SRC/graphics.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	t_point
Defines
#define	SCREEN   0
#define	POSTSCRIPT   1
#define	MAXPTS   100
Enumerations
enum	color_types {   WHITE, BLACK, DARKGREY, LIGHTGREY,   BLUE, GREEN, YELLOW, CYAN,   RED, DARKGREEN, MAGENTA, BISQUE,   LIGHTBLUE, THISTLE, PLUM, KHAKI,   CORAL, TURQUOISE, MEDIUMPURPLE, DARKSLATEBLUE,   DARKKHAKI, NUM_COLOR }
enum	line_types { SOLID, DASHED }
Functions
void	event_loop (void(*act_on_button)(float x, float y), void(*drawscreen)(void))
void	init_graphics (char *window_name)
void	close_graphics (void)
void	update_message (char *msg)
void	draw_message (void)
void	init_world (float xl, float yt, float xr, float yb)
void	flushinput (void)
void	setcolor (int cindex)
void	setlinestyle (int linestyle)
void	setlinewidth (int linewidth)
void	setfontsize (int pointsize)
void	drawline (float x1, float y1, float x2, float y2)
void	drawrect (float x1, float y1, float x2, float y2)
void	fillrect (float x1, float y1, float x2, float y2)
void	fillpoly (t_point *points, int npoints)
void	drawarc (float xcen, float ycen, float rad, float startang, float angextent)
void	fillarc (float xcen, float ycen, float rad, float startang, float angextent)
void	drawtext (float xc, float yc, const char *text, float boundx)
void	clearscreen (void)
void	create_button (char *prev_button_text, char *button_text, void(*button_func)(void(*drawscreen)(void)))
void	destroy_button (char *button_text)
int	init_postscript (char *fname)
void	close_postscript (void)

---

Define Documentation

#define MAXPTS   100

Definition at line 13 of file graphics.h.

#define POSTSCRIPT   1

Definition at line 2 of file graphics.h.

#define SCREEN   0

Definition at line 1 of file graphics.h.

---

Enumeration Type Documentation

enum color_types

Enumerator:

WHITE
BLACK
DARKGREY
LIGHTGREY
BLUE
GREEN
YELLOW
CYAN
RED
DARKGREEN
MAGENTA
BISQUE
LIGHTBLUE
THISTLE
PLUM
KHAKI
CORAL
TURQUOISE
MEDIUMPURPLE
DARKSLATEBLUE
DARKKHAKI
NUM_COLOR

Definition at line 4 of file graphics.h.

{ WHITE, BLACK, DARKGREY, LIGHTGREY, BLUE, GREEN, YELLOW,
  CYAN, RED, DARKGREEN, MAGENTA, BISQUE, LIGHTBLUE, THISTLE, PLUM, KHAKI,
  CORAL, TURQUOISE, MEDIUMPURPLE, DARKSLATEBLUE, DARKKHAKI, NUM_COLOR
};

enum line_types

Enumerator:

SOLID
DASHED

Definition at line 10 of file graphics.h.

{ SOLID, DASHED };

---

Function Documentation

void clearscreen

(

void

)

Definition at line 1205 of file graphics.c.

{
    int savecolor;

    if(disp_type == SCREEN)
        {
            XClearWindow(display, toplevel);
        }
    else
        {
/* erases current page.  Don't use erasepage, since this will erase *
 * everything, (even stuff outside the clipping path) causing       *
 * problems if this picture is incorporated into a larger document. */
            savecolor = currentcolor;
            setcolor(WHITE);
            fprintf(ps, "clippath fill\n\n");
            setcolor(savecolor);
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void close_graphics

(

void

)

Definition at line 1958 of file graphics.c.

{

/* Release all my drawing structures (through the X server) and *
 * close down the connection.                                   */

    int i;

    for(i = 1; i <= MAX_FONT_SIZE; i++)
        if(font_is_loaded[i])
            XFreeFont(display, font_info[i]);

    XFreeGC(display, gc);
    XFreeGC(display, gcxor);
    XFreeGC(display, gc_menus);

    if(private_cmap != None)
        XFreeColormap(display, private_cmap);

    XCloseDisplay(display);
    free(button);
}

Here is the caller graph for this function:

void close_postscript

(

void

)

Definition at line 2118 of file graphics.c.

{

/* Properly ends postscript output and redirects output to screen. */

    fprintf(ps, "showpage\n");
    fprintf(ps, "\n%%%%Trailer\n");
    fclose(ps);
    disp_type = SCREEN;
    update_transform();         /* Ensure screen world reflects any changes      *
                                 * made while printing.                          */

/* Need to make sure that we really set up the graphics context --  *
 * don't want the change requested to match the current setting and *
 * do nothing -> force the changes.                                 */

    force_setcolor(currentcolor);
    force_setlinestyle(currentlinestyle);
    force_setlinewidth(currentlinewidth);
    force_setfontsize(currentfontsize);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void create_button	(	char *	prev_button_text,
		char *	button_text,
		void(*)(void(*drawscreen)(void))	button_func
	)

Definition at line 585 of file graphics.c.

{

/* Creates a new button below the button containing prev_button_text.       *
 * The text and button function are set according to button_text and        *
 * button_func, respectively.                                               */

    int i, bnum, space;

    space = 8;

/* Only allow new buttons that are text (not poly) types.                   */

    bnum = -1;
    for(i = 4; i < num_buttons; i++)
        {
            if(button[i].istext == 1 &&
               strcmp(button[i].text, prev_button_text) == 0)
                {
                    bnum = i + 1;
                    break;
                }
        }

    if(bnum == -1)
        {
            printf
                ("Error in create_button:  button with text %s not found.\n",
                 prev_button_text);
            exit(1);
        }

    num_buttons++;
    button = (t_button *) my_realloc(button, num_buttons * sizeof(t_button));

/* NB:  Requirement that you specify the button that this button goes under *
 * guarantees that button[num_buttons-2] exists and is a text button.       */

    button[num_buttons - 1].xleft = button[num_buttons - 2].xleft;
    button[num_buttons - 1].ytop = button[num_buttons - 2].ytop +
        button[num_buttons - 2].height + space;
    button[num_buttons - 1].height = button[num_buttons - 2].height;
    button[num_buttons - 1].width = button[num_buttons - 2].width;
    map_button(num_buttons - 1);


    for(i = num_buttons - 1; i > bnum; i--)
        {
            button[i].ispoly = button[i - 1].ispoly;
/* No poly copy for now, as I'm only providing the ability to create text *
 * buttons.                                                               */

            button[i].istext = button[i - 1].istext;
            strcpy(button[i].text, button[i - 1].text);
            button[i].fcn = button[i - 1].fcn;
            button[i].ispressed = button[i - 1].ispressed;
        }

    button[bnum].istext = 1;
    button[bnum].ispoly = 0;
    my_strncpy(button[bnum].text, button_text, BUTTON_TEXT_LEN);
    button[bnum].fcn = button_func;
    button[bnum].ispressed = 1;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void destroy_button

(

char *

button_text

)

Definition at line 654 of file graphics.c.

{

/* Destroys the button with text button_text. */

    int i, bnum;

    bnum = -1;
    for(i = 4; i < num_buttons; i++)
        {
            if(button[i].istext == 1 &&
               strcmp(button[i].text, button_text) == 0)
                {
                    bnum = i;
                    break;
                }
        }

    if(bnum == -1)
        {
            printf
                ("Error in destroy_button:  button with text %s not found.\n",
                 button_text);
            exit(1);
        }

    for(i = bnum + 1; i < num_buttons; i++)
        {
            button[i - 1].ispoly = button[i].ispoly;
/* No poly copy for now, as I'm only providing the ability to create text *
 * buttons.                                                               */

            button[i - 1].istext = button[i].istext;
            strcpy(button[i - 1].text, button[i].text);
            button[i - 1].fcn = button[i].fcn;
            button[i - 1].ispressed = button[i].ispressed;
        }

    unmap_button(num_buttons - 1);
    num_buttons--;
    button = (t_button *) my_realloc(button, num_buttons * sizeof(t_button));
}

Here is the call graph for this function:

Here is the caller graph for this function:

void draw_message

(

void

)

Definition at line 1617 of file graphics.c.

{

/* Draw the current message in the text area at the screen bottom. */

    int len, width, savefontsize, savecolor;
    float ylow;

    if(disp_type == SCREEN)
        {
            XClearWindow(display, textarea);
            len = strlen(message);
            width = XTextWidth(font_info[menu_font_size], message, len);

            XSetForeground(display, gc_menus, colors[BLACK]);
            XDrawString(display, textarea, gc_menus,
                        (top_width - MWIDTH - width) / 2,
                        (T_AREA_HEIGHT - 4) / 2 +
                        (font_info[menu_font_size]->ascent -
                         font_info[menu_font_size]->descent) / 2, message,
                        len);
        }

    else
        {
/* Draw the message in the bottom margin.  Printer's generally can't  *
 * print on the bottom 1/4" (area with y < 18 in PostScript coords.)  */

            savecolor = currentcolor;
            setcolor(BLACK);
            savefontsize = currentfontsize;
            setfontsize(menu_font_size - 2);    /* Smaller OK on paper */
            ylow = ps_bot - 8.;
            fprintf(ps, "(%s) %.2f %.2f censhow\n", message,
                    (ps_left + ps_right) / 2., ylow);
            setcolor(savecolor);
            setfontsize(savefontsize);
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void drawarc	(	float	xcen,
		float	ycen,
		float	rad,
		float	startang,
		float	angextent
	)

Definition at line 1380 of file graphics.c.

{

/* Draws a circular arc.  X11 can do elliptical arcs quite simply, and *
 * PostScript could do them by scaling the coordinate axes.  Too much  *
 * work for now, and probably too complex an object for users to draw  *
 * much, so I'm just doing circular arcs.  Startang is relative to the *
 * Window's positive x direction.  Angles in degrees.                  */

    int xl, yt;
    unsigned int width, height;

/* Conservative (but fast) clip test -- check containing rectangle of *
 * a circle.                                                          */

    if(rect_off_screen(xc - rad, yc - rad, xc + rad, yc + rad))
        return;

/* X Windows has trouble with very large angles. (Over 360).    *
 * Do following to prevent its inaccurate (overflow?) problems. */
    if(fabs(angextent) > 360.)
        angextent = 360.;

    startang = angnorm(startang);

    if(disp_type == SCREEN)
        {
            xl = (int)(xcoord(xc) - fabs(xmult * rad));
            yt = (int)(ycoord(yc) - fabs(ymult * rad));
            width = (unsigned int)(2 * fabs(xmult * rad));
            height = width;
            XDrawArc(display, toplevel, gc, xl, yt, width, height,
                     (int)(startang * 64), (int)(angextent * 64));
        }
    else
        {
            fprintf(ps, "%.2f %.2f %.2f %.2f %.2f %s stroke\n", XPOST(xc),
                    YPOST(yc), fabs(rad * ps_xmult), startang,
                    startang + angextent,
                    (angextent < 0) ? "drawarcn" : "drawarc");
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void drawline	(	float	x1,
		float	y1,
		float	x2,
		float	y2
	)

Definition at line 1262 of file graphics.c.

{

/* Draw a line from (x1,y1) to (x2,y2) in the user-drawable area. *
 * Coordinates are in world (user) space.                         */

    if(rect_off_screen(x1, y1, x2, y2))
        return;

    if(disp_type == SCREEN)
        {
            /* Xlib.h prototype has x2 and y1 mixed up. */
            XDrawLine(display, toplevel, gc, xcoord(x1), ycoord(y1),
                      xcoord(x2), ycoord(y2));
        }
    else
        {
            fprintf(ps, "%.2f %.2f %.2f %.2f drawline\n", XPOST(x1),
                    YPOST(y1), XPOST(x2), YPOST(y2));
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void drawrect	(	float	x1,
		float	y1,
		float	x2,
		float	y2
	)

Definition at line 1288 of file graphics.c.

{

/* (x1,y1) and (x2,y2) are diagonally opposed corners, in world coords. */

    unsigned int width, height;
    int xw1, yw1, xw2, yw2, xl, yt;

    if(rect_off_screen(x1, y1, x2, y2))
        return;

    if(disp_type == SCREEN)
        {
/* translate to X Windows calling convention. */
            xw1 = xcoord(x1);
            xw2 = xcoord(x2);
            yw1 = ycoord(y1);
            yw2 = ycoord(y2);
            xl = min(xw1, xw2);
            yt = min(yw1, yw2);
            width = abs(xw1 - xw2);
            height = abs(yw1 - yw2);
            XDrawRectangle(display, toplevel, gc, xl, yt, width, height);
        }
    else
        {
            fprintf(ps, "%.2f %.2f %.2f %.2f drawrect\n", XPOST(x1),
                    YPOST(y1), XPOST(x2), YPOST(y2));
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void drawtext	(	float	xc,
		float	yc,
		const char *	text,
		float	boundx
	)

Definition at line 1533 of file graphics.c.

{

/* Draws text centered on xc,yc if it fits in boundx */

    int len, width, xw_off, yw_off;

    len = strlen(text);
    width = XTextWidth(font_info[currentfontsize], text, len);
    if(width > fabs(boundx * xmult))
        return;                 /* Don't draw if it won't fit */

    xw_off = width / (2. * xmult);      /* NB:  sign doesn't matter. */

/* NB:  2 * descent makes this slightly conservative but simplifies code. */
    yw_off = (font_info[currentfontsize]->ascent +
              2 * font_info[currentfontsize]->descent) / (2. * ymult);

/* Note:  text can be clipped when a little bit of it would be visible *
 * right now.  Perhaps X doesn't return extremely accurate width and   *
 * ascent values, etc?  Could remove this completely by multiplying    *
 * xw_off and yw_off by, 1.2 or 1.5.                                   */

    if(rect_off_screen(xc - xw_off, yc - yw_off, xc + xw_off, yc + yw_off))
        return;

    if(disp_type == SCREEN)
        {
            XDrawString(display, toplevel, gc, xcoord(xc) - width / 2,
                        ycoord(yc) + (font_info[currentfontsize]->ascent -
                                      font_info[currentfontsize]->descent) /
                        2, text, len);
        }
    else
        {
            fprintf(ps, "(%s) %.2f %.2f censhow\n", text, XPOST(xc),
                    YPOST(yc));
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void event_loop	(	void(*)(float x, float y)	act_on_button,
		void(*)(void)	drawscreen
	)

Definition at line 1118 of file graphics.c.

{

/* The program's main event loop.  Must be passed a user routine        *
 * drawscreen which redraws the screen.  It handles all window resizing *
 * zooming etc. itself.  If the user clicks a button in the graphics    *
 * (toplevel) area, the act_on_button routine passed in is called.      */

    XEvent report;
    int bnum;
    float x, y;

#define OFF 1
#define ON 0

    turn_on_off(ON);
    while(1)
        {
            XNextEvent(display, &report);
            switch (report.type)
                {
                case Expose:
#ifdef VERBOSE
                    printf("Got an expose event.\n");
                    printf("Count is: %d.\n", report.xexpose.count);
                    printf("Window ID is: %d.\n", report.xexpose.window);
#endif
                    if(report.xexpose.count != 0)
                        break;
                    if(report.xexpose.window == menu)
                        drawmenu();
                    else if(report.xexpose.window == toplevel)
                        drawscreen();
                    else if(report.xexpose.window == textarea)
                        draw_message();
                    break;
                case ConfigureNotify:
                    top_width = report.xconfigure.width;
                    top_height = report.xconfigure.height;
                    update_transform();
#ifdef VERBOSE
                    printf("Got a ConfigureNotify.\n");
                    printf("New width: %d  New height: %d.\n", top_width,
                           top_height);
#endif
                    break;
                case ButtonPress:
#ifdef VERBOSE
                    printf("Got a buttonpress.\n");
                    printf("Window ID is: %d.\n", report.xbutton.window);
#endif
                    if(report.xbutton.window == toplevel)
                        {
                            x = XTOWORLD(report.xbutton.x);
                            y = YTOWORLD(report.xbutton.y);
                            act_on_button(x, y);
                        }
                    else
                        {       /* A menu button was pressed. */
                            bnum = which_button(report.xbutton.window);
#ifdef VERBOSE
                            printf("Button number is %d\n", bnum);
#endif
                            button[bnum].ispressed = 1;
                            drawbut(bnum);
                            XFlush(display);    /* Flash the button */
                            button[bnum].fcn(drawscreen);
                            button[bnum].ispressed = 0;
                            drawbut(bnum);
                            if(button[bnum].fcn == proceed)
                                {
                                    turn_on_off(OFF);
                                    flushinput();
                                    return;     /* Rather clumsy way of returning *
                                                 * control to the simulator       */
                                }
                        }
                    break;
                }
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void fillarc	(	float	xcen,
		float	ycen,
		float	rad,
		float	startang,
		float	angextent
	)

Definition at line 1429 of file graphics.c.

{

/* Fills a circular arc.  Startang is relative to the Window's positive x   *
 * direction.  Angles in degrees.                                           */

    int xl, yt;
    unsigned int width, height;

/* Conservative (but fast) clip test -- check containing rectangle of *
 * a circle.                                                          */

    if(rect_off_screen(xc - rad, yc - rad, xc + rad, yc + rad))
        return;

/* X Windows has trouble with very large angles. (Over 360).    *
 * Do following to prevent its inaccurate (overflow?) problems. */

    if(fabs(angextent) > 360.)
        angextent = 360.;

    startang = angnorm(startang);

    if(disp_type == SCREEN)
        {
            xl = (int)(xcoord(xc) - fabs(xmult * rad));
            yt = (int)(ycoord(yc) - fabs(ymult * rad));
            width = (unsigned int)(2 * fabs(xmult * rad));
            height = width;
            XFillArc(display, toplevel, gc, xl, yt, width, height,
                     (int)(startang * 64), (int)(angextent * 64));
        }
    else
        {
            fprintf(ps, "%.2f %.2f %.2f %.2f %.2f %s\n", fabs(rad * ps_xmult),
                    startang, startang + angextent, XPOST(xc), YPOST(yc),
                    (angextent < 0) ? "fillarcn" : "fillarc");
        }
}

Here is the call graph for this function:

void fillpoly	(	t_point *	points,
		int	npoints
	)

Definition at line 1475 of file graphics.c.

{

    XPoint transpoints[MAXPTS];
    int i;
    float xmin, ymin, xmax, ymax;

    if(npoints > MAXPTS)
        {
            printf
                ("Error in fillpoly:  Only %d points allowed per polygon.\n",
                 MAXPTS);
            printf("%d points were requested.  Polygon is not drawn.\n",
                   npoints);
            return;
        }

/* Conservative (but fast) clip test -- check containing rectangle of *
 * polygon.                                                           */

    xmin = xmax = points[0].x;
    ymin = ymax = points[0].y;

    for(i = 1; i < npoints; i++)
        {
            xmin = min(xmin, points[i].x);
            xmax = max(xmax, points[i].x);
            ymin = min(ymin, points[i].y);
            ymax = max(ymax, points[i].y);
        }

    if(rect_off_screen(xmin, ymin, xmax, ymax))
        return;

    if(disp_type == SCREEN)
        {
            for(i = 0; i < npoints; i++)
                {
                    transpoints[i].x = (short)xcoord(points[i].x);
                    transpoints[i].y = (short)ycoord(points[i].y);
                }
            XFillPolygon(display, toplevel, gc, transpoints, npoints, Complex,
                         CoordModeOrigin);
        }
    else
        {
            fprintf(ps, "\n");

            for(i = npoints - 1; i >= 0; i--)
                fprintf(ps, "%.2f %.2f\n", XPOST(points[i].x),
                        YPOST(points[i].y));

            fprintf(ps, "%d fillpoly\n", npoints);
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void fillrect	(	float	x1,
		float	y1,
		float	x2,
		float	y2
	)

Definition at line 1324 of file graphics.c.

{

/* (x1,y1) and (x2,y2) are diagonally opposed corners in world coords. */

    unsigned int width, height;
    int xw1, yw1, xw2, yw2, xl, yt;

    if(rect_off_screen(x1, y1, x2, y2))
        return;

    if(disp_type == SCREEN)
        {
/* translate to X Windows calling convention. */
            xw1 = xcoord(x1);
            xw2 = xcoord(x2);
            yw1 = ycoord(y1);
            yw2 = ycoord(y2);
            xl = min(xw1, xw2);
            yt = min(yw1, yw2);
            width = abs(xw1 - xw2);
            height = abs(yw1 - yw2);
            XFillRectangle(display, toplevel, gc, xl, yt, width, height);
        }
    else
        {
            fprintf(ps, "%.2f %.2f %.2f %.2f fillrect\n", XPOST(x1),
                    YPOST(y1), XPOST(x2), YPOST(y2));
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void flushinput

(

void

)

Definition at line 1578 of file graphics.c.

{
    if(disp_type != SCREEN)
        return;
    XFlush(display);
}

Here is the caller graph for this function:

void init_graphics

(

char *

window_name

)

Definition at line 699 of file graphics.c.

{

    /* Open the toplevel window, get the colors, 2 graphics         *
     * contexts, load a font, and set up the toplevel window        *
     * Calls build_default_menu to set up the default menu.         */

    char *display_name = NULL;
    int x, y;                   /* window position */
    unsigned int border_width = 2;      /* ignored by OpenWindows */
    XTextProperty windowName;

/* X Windows' names for my colours. */
    char *cnames[NUM_COLOR] = { "white", "black", "grey55", "grey75", "blue",
        "green", "yellow", "cyan", "red", "RGBi:0.0/0.5/0.0", "magenta",
        "bisque", "lightblue", "thistle", "plum", "khaki",
        "coral", "turquoise", "mediumpurple", "darkslateblue", "darkkhaki"
    };

    XColor exact_def;
    Colormap cmap;
    int i;
    unsigned long valuemask = 0;        /* ignore XGCvalues and use defaults */
    XGCValues values;
    XEvent event;


    disp_type = SCREEN;         /* Graphics go to screen, not ps */

    for(i = 0; i <= MAX_FONT_SIZE; i++)
        font_is_loaded[i] = 0;  /* No fonts loaded yet. */

    /* connect to X server */
    if((display = XOpenDisplay(display_name)) == NULL)
        {
            fprintf(stderr, "Cannot connect to X server %s\n",
                    XDisplayName(display_name));
            exit(-1);
        }

    /* get screen size from display structure macro */
    screen_num = DefaultScreen(display);
    display_width = DisplayWidth(display, screen_num);
    display_height = DisplayHeight(display, screen_num);

    x = y = 0;

    top_width = 2 * display_width / 3;
    top_height = 4 * display_height / 5;

    cmap = DefaultColormap(display, screen_num);
    private_cmap = None;

    for(i = 0; i < NUM_COLOR; i++)
        {
            if(!XParseColor(display, cmap, cnames[i], &exact_def))
                {
                    fprintf(stderr, "Color name %s not in database",
                            cnames[i]);
                    exit(-1);
                }
            if(!XAllocColor(display, cmap, &exact_def))
                {
                    fprintf(stderr, "Couldn't allocate color %s.\n",
                            cnames[i]);

                    if(private_cmap == None)
                        {
                            fprintf(stderr,
                                    "Will try to allocate a private colourmap.\n");
                            fprintf(stderr,
                                    "Colours will only display correctly when your "
                                    "cursor is in the graphics window.\n"
                                    "Exit other colour applications and rerun this "
                                    "program if you don't like that.\n\n");

                            private_cmap =
                                XCopyColormapAndFree(display, cmap);
                            cmap = private_cmap;
                            if(!XAllocColor(display, cmap, &exact_def))
                                {
                                    fprintf(stderr,
                                            "Couldn't allocate color %s as private.\n",
                                            cnames[i]);
                                    exit(1);
                                }
                        }

                    else
                        {
                            fprintf(stderr,
                                    "Couldn't allocate color %s as private.\n",
                                    cnames[i]);
                            exit(1);
                        }
                }
            colors[i] = exact_def.pixel;
        }

    toplevel =
        XCreateSimpleWindow(display, RootWindow(display, screen_num), x, y,
                            top_width, top_height, border_width,
                            colors[BLACK], colors[WHITE]);

    if(private_cmap != None)
        XSetWindowColormap(display, toplevel, private_cmap);

    /* hints stuff deleted. */

    XSelectInput(display, toplevel, ExposureMask | StructureNotifyMask |
                 ButtonPressMask);


    /* Create default Graphics Contexts.  valuemask = 0 -> use defaults. */
    gc = XCreateGC(display, toplevel, valuemask, &values);
    gc_menus = XCreateGC(display, toplevel, valuemask, &values);

    /* Create XOR graphics context for Rubber Banding */
    values.function = GXxor;
    values.foreground = colors[BLACK];
    gcxor = XCreateGC(display, toplevel, (GCFunction | GCForeground),
                      &values);

    /* specify font for menus.  */
    load_font(menu_font_size);
    font_is_loaded[menu_font_size] = 1;
    XSetFont(display, gc_menus, font_info[menu_font_size]->fid);

/* Set drawing defaults for user-drawable area.  Use whatever the *
 * initial values of the current stuff was set to.                */
    force_setfontsize(currentfontsize);
    force_setcolor(currentcolor);
    force_setlinestyle(currentlinestyle);
    force_setlinewidth(currentlinewidth);

    XStringListToTextProperty(&window_name, 1, &windowName);
    XSetWMName(display, toplevel, &windowName);
/* Uncomment to set icon name */
/* XSetWMIconName (display, toplevel, &windowName); */

/* XStringListToTextProperty copies the window_name string into            *
 * windowName.value.  Free this memory now.                                */

    free(windowName.value);

    XMapWindow(display, toplevel);
    build_textarea();
    build_default_menu();

/* The following is completely unnecessary if the user is using the       *
 * interactive (event_loop) graphics.  It waits for the first Expose      *
 * event before returning so that I can tell the window manager has got   *
 * the top-level window up and running.  Thus the user can start drawing  *
 * into this window immediately, and there's no danger of the window not  *
 * being ready and output being lost.                                     */

    XPeekIfEvent(display, &event, test_if_exposed, NULL);
}

Here is the call graph for this function:

Here is the caller graph for this function:

int init_postscript

(

char *

fname

)

Definition at line 1983 of file graphics.c.

{
/* Opens a file for PostScript output.  The header information,  *
 * clipping path, etc. are all dumped out.  If the file could    *
 * not be opened, the routine returns 0; otherwise it returns 1. */

    ps = fopen(fname, "w");
    if(ps == NULL)
        {
            printf("Error: could not open %s for PostScript output.\n",
                   fname);
            printf("Drawing to screen instead.\n");
            return (0);
        }
    disp_type = POSTSCRIPT;     /* Graphics go to postscript file now. */

/* Header for minimal conformance with the Adobe structuring convention */
    fprintf(ps, "%%!PS-Adobe-1.0\n");
    fprintf(ps, "%%%%DocumentFonts: Helvetica\n");
    fprintf(ps, "%%%%Pages: 1\n");
/* Set up postscript transformation macros and page boundaries */
    update_ps_transform();
/* Bottom margin is at ps_bot - 15. to leave room for the on-screen message. */
    fprintf(ps, "%%%%BoundingBox: %d %d %d %d\n",
            (int)ps_left, (int)(ps_bot - 15.), (int)ps_right, (int)ps_top);
    fprintf(ps, "%%%%EndComments\n");

    fprintf(ps, "/censhow   %%draw a centered string\n");
    fprintf(ps, " { moveto               %% move to proper spot\n");
    fprintf(ps, "   dup stringwidth pop  %% get x length of string\n");
    fprintf(ps, "   -2 div               %% Proper left start\n");
    fprintf(ps,
            "   yoff rmoveto         %% Move left that much and down half font height\n");
    fprintf(ps, "   show newpath } def   %% show the string\n\n");

    fprintf(ps, "/setfontsize     %% set font to desired size and compute "
            "centering yoff\n");
    fprintf(ps, " { /Helvetica findfont\n");
    fprintf(ps, "   exch scalefont\n");
    fprintf(ps, "   setfont         %% Font size set ...\n\n");
    fprintf(ps, "   0 0 moveto      %% Get vertical centering offset\n");
    fprintf(ps, "   (Xg) true charpath\n");
    fprintf(ps, "   flattenpath pathbbox\n");
    fprintf(ps, "   /ascent exch def pop -1 mul /descent exch def pop\n");
    fprintf(ps, "   newpath\n");
    fprintf(ps, "   descent ascent sub 2 div /yoff exch def } def\n\n");

    fprintf(ps, "%% Next two lines for debugging only.\n");
    fprintf(ps, "/str 20 string def\n");
    fprintf(ps, "/pnum {str cvs print (  ) print} def\n");

    fprintf(ps, "/drawline      %% draw a line from (x2,y2) to (x1,y1)\n");
    fprintf(ps, " { moveto lineto stroke } def\n\n");

    fprintf(ps, "/rect          %% outline a rectangle \n");
    fprintf(ps, " { /y2 exch def /x2 exch def /y1 exch def /x1 exch def\n");
    fprintf(ps, "   x1 y1 moveto\n");
    fprintf(ps, "   x2 y1 lineto\n");
    fprintf(ps, "   x2 y2 lineto\n");
    fprintf(ps, "   x1 y2 lineto\n");
    fprintf(ps, "   closepath } def\n\n");

    fprintf(ps, "/drawrect      %% draw outline of a rectanagle\n");
    fprintf(ps, " { rect stroke } def\n\n");

    fprintf(ps, "/fillrect      %% fill in a rectanagle\n");
    fprintf(ps, " { rect fill } def\n\n");

    fprintf(ps, "/drawarc { arc stroke } def           %% draw an arc\n");
    fprintf(ps, "/drawarcn { arcn stroke } def "
            "        %% draw an arc in the opposite direction\n\n");

    fprintf(ps, "%%Fill a counterclockwise or clockwise arc sector, "
            "respectively.\n");
    fprintf(ps,
            "/fillarc { moveto currentpoint 5 2 roll arc closepath fill } "
            "def\n");
    fprintf(ps,
            "/fillarcn { moveto currentpoint 5 2 roll arcn closepath fill } "
            "def\n\n");

    fprintf(ps,
            "/fillpoly { 3 1 roll moveto         %% move to first point\n"
            "   2 exch 1 exch {pop lineto} for   %% line to all other points\n"
            "   closepath fill } def\n\n");


    fprintf(ps, "%%Color Definitions:\n");
    fprintf(ps, "/white { 1 setgray } def\n");
    fprintf(ps, "/black { 0 setgray } def\n");
    fprintf(ps, "/grey55 { .55 setgray } def\n");
    fprintf(ps, "/grey75 { .75 setgray } def\n");
    fprintf(ps, "/blue { 0 0 1 setrgbcolor } def\n");
    fprintf(ps, "/green { 0 1 0 setrgbcolor } def\n");
    fprintf(ps, "/yellow { 1 1 0 setrgbcolor } def\n");
    fprintf(ps, "/cyan { 0 1 1 setrgbcolor } def\n");
    fprintf(ps, "/red { 1 0 0 setrgbcolor } def\n");
    fprintf(ps, "/darkgreen { 0 0.5 0 setrgbcolor } def\n");
    fprintf(ps, "/magenta { 1 0 1 setrgbcolor } def\n");
        fprintf(ps, "/bisque { 1 0.9 0.8 setrgbcolor } def\n");
        fprintf(ps, "/lightblue { 0.7 0.8 0.9 setrgbcolor } def\n");
        fprintf(ps, "/thistle { 0.8 0.7 0.8 setrgbcolor } def\n");
        fprintf(ps, "/plum {0.8 0.6 0.8 setrgbcolor } def\n");
        fprintf(ps, "/khaki { 1 0.9 0.6 setrgbcolor } def\n");
        fprintf(ps, "/coral { 1 0.7 0.6 setrgbcolor } def\n");
        fprintf(ps, "/turquoise { 0.5 0.6 0.9 setrgbcolor } def\n");
        fprintf(ps, "/mediumpurple { 0.7 0.6 0.7 setrgbcolor } def\n");
        fprintf(ps, "/darkslateblue { 0.7 0.5 0.7 setrgbcolor } def\n");
        fprintf(ps, "/darkkhaki { 0.9 0.7 0.4 setrgbcolor } def\n");

    fprintf(ps, "\n%%Solid and dashed line definitions:\n");
    fprintf(ps, "/linesolid {[] 0 setdash} def\n");
    fprintf(ps, "/linedashed {[3 3] 0 setdash} def\n");

    fprintf(ps, "\n%%%%EndProlog\n");
    fprintf(ps, "%%%%Page: 1 1\n\n");

/* Set up PostScript graphics state to match current one. */
    force_setcolor(currentcolor);
    force_setlinestyle(currentlinestyle);
    force_setlinewidth(currentlinewidth);
    force_setfontsize(currentfontsize);

/* Draw this in the bottom margin -- must do before the clippath is set */
    draw_message();

/* Set clipping on page. */
    fprintf(ps, "%.2f %.2f %.2f %.2f rect ", ps_left, ps_bot, ps_right,
            ps_top);
    fprintf(ps, "clip newpath\n\n");

    return (1);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void init_world	(	float	xl,
		float	yt,
		float	xr,
		float	yb
	)

Definition at line 1587 of file graphics.c.

{

/* Sets the coordinate system the user wants to draw into.          */

    xleft = x1;
    xright = x2;
    ytop = y1;
    ybot = y2;

    saved_xleft = xleft;        /* Save initial world coordinates to allow full */
    saved_xright = xright;      /* view button to zoom all the way out.         */
    saved_ytop = ytop;
    saved_ybot = ybot;

    if(disp_type == SCREEN)
        {
            update_transform();
        }
    else
        {
            update_ps_transform();
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void setcolor

(

int

cindex

)

Definition at line 286 of file graphics.c.

{

    if(currentcolor != cindex)
        force_setcolor(cindex);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void setfontsize

(

int

pointsize

)

Definition at line 394 of file graphics.c.

{
/* For efficiency, this routine doesn't do anything if no change is *
 * implied.  If you want to force the graphics context or PS file   *
 * to have font info set, call force_setfontsize (this is necessary *
 * in initialization and X11 / Postscript switches).                */

    if(pointsize != currentfontsize)
        force_setfontsize(pointsize);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void setlinestyle

(

int

linestyle

)

Definition at line 320 of file graphics.c.

{

    if(linestyle != currentlinestyle)
        force_setlinestyle(linestyle);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void setlinewidth

(

int

linewidth

)

Definition at line 352 of file graphics.c.

{

    if(linewidth != currentlinewidth)
        force_setlinewidth(linewidth);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void update_message

(

char *

msg

)

Definition at line 1659 of file graphics.c.

{

/* Changes the message to be displayed on screen.   */

    my_strncpy(message, msg, BUFSIZE);
    draw_message();
}

Here is the call graph for this function:

Here is the caller graph for this function:
