odin_util.c File Reference

#include <string.h>
#include <stdio.h>
#include <stdlib.h>
#include <ctype.h>
#include "types.h"
#include "globals.h"
#include "errors.h"
#include "odin_util.h"

Include dependency graph for odin_util.c:

Go to the source code of this file.

Functions
char *	make_signal_name (char *signal_name, int bit)
char *	make_full_ref_name (char *previous, char *module_name, char *module_instance_name, char *signal_name, int bit)
char *	convert_long_to_bit_string (long long orig_long, int num_bits)
long long	convert_dec_string_of_size_to_long (char *orig_string, int size)
long long	convert_hex_string_of_size_to_long (char *orig_string, int size)
long long	convert_oct_string_of_size_to_long (char *orig_string, int size)
long long	convert_binary_string_of_size_to_long (char *orig_string, int size)
long long int	my_power (long long int x, long long int y)
char *	make_string_based_on_id (nnode_t *node)
char *	make_simple_name (char *input, char *flatten_string, char flatten_char)
void *	my_malloc_struct (int bytes_to_alloc)
long long int	pow2 (int to_the_power)

---

Function Documentation

long long convert_binary_string_of_size_to_long	(	char *	orig_string,
		int	size
	)

Definition at line 248 of file odin_util.c.

{
        int i;
        long long return_value = 0;
        long long current_base_value = 1;
        char temp[2];

        if (strlen(orig_string) > 63)
        {
                /* greater than our bit capacity so not a constant */
                return -1;
        }

        for (i = strlen(orig_string)-1; i > -1; i--)
        {
                if ((tolower(orig_string[i]) == 'x') || (tolower(orig_string[i]) == 'z'))
                {
                        /* this can't be converted to a decimal value */
                        return -1;
                }
                else if (isdigit(orig_string[i]))
                {
                        sprintf(temp, "%c", orig_string[i]);
                        oassert(atoi(temp) < 2);
                        return_value += (long long)(atoi(temp) * current_base_value);
                }
                else
                {
                        error_message(PARSE_ERROR, -1, -1, "This suspected binary number (%s) is not\n", orig_string);
                }
                current_base_value *= 2;
        }

        return return_value;
}

Here is the call graph for this function:

Here is the caller graph for this function:

long long convert_dec_string_of_size_to_long	(	char *	orig_string,
		int	size
	)

Definition at line 124 of file odin_util.c.

{
        int i;
        long long return_value = 0;
        long long current_base_value = 1;
        char temp[2];

        if (strlen(orig_string) > 19)
        {
                /* greater than our bit capacity so not a constant 64 bits */
                return -1;
        }

        for (i = strlen(orig_string)-1; i > -1; i--)
        {
                if (isdigit(orig_string[i]))
                {
                        sprintf(temp, "%c", orig_string[i]);
                        return_value += (long long)(atoi(temp) * current_base_value);
                }
                else
                {
                        error_message(PARSE_ERROR, -1, -1, "This suspected decimal number (%s) is not\n", orig_string);
                }
                current_base_value *= 10;
        }

        return return_value;
}

Here is the call graph for this function:

Here is the caller graph for this function:

long long convert_hex_string_of_size_to_long	(	char *	orig_string,
		int	size
	)

Definition at line 157 of file odin_util.c.

{
        int i;
        long long return_value = 0;
        long long current_base_value = 1;
        char temp[2];

        if (strlen(orig_string) > 16)
        {
                /* greater than our bit capacity so not a constant */
                return -1;
        }

        for (i = strlen(orig_string)-1; i > -1; i--)
        {
                if (isdigit(orig_string[i]))
                {
                        sprintf(temp, "%c", orig_string[i]);
                        return_value += (long long)(atoi(temp) * current_base_value);
                }
                else if ((orig_string[i] == 'a') || (orig_string[i] == 'A'))
                {
                        return_value += (long long)(10 * current_base_value);
                }
                else if ((orig_string[i] == 'b') || (orig_string[i] == 'B'))
                {
                        return_value += (long long)(11 * current_base_value);
                }
                else if ((orig_string[i] == 'c') || (orig_string[i] == 'C'))
                {
                        return_value += (long long)(11 * current_base_value);
                }
                else if ((orig_string[i] == 'd') || (orig_string[i] == 'D'))
                {
                        return_value += (long long)(11 * current_base_value);
                }
                else if ((orig_string[i] == 'e') || (orig_string[i] == 'E'))
                {
                        return_value += (long long)(11 * current_base_value);
                }
                else if ((orig_string[i] == 'f') || (orig_string[i] == 'F'))
                {
                        return_value += (long long)(11 * current_base_value);
                }
                else
                {
                        error_message(PARSE_ERROR, -1, -1, "This suspected hex number (%s) is not\n", orig_string);
                }
                current_base_value *= 16;
        }

        return return_value;
}

Here is the call graph for this function:

Here is the caller graph for this function:

char* convert_long_to_bit_string	(	long long	orig_long,
		int	num_bits
	)

Definition at line 98 of file odin_util.c.

{
        int i;
        char *return_val = (char*)malloc(sizeof(char)*(num_bits+1));
        int mask = 1;

        for (i = num_bits-1; i >= 0; i--)
        {
                if((mask & orig_long) > 0)
                {
                        return_val[i] = '1';
                }
                else
                {
                        return_val[i] = '0';
                }
                mask = mask << 1;
        }
        return_val[num_bits] = '\0';

        return return_val;
}

Here is the caller graph for this function:

long long convert_oct_string_of_size_to_long	(	char *	orig_string,
		int	size
	)

Definition at line 214 of file odin_util.c.

{
        int i;
        long long return_value = 0;
        long long current_base_value = 1;
        char temp[2];

        if (strlen(orig_string) > 21)
        {
                /* greater than our bit capacity so not a constant */
                return -1;
        }

        for (i = strlen(orig_string)-1; i > -1; i--)
        {
                if (isdigit(orig_string[i]))
                {
                        oassert(atoi(temp) < 8);
                        sprintf(temp, "%c", orig_string[i]);
                        return_value += (long long)(atoi(temp) * current_base_value);
                }
                else
                {
                        error_message(PARSE_ERROR, -1, -1, "This suspected oct number (%s) is not\n", orig_string);
                }
                current_base_value *= 8;
        }

        return return_value;
}

Here is the call graph for this function:

Here is the caller graph for this function:

char* make_full_ref_name	(	char *	previous,
		char *	module_name,
		char *	module_instance_name,
		char *	signal_name,
		int	bit
	)

Definition at line 58 of file odin_util.c.

{
        char *return_string;
        return_string = (char*)malloc(sizeof(char)*1);
        return_string[0] = '\0';

        if (previous != NULL)
        {
                return_string = (char*)realloc(return_string, sizeof(char)*(strlen(previous)+1+1));
                sprintf(return_string, "%s", previous);
        }
        if (module_name != NULL)
        {
                return_string = (char*)realloc(return_string, sizeof(char)*(strlen(return_string)+1+strlen(module_name)+1+strlen(module_instance_name)+1));
                sprintf(return_string, "%s.%s+%s", return_string, module_name, module_instance_name);
        }
        if ((signal_name != NULL) && ((previous != NULL) || ((module_name != NULL))))
        {
                return_string = (char*)realloc(return_string, sizeof(char)*(strlen(return_string)+1+strlen(signal_name)+1));
                strcat(return_string, "^");
                strcat(return_string, signal_name);
        }
        else if (signal_name != NULL)
        {
                return_string = (char*)realloc(return_string, sizeof(char)*(strlen(return_string)+1+strlen(signal_name)+1));
                sprintf(return_string, "%s", signal_name);
        }
        if (bit != -1)
        {
                oassert(signal_name != NULL);
                return_string = (char*)realloc(return_string, sizeof(char)*(strlen(return_string)+1+10+1));
                sprintf(return_string, "%s~%d", return_string, bit);
        }
        return return_string;
}

Here is the caller graph for this function:

char* make_signal_name	(	char *	signal_name,
		int	bit
	)

Definition at line 38 of file odin_util.c.

{
        char *return_string;

        oassert(signal_name != NULL);
        if (bit == -1)
                return strdup(signal_name);

        return_string = strdup(signal_name);
        return_string = (char*)realloc(return_string, sizeof(char)*(strlen(return_string)+1+10+1));
        sprintf(return_string, "%s-%d", return_string, bit);
        return return_string;
}

char* make_simple_name	(	char *	input,
		char *	flatten_string,
		char	flatten_char
	)

Definition at line 325 of file odin_util.c.

{
        int i;
        int j;
        char *return_string = NULL;
        oassert(input != NULL);

        return_string = (char*)malloc(sizeof(char)*(strlen(input)+1));

        for (i = 0; i < strlen(input); i++)
        {
                return_string[i] = input[i];
                for (j = 0; j < strlen(flatten_string); j++)
                {
                        if (input[i] == flatten_string[j])
                        {
                                return_string[i] = flatten_char;
                                break;
                        }
                }
        }

        return_string[strlen(input)] = '\0';

        return return_string;
}

Here is the caller graph for this function:

char* make_string_based_on_id

(

nnode_t *

node

)

Definition at line 311 of file odin_util.c.

{
        char *return_string;

        return_string = (char*)malloc(sizeof(char)*(20+2)); // any unique id greater than 20 characters means trouble

        sprintf(return_string, "n%ld", node->unique_id);

        return return_string;
}

void* my_malloc_struct

(

int

bytes_to_alloc

)

Definition at line 355 of file odin_util.c.

{
        void *allocated = NULL;
        static long int m_id = 0;

        // ways to stop the execution at the point when a specific structure is built
        //oassert(m_id != 1777);

        allocated = malloc(bytes_to_alloc);
        if(allocated == NULL)
        {
                fprintf(stderr,"MEMORY FAILURE\n");
                oassert (0);
        }

        /* mark the unique_id */
        *((long int*)allocated) = m_id;

        m_id++;

        return(allocated);
}

Here is the caller graph for this function:

long long int my_power	(	long long int	x,
		long long int	y
	)

Definition at line 288 of file odin_util.c.

{
        int i;
        long long int value;

        if (y == 0)
        {
                return 1;
        }

        value = x;

        for (i = 1; i < y; i++)
        {
                value *= x;
        }

        return value;
}

Here is the caller graph for this function:

long long int pow2

(

int

to_the_power

)

Definition at line 380 of file odin_util.c.

{
        int i;
        long long int return_val = 1;

        for (i = 0; i < to_the_power; i++)
        {
                return_val = return_val << 1;
        }

        return return_val;
}

Here is the caller graph for this function:
