SRC/segment_stats.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Functions
void	get_segment_usage_stats (int num_segment, t_segment_inf *segment_inf)

---

Function Documentation

void get_segment_usage_stats	(	int	num_segment,
		t_segment_inf *	segment_inf
	)

Definition at line 18 of file segment_stats.c.

{

/* Computes statistics on the fractional utilization of segments by type    *
 * (index) and by length.  This routine needs a valid rr_graph, and a       *
 * completed routing.  Note that segments cut off by the end of the array   *
 * are counted as full-length segments (e.g. length 4 even if the last 2    *
 * units of wire were chopped off by the chip edge).                        */

    int inode, length, seg_type, max_segment_length, cost_index;
    int *seg_occ_by_length, *seg_cap_by_length; /* [0..max_segment_length] */
    int *seg_occ_by_type, *seg_cap_by_type;     /* [0..num_segment-1]      */
    float utilization;


    max_segment_length = 0;
    for(seg_type = 0; seg_type < num_segment; seg_type++)
        {
            if(segment_inf[seg_type].longline == FALSE)
                max_segment_length = max(max_segment_length,
                                         segment_inf[seg_type].length);
        }

    seg_occ_by_length = (int *)my_calloc((max_segment_length + 1),
                                         sizeof(int));
    seg_cap_by_length = (int *)my_calloc((max_segment_length + 1),
                                         sizeof(int));

    seg_occ_by_type = (int *)my_calloc(num_segment, sizeof(int));
    seg_cap_by_type = (int *)my_calloc(num_segment, sizeof(int));


    for(inode = 0; inode < num_rr_nodes; inode++)
        {
            if(rr_node[inode].type == CHANX || rr_node[inode].type == CHANY)
                {
                    cost_index = rr_node[inode].cost_index;
                    seg_type = rr_indexed_data[cost_index].seg_index;

                    if(!segment_inf[seg_type].longline)
                        length = segment_inf[seg_type].length;
                    else
                        length = LONGLINE;

                    seg_occ_by_length[length] += rr_node[inode].occ;
                    seg_cap_by_length[length] += rr_node[inode].capacity;
                    seg_occ_by_type[seg_type] += rr_node[inode].occ;
                    seg_cap_by_type[seg_type] += rr_node[inode].capacity;

                }
        }

    printf("\nSegment usage by type (index):\n");
    printf("Segment type       Fractional utilization\n");
    printf("------------       ----------------------\n");

    for(seg_type = 0; seg_type < num_segment; seg_type++)
        {
            if(seg_cap_by_type[seg_type] != 0)
                {
                    utilization = (float)seg_occ_by_type[seg_type] /
                        (float)seg_cap_by_type[seg_type];
                    printf("%8d                  %5.3g\n", seg_type,
                           utilization);
                }
        }


    printf("\nSegment usage by length:\n");
    printf("Segment length       Fractional utilization\n");
    printf("--------------       ----------------------\n");


    for(length = 1; length <= max_segment_length; length++)
        {
            if(seg_cap_by_length[length] != 0)
                {
                    utilization = (float)seg_occ_by_length[length] /
                        (float)seg_cap_by_length[length];
                    printf("%9d                   %5.3g\n", length,
                           utilization);
                }
        }

    if(seg_cap_by_length[LONGLINE] != 0)
        {
            utilization = (float)seg_occ_by_length[LONGLINE] /
                (float)seg_cap_by_length[LONGLINE];
            printf("   longline                 %5.3g\n", utilization);
        }


    free(seg_occ_by_length);
    free(seg_cap_by_length);
    free(seg_occ_by_type);
    free(seg_cap_by_type);
}

Here is the call graph for this function:

Here is the caller graph for this function:
