho_cost_index, num_segs_same_dir, num_segs_ortho_dir;
    float expected_cost, cong_cost, Tdel;

    rr_type = rr_node[inode].type;

    if(rr_type == CHANX || rr_type == CHANY)
        {
            num_segs_same_dir =
                get_expected_segs_to_target(inode, target_node,
                                            &num_segs_ortho_dir);
            cost_index = rr_node[inode].cost_index;
            ortho_cost_index = rr_indexed_data[cost_index].ortho_cost_index;

            cong_cost =
                num_segs_same_dir * rr_indexed_data[cost_index].base_cost +
                num_segs_ortho_dir *
                rr_indexed_data[ortho_cost_index].base_cost;
            cong_cost +=
                rr_indexed_data[IPIN_COST_INDEX].base_cost +
                rr_indexed_data[SINK_COST_INDEX].base_cost;

            Tdel = num_segs_same_dir * rr_indexed_data[cost_index].T_linear +
                num_segs_ortho_dir *
                rr_indexed_data[ortho_cost_index].T_linear +
                num_segs_same_dir * num_segs_same_dir *
                rr_indexed_data[cost_index].T_quadratic +
                num_segs_ortho_dir * num_segs_ortho_dir *
                rr_indexed_data[ortho_cost_index].T_quadratic +
                R_upstream * (num_segs_same_dir *
                              rr_indexed_data[cost_index].C_load +
                              num_segs_ortho_dir *
                              rr_indexed_data[ortho_cost_index].C_load);

            Tdel += rr_indexed_data[IPIN_COST_INDEX].T_linear;

            expected_cost =
                criticality_fac * Tdel + (1. - criticality_fac) * cong_cost;
            return (expected_cost);
        }

    else if(rr_type == IPIN)
        {                       /* Change if you're allowing route-throughs */
            return (rr_indexed_data[SINK_COST_INDEX].base_cost);
        }

    else
        {                       /* Change this if you want to investigate route-throughs */
            return (0.);
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

static void timing_driven_check_net_delays

(

float **

net_delay

)

[static]

Definition at line 769 of file route_timing.c.

{

/* Checks that the net delays computed incrementally during timing driven    *
 * routing match those computed from scratch by the net_delay.c module.      */

    int inet, ipin;
    float **net_delay_check;
    struct s_linked_vptr *ch_list_head_net_delay_check;

    net_delay_check = alloc_net_delay(&ch_list_head_net_delay_check);
    load_net_delay_from_routing(net_delay_check);

    for(inet = 0; inet < num_nets; inet++)
        {
            for(ipin = 1; ipin <= net[inet].num_sinks; ipin++)
                {
                    if(net_delay_check[inet][ipin] == 0.)
                        {       /* Should be only GLOBAL nets */
                            if(net_delay[inet][ipin] != 0.)
                                {
                                    printf
                                        ("Error in timing_driven_check_net_delays: net %d pin %d."
                                         "\tIncremental calc. net_delay is %g, but from scratch "
                                         "net delay is %g.\n", inet, ipin,
                                         net_delay[inet][ipin],
                                         net_delay_check[inet][ipin]);
                                    exit(1);
                                }
                        }
                    else
                        {
                            if(fabs
                               (1. -
                                net_delay[inet][ipin] /
                                net_delay_check[inet][ipin]) > ERROR_TOL)
                                {
                                    printf
                                        ("Error in timing_driven_check_net_delays: net %d pin %d."
                                         "\tIncremental calc. net_delay is %g, but from scratch "
                                         "net delay is %g.\n", inet, ipin,
                                         net_delay[inet][ipin],
                                         net_delay_check[inet][ipin]);
                                    exit(1);
                                }
                        }
                }
        }

    free_net_delay(net_delay_check, &ch_list_head_net_delay_check);
    printf("Completed net delay value cross check successfully.\n");
}

Here is the call graph for this function:

Here is the caller graph for this function:

static void timing_driven_expand_neighbours	(	struct s_heap *	current,
		int	inet,
		float	bend_cost,
		float	criticality_fac,
		int	target_node,
		float	astar_fac
	)			[static]

Definition at line 453 of file route_timing.c.

{

/* Puts all the rr_nodes adjacent to current on the heap.  rr_nodes outside *
 * the expanded bounding box specified in route_bb are not added to the     *
 * heap.                                                                    */

    int iconn, to_node, num_edges, inode, iswitch, target_x, target_y;
    t_rr_type from_type, to_type;
    float new_tot_cost, old_back_pcost, new_back_pcost, R_upstream;
    float new_R_upstream, Tdel;

    inode = current->index;
    old_back_pcost = current->backward_path_cost;
    R_upstream = current->R_upstream;
    num_edges = rr_node[inode].num_edges;

    target_x = rr_node[target_node].xhigh;
    target_y = rr_node[target_node].yhigh;

    for(iconn = 0; iconn < num_edges; iconn++)
        {
            to_node = rr_node[inode].edges[iconn];

            if(rr_node[to_node].xhigh < route_bb[inet].xmin ||
               rr_node[to_node].xlow > route_bb[inet].xmax ||
               rr_node[to_node].yhigh < route_bb[inet].ymin ||
               rr_node[to_node].ylow > route_bb[inet].ymax)
                continue;       /* Node is outside (expanded) bounding box. */

/* Prune away IPINs that lead to blocks other than the target one.  Avoids  *
 * the issue of how to cost them properly so they don't get expanded before *
 * more promising routes, but makes route-throughs (via CLBs) impossible.   *
 * Change this if you want to investigate route-throughs.                   */

            to_type = rr_node[to_node].type;
            if(to_type == IPIN && (rr_node[to_node].xhigh != target_x ||
                                   rr_node[to_node].yhigh != target_y))
                continue;


/* new_back_pcost stores the "known" part of the cost to this node -- the   *
 * congestion cost of all the routing resources back to the existing route  *
 * plus the known delay of the total path back to the source.  new_tot_cost *
 * is this "known" backward cost + an expected cost to get to the target.   */

            new_back_pcost = old_back_pcost + (1. - criticality_fac) *
                get_rr_cong_cost(to_node);

            iswitch = rr_node[inode].switches[iconn];
            if(switch_inf[iswitch].buffered)
                {
                    new_R_upstream = switch_inf[iswitch].R;
                }
            else
                {
                    new_R_upstream = R_upstream + switch_inf[iswitch].R;
                }

            Tdel =
                rr_node[to_node].C * (new_R_upstream +
                                      0.5 * rr_node[to_node].R);
            Tdel += switch_inf[iswitch].Tdel;
            new_R_upstream += rr_node[to_node].R;
            new_back_pcost += criticality_fac * Tdel;

            if(bend_cost != 0.)
                {
                    from_type = rr_node[inode].type;
                    to_type = rr_node[to_node].type;
                    if((from_type == CHANX && to_type == CHANY) ||
                       (from_type == CHANY && to_type == CHANX))
                        new_back_pcost += bend_cost;
                }

            new_tot_cost = new_back_pcost + astar_fac *
                get_timing_driven_expected_cost(to_node, target_node,
                                                criticality_fac,
                                                new_R_upstream);

            node_to_heap(to_node, new_tot_cost, inode, iconn, new_back_pcost,
                         new_R_upstream);

        }                       /* End for all neighbours */
}

Here is the call graph for this function:

Here is the caller graph for this function:

boolean timing_driven_route_net	(	int	inet,
		float	pres_fac,
		float	max_criticality,
		float	criticality_exp,
		float	astar_fac,
		float	bend_cost,
		float *	net_slack,
		float *	pin_criticality,
		int *	sink_order,
		t_rt_node **	rt_node_of_sink,
		float	T_crit,
		float *	net_delay
	)

Definition at line 253 of file route_timing.c.

{

/* Returns TRUE as long is found some way to hook up this net, even if that *
 * way resulted in overuse of resources (congestion).  If there is no way   *
 * to route this net, even ignoring congestion, it returns FALSE.  In this  *
 * case the rr_graph is disconnected and you can give up.                   */

    int ipin, num_sinks, itarget, target_pin, target_node, inode;
    float target_criticality, old_tcost, new_tcost, largest_criticality,
        pin_crit;
    float old_back_cost, new_back_cost;
    t_rt_node *rt_root;
    struct s_heap *current;
    struct s_trace *new_route_start_tptr;

/* Rip-up any old routing. */

    pathfinder_update_one_cost(trace_head[inet], -1, pres_fac);
    free_traceback(inet);

    for(ipin = 1; ipin <= net[inet].num_sinks; ipin++)
        {                       /* For all sinks */
            pin_crit = max(max_criticality - net_slack[ipin] / T_crit, 0.);
            pin_crit = pow(pin_crit, criticality_exp);
            pin_crit = min(pin_crit, max_criticality);
            pin_criticality[ipin] = pin_crit;
        }

    num_sinks = net[inet].num_sinks;
    heapsort(sink_order, pin_criticality, num_sinks);

/* Update base costs according to fanout and criticality rules */

    largest_criticality = pin_criticality[sink_order[1]];
    update_rr_base_costs(inet, largest_criticality);

    mark_ends(inet);            /* Only needed to check for multiply-connected SINKs */

    rt_root = init_route_tree_to_source(inet);

    for(itarget = 1; itarget <= num_sinks; itarget++)
        {
            target_pin = sink_order[itarget];
            target_node = net_rr_terminals[inet][target_pin];

            target_criticality = pin_criticality[target_pin];

            add_route_tree_to_heap(rt_root, target_node, target_criticality,
                                   astar_fac);

            current = get_heap_head();

            if(current == NULL)
                {               /* Infeasible routing.  No possible path for net. */
                    reset_path_costs();
                    free_route_tree(rt_root);
                    return (FALSE);
                }

            inode = current->index;

            while(inode != target_node)
                {
                    old_tcost = rr_node_route_inf[inode].path_cost;
                    new_tcost = current->cost;

                    if(old_tcost > 0.99 * HUGE_FLOAT)   /* First time touched. */
                        old_back_cost = HUGE_FLOAT;
                    else
                        old_back_cost =
                            rr_node_route_inf[inode].backward_path_cost;

                    new_back_cost = current->backward_path_cost;

                    /* I only re-expand a node if both the "known" backward cost is lower  *
                     * in the new expansion (this is necessary to prevent loops from       *
                     * forming in the routing and causing havoc) *and* the expected total  *
                     * cost to the sink is lower than the old value.  Different R_upstream *
                     * values could make a path with lower back_path_cost less desirable   *
                     * than one with higher cost.  Test whether or not I should disallow   *
                     * re-expansion based on a higher total cost.                          */

                    if(old_tcost > new_tcost && old_back_cost > new_back_cost)
                        {
                            rr_node_route_inf[inode].prev_node =
                                current->u.prev_node;
                            rr_node_route_inf[inode].prev_edge =
                                current->prev_edge;
                            rr_node_route_inf[inode].path_cost = new_tcost;
                            rr_node_route_inf[inode].backward_path_cost =
                                new_back_cost;

                            if(old_tcost > 0.99 * HUGE_FLOAT)   /* First time touched. */
                                add_to_mod_list(&rr_node_route_inf[inode].
                                                path_cost);

                            timing_driven_expand_neighbours(current, inet,
                                                            bend_cost,
                                                            target_criticality,
                                                            target_node,
                                                            astar_fac);
                        }

                    free_heap_data(current);
                    current = get_heap_head();

                    if(current == NULL)
                        {       /* Impossible routing.  No path for net. */
                            reset_path_costs();
                            free_route_tree(rt_root);
                            return (FALSE);
                        }

                    inode = current->index;
                }

/* NB:  In the code below I keep two records of the partial routing:  the   *
 * traceback and the route_tree.  The route_tree enables fast recomputation *
 * of the Elmore delay to each node in the partial routing.  The traceback  *
 * lets me reuse all the routines written for breadth-first routing, which  *
 * all take a traceback structure as input.  Before this routine exits the  *
 * route_tree structure is destroyed; only the traceback is needed at that  *
 * point.                                                                   */

            rr_node_route_inf[inode].target_flag--;     /* Connected to this SINK. */
            new_route_start_tptr = update_traceback(current, inet);
            rt_node_of_sink[target_pin] = update_route_tree(current);
            free_heap_data(current);
            pathfinder_update_one_cost(new_route_start_tptr, 1, pres_fac);

            empty_heap();
            reset_path_costs();
        }

/* For later timing analysis. */

    update_net_delays_from_route_tree(net_delay, rt_node_of_sink, inet);
    free_route_tree(rt_root);
    return (TRUE);
}

Here is the call graph for this function:

Here is the caller graph for this function:

boolean try_timing_driven_route	(	struct s_router_opts	router_opts,
		float **	net_slack,
		float **	net_delay,
		t_ivec **	fb_opins_used_locally
	)

Definition at line 50 of file route_timing.c.

{

/* Timing-driven routing algorithm.  The timing graph (includes net_slack)   *
 * must have already been allocated, and net_delay must have been allocated. *
 * Returns TRUE if the routing succeeds, FALSE otherwise.                    */

    int itry, inet, ipin;
    boolean success, is_routable, rip_up_local_opins;
    float *pin_criticality;     /* [1..max_pins_per_net-1]. */
    int *sink_order;            /* [1..max_pins_per_net-1]. */
    t_rt_node **rt_node_of_sink;        /* [1..max_pins_per_net-1]. */
    float T_crit, pres_fac;

    alloc_timing_driven_route_structs(&pin_criticality, &sink_order,
                                      &rt_node_of_sink);

/* First do one routing iteration ignoring congestion and marking all sinks  *
 * on each net as critical to get reasonable net delay estimates.            */

    for(inet = 0; inet < num_nets; inet++)
        {
            if(net[inet].is_global == FALSE)
                {
                    for(ipin = 1; ipin <= net[inet].num_sinks; ipin++)
                        net_slack[inet][ipin] = 0.;
                }
            else
                {               /* Set delay of global signals to zero. */
                    for(ipin = 1; ipin <= net[inet].num_sinks; ipin++)
                        net_delay[inet][ipin] = 0.;
                }
        }

    T_crit = 1.;
    pres_fac = router_opts.first_iter_pres_fac; /* Typically 0 -> ignore cong. */

    for(itry = 1; itry <= router_opts.max_router_iterations; itry++)
        {

            for(inet = 0; inet < num_nets; inet++)
                {
                    if(net[inet].is_global == FALSE)
                        {       /* Skip global nets. */

                            is_routable =
                                timing_driven_route_net(inet, pres_fac,
                                                        router_opts.
                                                        max_criticality,
                                                        router_opts.
                                                        criticality_exp,
                                                        router_opts.astar_fac,
                                                        router_opts.bend_cost,
                                                        net_slack[inet],
                                                        pin_criticality,
                                                        sink_order,
                                                        rt_node_of_sink,
                                                        T_crit,
                                                        net_delay[inet]);

                            /* Impossible to route? (disconnected rr_graph) */

                            if(!is_routable)
                                {
                                    printf("Routing failed.\n");
                                    free_timing_driven_route_structs
                                        (pin_criticality, sink_order,
                                         rt_node_of_sink);
                                    return (FALSE);
                                }
                        }
                }

            /* Make sure any FB OPINs used up by subblocks being hooked directly     *
             * to them are reserved for that purpose.                                 */

            if(itry == 1)
                rip_up_local_opins = FALSE;
            else
                rip_up_local_opins = TRUE;

            reserve_locally_used_opins(pres_fac, rip_up_local_opins,
                                       fb_opins_used_locally);

            /* Pathfinder guys quit after finding a feasible route. I may want to keep *
             * going longer, trying to improve timing.  Think about this some.         */

            success = feasible_routing();
            if(success)
                {
                    printf
                        ("Successfully routed after %d routing iterations.\n",
                         itry);
                    free_timing_driven_route_structs(pin_criticality,
                                                     sink_order,
                                                     rt_node_of_sink);
#ifdef DEBUG
                    timing_driven_check_net_delays(net_delay);
#endif
                    return (TRUE);
                }

            if(itry == 1)
                {
                    pres_fac = router_opts.initial_pres_fac;
                    pathfinder_update_cost(pres_fac, 0.);       /* Acc_fac=0 for first iter. */
                }
            else
                {
                    pres_fac *= router_opts.pres_fac_mult;

                        /* Avoid overflow for high iteration counts, even if acc_cost is big */
                        pres_fac = min (pres_fac, HUGE_FLOAT / 1e5);

                    pathfinder_update_cost(pres_fac, router_opts.acc_fac);
                }

            /* Update slack values by doing another timing analysis.                 *
             * Timing_driven_route_net updated the net delay values.                 */

            load_timing_graph_net_delays(net_delay);
            T_crit = load_net_slack(net_slack, 0);
            printf("T_crit: %g.\n", T_crit);
        }

    printf("Routing failed.\n");
    free_timing_driven_route_structs(pin_criticality, sink_order,
                                     rt_node_of_sink);
    return (FALSE);
}

Here is the call graph for this function:

Here is the caller graph for this function:

static void update_rr_base_costs	(	int	inet,
		float	largest_criticality
	)			[static]

Definition at line 735 of file route_timing.c.

{

/* Changes the base costs of different types of rr_nodes according to the  *
 * criticality, fanout, etc. of the current net being routed (inet).       */

    float fanout, factor;
    int index;

    fanout = net[inet].num_sinks;

    /* Other reasonable values for factor include fanout and 1 */
    factor = sqrt(fanout);

    for(index = CHANX_COST_INDEX_START; index < num_rr_indexed_data; index++)
        {
            if(rr_indexed_data[index].T_quadratic > 0.)
                {               /* pass transistor */
                    rr_indexed_data[index].base_cost =
                        rr_indexed_data[index].saved_base_cost * factor;
                }
            else
                {
                    rr_indexed_data[index].base_cost =
                        rr_indexed_data[index].saved_base_cost;
                }
        }
}

Here is the caller graph for this function:
