output_blif.c File Reference

#include <string.h>
#include <stdio.h>
#include <stdlib.h>
#include <stdarg.h>
#include "types.h"
#include "globals.h"
#include "errors.h"
#include "netlist_utils.h"
#include "odin_util.h"
#include "outputs.h"
#include "util.h"
#include "multipliers.h"
#include "hard_blocks.h"
Include dependency graph for output_blif.c:

Go to the source code of this file.

Functions

void depth_first_traversal_to_output (short marker_value, FILE *fp, netlist_t *netlist)
void depth_traverse_output_blif (nnode_t *node, int traverse_mark_number, FILE *fp)
void output_node (nnode_t *node, short traverse_number, FILE *fp)
void define_logical_function (nnode_t *node, short type, FILE *out)
void define_set_input_logical_function (nnode_t *node, char *bit_output, FILE *out)
void define_ff (nnode_t *node, FILE *out)
void define_decoded_mux (nnode_t *node, FILE *out)
void output_blif_pin_connect (nnode_t *node, FILE *out)
void output_blif (char *file_name, netlist_t *netlist)

Function Documentation

void define_decoded_mux ( nnode_t *  node,
FILE *  out
)

Definition at line 623 of file output_blif.c.

00624 {
00625         int i, j;
00626
00627         oassert(node->input_port_sizes[0] == node->input_port_sizes[1]);
00628
00629         fprintf(out, ".names");
00630
00631         if (global_args.high_level_block != NULL)
00632         {
00633                 /* printout all the port hookups */
00634                 for (i = 0; i < node->num_input_pins; i++)
00635                 {
00636                         /* now hookup the input wires with their respective ports.  [1+i] to skip output spot. */
00637                         if (node->input_pins[i]->net->driver_pin->node->related_ast_node != NULL)
00638                         {
00639                                 fprintf(out, " %s^^%i-%i", node->input_pins[i]->net->driver_pin->node->name, node->input_pins[i]->net->driver_pin->node->related_ast_node->far_tag, node->input_pins[i]->net->driver_pin->node->related_ast_node->high_number);
00640                         }
00641                         else
00642                         {
00643                                 fprintf(out, " %s", node->input_pins[i]->net->driver_pin->node->name);
00644                         }
00645                 }
00646                 /* now print the output */
00647                 if (node->related_ast_node != NULL)
00648                         fprintf(out, " %s^^%i-%i", node->name, node->related_ast_node->far_tag, node->related_ast_node->high_number);
00649                 else
00650                         fprintf(out, " %s", node->name);
00651         }
00652         else
00653         {
00654                 /* printout all the port hookups */
00655                 for (i = 0; i < node->num_input_pins; i++)
00656                 {
00657                         /* now hookup the input wires with their respective ports.  [1+i] to skip output spot. */
00658                         /* Just print the driver_pin->name NOT driver_pin->node->name -- KEN */
00659                         if ((node->input_pins[i]->net->driver_pin->node->type == MULTIPLY) ||
00660                             (node->input_pins[i]->net->driver_pin->node->type == HARD_IP) ||
00661                             (node->input_pins[i]->net->driver_pin->node->type == MEMORY))
00662                         {
00663                                 fprintf(out, " %s", node->input_pins[i]->net->driver_pin->name);
00664                         }
00665                         else
00666                         {
00667                                 fprintf(out, " %s", node->input_pins[i]->net->driver_pin->node->name);
00668                         }
00669                 }
00670                 /* now print the output */
00671                 fprintf(out, " %s", node->name);
00672         }
00673         fprintf(out, "\n");
00674
00675         oassert(node->num_output_pins == 1);
00676
00677         /* generates: 1----- 1\n-1----- 1\n ... */
00678         for (i = 0; i < node->input_port_sizes[0]; i++)
00679         {
00680                 for (j = 0; j < node->num_input_pins; j++)
00681                 {
00682                         if (i == j)
00683                                 fprintf(out, "1");
00684                         else if (i+node->input_port_sizes[0] == j)
00685                                 fprintf(out, "1");
00686                         else if (i > node->input_port_sizes[0])
00687                                 fprintf(out, "0");
00688                         else
00689                                 fprintf(out, "-");
00690                 }
00691                 fprintf(out, " 1\n");
00692         }
00693
00694         fprintf(out, "\n");
00695 }

Here is the caller graph for this function:

void define_ff ( nnode_t *  node,
FILE *  out
)

Definition at line 601 of file output_blif.c.

00602 {
00603         oassert(node->num_output_pins == 1);
00604         oassert(node->num_input_pins == 2);
00605
00606         /* input, output, clock */
00607         if (global_args.high_level_block != NULL)
00608                 fprintf(out, ".latch %s^^%i-%i %s^^%i-%i re %s^^%i-%i 0", node->input_pins[0]->net->driver_pin->node->name, node->input_pins[0]->net->driver_pin->node->related_ast_node->far_tag, node->input_pins[0]->net->driver_pin->node->related_ast_node->high_number, node->name, node->related_ast_node->far_tag, node->related_ast_node->high_number, node->input_pins[1]->net->driver_pin->node->name, node->input_pins[1]->net->driver_pin->node->related_ast_node->far_tag, node->input_pins[1]->net->driver_pin->node->related_ast_node->high_number);
00609         else
00610         {
00611                 if (node->input_pins[1]->net->driver_pin != NULL)
00612                         fprintf(out, ".latch %s %s re %s 0\n", node->input_pins[0]->net->driver_pin->name, node->name, node->input_pins[1]->net->driver_pin->node->name);
00613                 else
00614                         fprintf(out, ".latch %s %s re %s 0\n", node->input_pins[0]->net->driver_pin->node->name, node->name, node->input_pins[1]->net->driver_pin->node->name);
00615         }
00616
00617         fprintf(out, "\n");
00618 }

Here is the caller graph for this function:

void define_logical_function ( nnode_t *  node,
short  type,
FILE *  out
)

Definition at line 372 of file output_blif.c.

00373 {
00374         int i, j;
00375         char *temp_string;
00376         int flag = 0;
00377
00378         fprintf(out, ".names");
00379
00380
00381         if (global_args.high_level_block != NULL)
00382         {
00383                 /* printout all the port hookups */
00384                 for (i = 0; i < node->num_input_pins; i++)
00385                 {
00386                         /* now hookup the input wires with their respective ports.  [1+i] to skip output spot. */
00387                         if (node->input_pins[i]->net->driver_pin->node->related_ast_node != NULL)
00388                                 fprintf(out, " %s^^%i-%i", node->input_pins[i]->net->driver_pin->node->name,    node->input_pins[i]->net->driver_pin->node->related_ast_node->far_tag, node->input_pins[i]->net->driver_pin->node->related_ast_node->high_number);
00389                         else
00390                                 fprintf(out, " %s", node->input_pins[i]->net->driver_pin->node->name);
00391                 }
00392                 /* now print the output */
00393                 if (node->related_ast_node != NULL)
00394                         fprintf(out, " %s^^%i-%i", node->name, node->related_ast_node->far_tag, node->related_ast_node->high_number);
00395                 else
00396                         fprintf(out, " %s", node->name);
00397         }
00398         else
00399         {
00400                 /* printout all the port hookups */
00401                 for (i = 0; i < node->num_input_pins; i++)
00402                 {
00403                         /* now hookup the input wires with their respective ports.  [1+i] to skip output spot. */
00404                         /* Just print the driver_pin->name NOT driver_pin->node->name -- KEN */
00405                         if ((node->input_pins[i]->net->driver_pin->node->type == MULTIPLY) ||
00406                             (node->input_pins[i]->net->driver_pin->node->type == HARD_IP) ||
00407                             (node->input_pins[i]->net->driver_pin->node->type == MEMORY))
00408                         {
00409                                 fprintf(out, " %s", node->input_pins[i]->net->driver_pin->name);
00410                         }
00411                         else
00412                         {
00413                                 fprintf(out, " %s", node->input_pins[i]->net->driver_pin->node->name);
00414                         }
00415                 }
00416                 /* now print the output */
00417                 fprintf(out, " %s", node->name);
00418         }
00419         fprintf(out, "\n");
00420
00421         oassert(node->num_output_pins == 1);
00422
00423         /* print out the blif definition of this gate */
00424         switch (node->type)
00425         {
00426                 case LOGICAL_AND:
00427                 {
00428                         /* generates: 111111 1 */
00429                         for (i = 0; i < node->num_input_pins; i++)
00430                         {
00431                                 fprintf(out, "1");
00432                         }
00433                         fprintf(out, " 1\n");
00434                         break;
00435                 }
00436                 case LOGICAL_OR:
00437                 {
00438                         /* generates: 1----- 1\n-1----- 1\n ... */
00439                         for (i = 0; i < node->num_input_pins; i++)
00440                         {
00441                                 for (j = 0; j < node->num_input_pins; j++)
00442                                 {
00443                                         if (i == j)
00444                                                 fprintf(out, "1");
00445                                         else
00446                                                 fprintf(out, "-");
00447                                 }
00448                                 fprintf(out, " 1\n");
00449                         }
00450                         break;
00451                 }
00452                 case LOGICAL_NAND:
00453                 {
00454                         /* generates: 0----- 1\n-0----- 1\n ... */
00455                         for (i = 0; i < node->num_input_pins; i++)
00456                         {
00457                                 for (j = 0; j < node->num_input_pins; j++)
00458                                 {
00459                                         if (i == j)
00460                                                 fprintf(out, "0");
00461                                         else
00462                                                 fprintf(out, "-");
00463                                 }
00464                                 fprintf(out, " 1\n");
00465                         }
00466                         break;
00467                 }
00468                 case LOGICAL_NOT:
00469                 case LOGICAL_NOR:
00470                 {
00471                         /* generates: 0000000 1 */
00472                         for (i = 0; i < node->num_input_pins; i++)
00473                         {
00474                                 fprintf(out, "0");
00475                         }
00476                         fprintf(out, " 1\n");
00477                         break;
00478                 }
00479                 case LOGICAL_EQUAL:
00480                 case LOGICAL_XOR:
00481                 {
00482                         oassert(node->num_input_pins <= 3);
00483                         /* generates: a 1 when odd number of 1s */
00484                         for (i = 0; i < my_power(2, node->num_input_pins); i++)
00485                         {
00486                                 if ((i % 8 == 1) || (i % 8 == 2) || (i % 8 == 4) || (i % 8 == 7))
00487                                 {
00488                                         temp_string = convert_long_to_bit_string(i, node->num_input_pins);
00489                                         fprintf(out, "%s", temp_string);
00490                                         free(temp_string);
00491                                         fprintf(out, " 1\n");
00492                                 }
00493                         }
00494                         break;
00495                 }
00496                 case NOT_EQUAL:
00497                 case LOGICAL_XNOR:
00498                 {
00499                         oassert(node->num_input_pins <= 3);
00500                         for (i = 0; i < my_power(2, node->num_input_pins); i++)
00501                         {
00502                                 if ((i % 8 == 0) || (i % 8 == 3) || (i % 8 == 5) || (i % 8 == 6))
00503                                 {
00504                                         temp_string = convert_long_to_bit_string(i, node->num_input_pins);
00505                                         fprintf(out, "%s", temp_string);
00506                                         free(temp_string);
00507                                         fprintf(out, " 1\n");
00508                                 }
00509                         }
00510                         break;
00511                 }
00512                 default:
00513                         oassert(FALSE);
00514                         break;
00515         }
00516
00517         fprintf(out, "\n");
00518         if (flag == 1)
00519                 output_blif_pin_connect(node, out);
00520 }

Here is the call graph for this function:

Here is the caller graph for this function:

void define_set_input_logical_function ( nnode_t *  node,
char *  bit_output,
FILE *  out
)

Definition at line 525 of file output_blif.c.

00526 {
00527         int i;
00528         int flag = 0;
00529
00530         fprintf(out, ".names");
00531
00532         oassert(node->num_output_pins == 1);
00533         oassert(node->num_input_pins >= 1);
00534
00535
00536         if (global_args.high_level_block != NULL)
00537         {
00538                 /* printout all the port hookups */
00539                 for (i = 0; i < node->num_input_pins; i++)
00540                 {
00541                         /* now hookup the input wires with their respective ports.  [1+i] to skip output spot. */
00542                         if (node->input_pins[i]->net->driver_pin->node->related_ast_node != NULL)
00543                                 fprintf(out, " %s^^%i-%i", node->input_pins[i]->net->driver_pin->node->name, node->input_pins[i]->net->driver_pin->node->related_ast_node->far_tag, node->input_pins[i]->net->driver_pin->node->related_ast_node->high_number);
00544                         else
00545                                 fprintf(out, " %s", node->input_pins[i]->net->driver_pin->node->name);
00546                 }
00547
00548                 /* now print the output */
00549                 if (node->related_ast_node != NULL)
00550                         fprintf(out, " %s^^%i-%i", node->name, node->related_ast_node->far_tag, node->related_ast_node->high_number);
00551                 else
00552                         fprintf(out, " %s", node->name);
00553                 fprintf(out, "\n");
00554
00555                 /* print out the blif definition of this gate */
00556                 if (bit_output != NULL)
00557                 {
00558                         fprintf(out, "%s", bit_output);
00559                 }
00560                 fprintf(out, "\n");
00561         }
00562         else
00563         {
00564                 /* printout all the port hookups */
00565                 for (i = 0; i < node->num_input_pins; i++)
00566                 {
00567                         /* now hookup the input wires with their respective ports.  [1+i] to skip output spot. */
00568                         /* Just print the driver_pin->name NOT driver_pin->node->name -- KEN */
00569                         if ((node->input_pins[i]->net->driver_pin->node->type == MULTIPLY) ||
00570                             (node->input_pins[i]->net->driver_pin->node->type == HARD_IP) ||
00571                             (node->input_pins[i]->net->driver_pin->node->type == MEMORY))
00572                         {
00573                                 fprintf(out, " %s", node->input_pins[i]->net->driver_pin->name);
00574                         }
00575                         else
00576                         {
00577                                 fprintf(out, " %s", node->input_pins[i]->net->driver_pin->node->name);
00578                         }
00579                 }
00580
00581                 /* now print the output */
00582                 fprintf(out, " %s", node->name);
00583                 fprintf(out, "\n");
00584
00585                 /* print out the blif definition of this gate */
00586                 if (bit_output != NULL)
00587                 {
00588                         fprintf(out, "%s", bit_output);
00589                 }
00590                 fprintf(out, "\n");
00591         }
00592
00593         if ((flag == 1) && (node->type == HARD_IP))
00594                 output_blif_pin_connect(node, out);
00595 }

Here is the call graph for this function:

Here is the caller graph for this function:

void depth_first_traversal_to_output ( short  marker_value,
FILE *  fp,
netlist_t *  netlist
)

Definition at line 205 of file output_blif.c.

00206 {
00207         int i;
00208
00209         netlist->gnd_node->name = "gnd";
00210         netlist->vcc_node->name = "vcc";
00211         netlist->pad_node->name = "unconn";
00212         /* now traverse the ground, vcc, and unconn pins */
00213         depth_traverse_output_blif(netlist->gnd_node, marker_value, fp);
00214         depth_traverse_output_blif(netlist->vcc_node, marker_value, fp);
00215         depth_traverse_output_blif(netlist->pad_node, marker_value, fp);
00216
00217         /* start with the primary input list */
00218         for (i = 0; i < netlist->num_top_input_nodes; i++)
00219         {
00220                 if (netlist->top_input_nodes[i] != NULL)
00221                 {
00222                         depth_traverse_output_blif(netlist->top_input_nodes[i], marker_value, fp);
00223                 }
00224         }
00225 }

Here is the call graph for this function:

Here is the caller graph for this function:

void depth_traverse_output_blif ( nnode_t *  node,
int  traverse_mark_number,
FILE *  fp
)

Definition at line 230 of file output_blif.c.

00231 {
00232         int i, j;
00233         nnode_t *next_node;
00234         nnet_t *next_net;
00235
00236         if (node->traverse_visited == traverse_mark_number)
00237         {
00238                 return;
00239         }
00240         else
00241         {
00242                 /* ELSE - this is a new node so depth visit it */
00243
00244                 /* POST traverse  map the node since you might delete */
00245                 output_node(node, traverse_mark_number, fp);
00246
00247                 /* mark that we have visitied this node now */
00248                 node->traverse_visited = traverse_mark_number;
00249
00250                 for (i = 0; i < node->num_output_pins; i++)
00251                 {
00252                         if (node->output_pins[i]->net == NULL)
00253                                 continue;
00254
00255                         next_net = node->output_pins[i]->net;
00256                         for (j = 0; j < next_net->num_fanout_pins; j++)
00257                         {
00258                                 if (next_net->fanout_pins[j] == NULL)
00259                                         continue;
00260
00261                                 next_node = next_net->fanout_pins[j]->node;
00262                                 if (next_node == NULL)
00263                                         continue;
00264
00265                                 /* recursive call point */
00266                                 depth_traverse_output_blif(next_node, traverse_mark_number, fp);
00267                         }
00268                 }
00269
00270         }
00271 }

Here is the call graph for this function:

Here is the caller graph for this function:

void output_blif ( char *  file_name,
netlist_t *  netlist
)

Definition at line 51 of file output_blif.c.

00052 {
00053         int i;
00054         int count = 0;
00055         short first_time_inputs = FALSE;
00056         short first_time_outputs = FALSE;
00057         FILE *out;
00058         char *out_file;
00059
00060         /* open the file for output */
00061         if (global_args.high_level_block != NULL)
00062         {
00063                 out_file = (char*)malloc(sizeof(char)*(1+strlen(file_name)+strlen(global_args.high_level_block)+6));
00064                 sprintf(out_file, "%s_%s.blif", file_name, global_args.high_level_block);
00065                 out = fopen(out_file, "w");
00066         }
00067         else
00068         {
00069                 out = fopen(file_name, "w");
00070         }
00071
00072         if (out == NULL)
00073         {
00074                 error_message(NETLIST_ERROR, -1, -1, "Could not open output file %s\n", file_name);
00075         }
00076
00077         fprintf(out, ".model %s\n", top_module->children[0]->types.identifier);
00078
00079         /* generate all te signals */
00080         for (i = 0; i < netlist->num_top_input_nodes; i++)
00081         {
00082                 if (first_time_inputs == FALSE)
00083                 {
00084                         count = fprintf(out, ".inputs");
00085                         first_time_inputs = TRUE;
00086                 }
00087
00088                 if (global_args.high_level_block != NULL)
00089                 {
00090                         if (strlen(netlist->top_input_nodes[i]->name) + count < 79)
00091                                 count = count + fprintf(out, " %s^^%i-%i", netlist->top_input_nodes[i]->name, netlist->top_input_nodes[i]->related_ast_node->far_tag, netlist->top_input_nodes[i]->related_ast_node->high_number);
00092                         else
00093                         {
00094                                 /* wrapping line */
00095                                 count = fprintf(out, " \\\n %s^^%i-%i", netlist->top_input_nodes[i]->name,netlist->top_input_nodes[i]->related_ast_node->far_tag, netlist->top_input_nodes[i]->related_ast_node->high_number);
00096                                 count = count - 3;
00097                         }
00098                 }
00099                 else
00100                 {
00101                         if (strlen(netlist->top_input_nodes[i]->name) + count < 79)
00102                         {
00103                                 count = count + fprintf(out, " %s", netlist->top_input_nodes[i]->name);
00104                         }
00105                         else
00106                         {
00107                                 /* wrapping line */
00108                                 count = fprintf(out, " \\\n %s", netlist->top_input_nodes[i]->name);
00109                                 count = count - 3;
00110                         }
00111                 }
00112         }
00113         fprintf(out, "\n");
00114
00115         count = 0;
00116         for (i = 0; i < netlist->num_top_output_nodes; i++)
00117         {
00118                 if (netlist->top_output_nodes[i]->input_pins[0]->net->driver_pin == NULL)
00119                 {
00120                         warning_message(NETLIST_ERROR, netlist->top_output_nodes[i]->related_ast_node->line_number, netlist->top_output_nodes[i]->related_ast_node->file_number, "This output is undriven (%s) and will be removed\n", netlist->top_output_nodes[i]->name);
00121                 }
00122                 else
00123                 {
00124                         if (first_time_outputs == FALSE)
00125                         {
00126                                 count = fprintf(out, ".outputs");
00127                                 first_time_outputs = TRUE;
00128                         }
00129
00130                         if (global_args.high_level_block != NULL)
00131                         {
00132                                 if ((strlen(netlist->top_output_nodes[i]->name) + count) < 79)
00133                                         count = count + fprintf(out, " %s^^%i-%i", netlist->top_output_nodes[i]->name,netlist->top_output_nodes[i]->related_ast_node->far_tag, netlist->top_output_nodes[i]->related_ast_node->high_number);
00134                                 else
00135                                 {
00136                                         /* wrapping line */
00137                                         count = fprintf(out, "\\\n %s^^%i-%i", netlist->top_output_nodes[i]->name,netlist->top_output_nodes[i]->related_ast_node->far_tag, netlist->top_output_nodes[i]->related_ast_node->high_number);
00138                                         count = count - 3;
00139                                 }
00140                         }
00141                         else
00142                         {
00143                                 if ((strlen(netlist->top_output_nodes[i]->name) + count) < 79)
00144                                         count = count + fprintf(out, " %s", netlist->top_output_nodes[i]->name);
00145                                 else
00146                                 {
00147                                         /* wrapping line */
00148                                         count = fprintf(out, "\\\n %s", netlist->top_output_nodes[i]->name);
00149                                         count = count - 3;
00150                                 }
00151                         }
00152                 }
00153         }
00154         fprintf(out, "\n");
00155
00156         /* add gnd, unconn, and vcc */
00157         fprintf(out, "\n.names gnd\n.names unconn\n.names vcc\n1\n");
00158         fprintf(out, "\n");
00159
00160         /* traverse the internals of the flat net-list */
00161         if (strcmp(configuration.output_type, "blif") == 0)
00162         {
00163                 depth_first_traversal_to_output(OUTPUT_TRAVERSE_VALUE, out, netlist);
00164         }
00165         else
00166                 oassert(FALSE);
00167
00168         /* connect all the outputs up to the last gate */
00169         for (i = 0; i < netlist->num_top_output_nodes; i++)
00170         {
00171                 /* KEN -- DPRAM WORKING HERE FOR JASON */
00172                 if (netlist->top_output_nodes[i]->input_pins[0]->net->driver_pin != NULL)
00173                 {
00174                         if (global_args.high_level_block != NULL)
00175                         {
00176                                 fprintf(out, ".names %s^^%i-%i %s^^%i-%i\n1 1\n", netlist->top_output_nodes[i]->input_pins[0]->net->driver_pin->node->name,netlist->top_output_nodes[i]->input_pins[0]->net->driver_pin->node->related_ast_node->far_tag, netlist->top_output_nodes[i]->input_pins[0]->net->driver_pin->node->related_ast_node->high_number, netlist->top_output_nodes[i]->name, netlist->top_output_nodes[i]->related_ast_node->far_tag, netlist->top_output_nodes[i]->related_ast_node->high_number);
00177                         }
00178                         else
00179                         {
00180                                 if (netlist->top_output_nodes[i]->input_pins[0]->net->driver_pin->mapping != NULL)
00181                                         fprintf(out, ".names %s %s\n1 1\n", netlist->top_output_nodes[i]->input_pins[0]->net->driver_pin->name, netlist->top_output_nodes[i]->name);
00182                                 else
00183                                         fprintf(out, ".names %s %s\n1 1\n", netlist->top_output_nodes[i]->input_pins[0]->net->driver_pin->node->name, netlist->top_output_nodes[i]->name);
00184                         }
00185
00186                 }
00187         }
00188
00189         /* finish off the top level module */
00190         fprintf(out, ".end\n");
00191         fprintf(out, "\n");
00192
00193         /* Print out any hard block modules */
00194 #ifdef VPR6
00195         add_the_blackbox_for_mults(out);
00196         output_hard_blocks(out);
00197 #endif
00198
00199         fclose(out);
00200 }

Here is the call graph for this function:

Here is the caller graph for this function:

void output_blif_pin_connect ( nnode_t *  node,
FILE *  out
)

Definition at line 700 of file output_blif.c.

00701 {
00702         int i;
00703
00704         /* printout all the port hookups */
00705         for (i = 0; i < node->num_input_pins; i++)
00706         {
00707                 /* Find pins that need to be connected -- KEN */
00708                 if (node->input_pins[i]->net->driver_pin->name != NULL)
00709                         fprintf(out, ".names %s %s\n1 1\n\n", node->input_pins[i]->net->driver_pin->node->name, node->input_pins[i]->net->driver_pin->name);
00710         }
00711
00712         return;
00713 }

Here is the caller graph for this function:

void output_node ( nnode_t *  node,
short  traverse_number,
FILE *  fp
)

Definition at line 276 of file output_blif.c.

00277 {
00278         switch (node->type)
00279         {
00280                 case GT:
00281                         define_set_input_logical_function(node, "100 1\n", fp);
00282                         oassert(node->num_input_pins == 3);
00283                         oassert(node->input_pins[2] != NULL);
00284                         break;
00285                 case LT:
00286                         define_set_input_logical_function(node, "010 1\n", fp); // last input decides if this
00287                         oassert(node->num_input_pins == 3);
00288                         oassert(node->input_pins[2] != NULL);
00289                         break;
00290                 case ADDER_FUNC:
00291                         define_set_input_logical_function(node, "001 1\n010 1\n100 1\n111 1\n", fp);
00292                         break;
00293                 case CARRY_FUNC:
00294                         define_set_input_logical_function(node, "011 1\n100 1\n110 1\n111 1\n", fp);
00295                         break;
00296                 case BITWISE_NOT:
00297                         define_set_input_logical_function(node, "0 1\n", fp);
00298                         break;
00299
00300                 case LOGICAL_AND:
00301                 case LOGICAL_OR:
00302                 case LOGICAL_XOR:
00303                 case LOGICAL_XNOR:
00304                 case LOGICAL_NAND:
00305                 case LOGICAL_NOR:
00306                 case LOGICAL_EQUAL:
00307                 case NOT_EQUAL:
00308                 case LOGICAL_NOT:
00309                         define_logical_function(node, node->type, fp);
00310                         break;
00311
00312                 case MUX_2:
00313                         define_decoded_mux(node, fp);
00314                         break;
00315
00316                 case FF_NODE:
00317                         define_ff(node, fp);
00318                         break;
00319
00320                 case MULTIPLY:
00321                         if (hard_multipliers == NULL)
00322                                 oassert(FALSE); /* should be soft logic! */
00323 #ifdef VPR6
00324                         define_mult_function(node, node->type, fp);
00325 #endif
00326                         break;
00327
00328                 case MEMORY:
00329                 case HARD_IP:
00330 #ifdef VPR6
00331                         define_hard_block(node, node->type, fp);
00332 #endif
00333                         break;
00334
00335                 case INPUT_NODE:
00336                 case OUTPUT_NODE:
00337                 case PAD_NODE:
00338                 case CLOCK_NODE:
00339                 case GND_NODE:
00340                 case VCC_NODE:
00341                         /* some nodes already converted */
00342                         break;
00343
00344                 case BITWISE_AND:
00345                 case BITWISE_NAND:
00346                 case BITWISE_NOR:
00347                 case BITWISE_XNOR:
00348                 case BITWISE_XOR:
00349                 case BITWISE_OR:
00350                 case BUF_NODE:
00351                 case MULTI_PORT_MUX:
00352                 case SL:
00353                 case SR:
00354                 case CASE_EQUAL:
00355                 case CASE_NOT_EQUAL:
00356                 case DIVIDE:
00357                 case MODULO:
00358                 case GTE:
00359                 case LTE:
00360                 case ADD:
00361                 case MINUS:
00362                 default:
00363                         /* these nodes should have been converted to softer versions */
00364                         oassert(FALSE);
00365                         break;
00366         }
00367 }

Here is the call graph for this function:

Here is the caller graph for this function:

Generated on Tue Aug 2 10:43:39 2011 for ODIN_II by  doxygen 1.6.3
