SRC/check_route.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Functions
void	check_route (enum e_route_type route_type, int num_switch, t_ivec **fb_opins_used_locally)

---

Function Documentation

void check_route	(	enum e_route_type	route_type,
		int	num_switch,
		t_ivec **	fb_opins_used_locally
	)

Definition at line 39 of file check_route.c.

{

/* This routine checks that a routing:  (1) Describes a properly         *
 * connected path for each net, (2) this path connects all the           *
 * pins spanned by that net, and (3) that no routing resources are       *
 * oversubscribed (the occupancy of everything is recomputed from        *
 * scratch).                                                             */

    int inet, ipin, max_pins, inode, prev_node;
    boolean valid, connects;
    boolean *connected_to_route;        /* [0 .. num_rr_nodes-1] */
    struct s_trace *tptr;
    boolean *pin_done;

    printf("\nChecking to ensure routing is legal ...\n");

/* Recompute the occupancy from scratch and check for overuse of routing *
 * resources.  This was already checked in order to determine that this  *
 * is a successful routing, but I want to double check it here.          */

    recompute_occupancy_from_scratch(fb_opins_used_locally);
    valid = feasible_routing();
    if(valid == FALSE)
        {
            printf
                ("Error in check_route -- routing resources are overused.\n");
            exit(1);
        }

    check_locally_used_fb_opins(fb_opins_used_locally, route_type);

    connected_to_route = (boolean *) my_calloc(num_rr_nodes, sizeof(boolean));

    max_pins = 0;
    for(inet = 0; inet < num_nets; inet++)
        max_pins = max(max_pins, (net[inet].num_sinks + 1));

    pin_done = (boolean *) my_malloc(max_pins * sizeof(boolean));

/* Now check that all nets are indeed connected. */

    for(inet = 0; inet < num_nets; inet++)
        {

            if(net[inet].is_global)     /* Skip global nets. */
                continue;

            for(ipin = 0; ipin < (net[inet].num_sinks + 1); ipin++)
                pin_done[ipin] = FALSE;

/* Check the SOURCE of the net. */

            tptr = trace_head[inet];
            if(tptr == NULL)
                {
                    printf("Error in check_route:  net %d has no routing.\n",
                           inet);
                    exit(1);
                }

            inode = tptr->index;
            check_node_and_range(inode, route_type);
            check_switch(tptr, num_switch);
            connected_to_route[inode] = TRUE;   /* Mark as in path. */

            check_source(inode, inet);
            pin_done[0] = TRUE;

            prev_node = inode;
            tptr = tptr->next;

/* Check the rest of the net */

            while(tptr != NULL)
                {
                    inode = tptr->index;
                    check_node_and_range(inode, route_type);
                    check_switch(tptr, num_switch);

                    if(rr_node[prev_node].type == SINK)
                        {
                            if(connected_to_route[inode] == FALSE)
                                {
                                    printf
                                        ("Error in check_route.  Node %d does not link "
                                         "into the existing routing for net %d.\n",
                                         inode, inet);
                                    exit(1);
                                }
                        }

                    else
                        {
                            connects = check_adjacent(prev_node, inode);
                            if(!connects)
                                {
                                    printf
                                        ("Error in check_route while checking net %d.\n",
                                         inet);
                                    printf
                                        ("Non-adjacent segments in traceback.\n");
                                    exit(1);
                                }

                            if(connected_to_route[inode]
                               && rr_node[inode].type != SINK)
                                {

                                    /* Note:  Can get multiple connections to the same logically-equivalent     *
                                     * SINK in some logic blocks.                                               */

                                    printf
                                        ("Error in check_route:  net %d routing is not a tree.\n",
                                         inet);
                                    exit(1);
                                }

                            connected_to_route[inode] = TRUE;   /* Mark as in path. */

                            if(rr_node[inode].type == SINK)
                                check_sink(inode, inet, pin_done);

                        }       /* End of prev_node type != SINK */
                    prev_node = inode;
                    tptr = tptr->next;
                }               /* End while */

            if(rr_node[prev_node].type != SINK)
                {
                    printf("Error in check_route.  Net %d does not end\n",
                           inet);
                    printf("with a SINK.\n");
                    exit(1);
                }

            for(ipin = 0; ipin < (net[inet].num_sinks + 1); ipin++)
                {
                    if(pin_done[ipin] == FALSE)
                        {
                            printf
                                ("Error in check_route.  Net %d does not \n",
                                 inet);
                            printf("connect to pin %d.\n", ipin);
                            exit(1);
                        }
                }

            reset_flags(inet, connected_to_route);

        }                       /* End for each net */

    free(pin_done);
    free(connected_to_route);
    printf("Completed routing consistency check successfully.\n\n");
}

Here is the call graph for this function:

Here is the caller graph for this function:
