ast_util.h File Reference

#include "types.h"

Include dependency graph for ast_util.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Functions
ast_node_t *	create_node_w_type (ids id, int line_number, int file_number)
void	free_child_in_tree (ast_node_t *from, int idx_removal)
void	free_ast_node (ast_node_t *child)
void	free_ast_node_only (ast_node_t *child)
ast_node_t *	create_tree_node_id (char *string, int line_number, int file_number)
ast_node_t *	create_tree_node_long_long_number (long long number, int line_number, int file_number)
ast_node_t *	create_tree_node_number (char *number, int line_number, int file_number)
void	allocate_children_to_node (ast_node_t *node, int num_children,...)
void	add_child_to_node (ast_node_t *node, ast_node_t *child)
int	get_range (ast_node_t *first_node)
void	make_concat_into_list_of_strings (ast_node_t *concat_top)
char *	get_name_of_pin_at_bit (ast_node_t *var_node, int bit)
char *	get_name_of_var_declare_at_bit (ast_node_t *var_declare, int bit)
char_list_t *	get_name_of_pins (ast_node_t *var_node)
char_list_t *	get_name_of_pins_with_prefix (ast_node_t *var_node, char *instance_name_prefix)

---

Function Documentation

void add_child_to_node	(	ast_node_t *	node,
		ast_node_t *	child
	)

Definition at line 325 of file ast_util.c.

{
        /* allocate space for the children */
        node->children = (ast_node_t**)realloc(node->children, sizeof(ast_node_t*)*(node->num_children+1));
        node->num_children ++;
        node->children[node->num_children-1] = child;
}

Here is the caller graph for this function:

void allocate_children_to_node	(	ast_node_t *	node,
		int	num_children,
			...
	)

Definition at line 304 of file ast_util.c.

{
        va_list ap;
        int i;

        /* allocate space for the children */
        node->children = (ast_node_t**)malloc(sizeof(ast_node_t*)*num_children);
        node->num_children = num_children;

        /* set the virtual arguments */
        va_start(ap, num_children);

        for (i = 0; i < num_children; i++)
        {
                node->children[i] = va_arg(ap, ast_node_t*);
        }
}

Here is the caller graph for this function:

ast_node_t* create_node_w_type	(	ids	id,
		int	line_number,
		int	file_number
	)

Definition at line 41 of file ast_util.c.

{
        static long unique_count = 0;

//      oassert(unique_count != 198);

        ast_node_t* new_node;

        new_node = (ast_node_t*)calloc(1, sizeof(ast_node_t));
        oassert(new_node != NULL);
        new_node->type = id;

        new_node->children = NULL;
        new_node->num_children = 0;

        new_node->line_number = line_number;
        new_node->file_number = file_number;
        new_node->unique_count = unique_count++;

        new_node->far_tag = 0;
        new_node->high_number = 0;

        return new_node;
}

Here is the caller graph for this function:

ast_node_t* create_tree_node_id	(	char *	string,
		int	line_number,
		int	file_number
	)

Definition at line 169 of file ast_util.c.

{
        ast_node_t* new_node = create_node_w_type(IDENTIFIERS, line_number, current_parse_file);
        new_node->types.identifier = string;

        return new_node;
}

Here is the call graph for this function:

Here is the caller graph for this function:

ast_node_t* create_tree_node_long_long_number	(	long long	number,
		int	line_number,
		int	file_number
	)

Definition at line 180 of file ast_util.c.

{
        ast_node_t* new_node = create_node_w_type(NUMBERS, line_number, current_parse_file);
        new_node->types.number.base = LONG_LONG;
        new_node->types.number.value = number;

        return new_node;
}

Here is the call graph for this function:

Here is the caller graph for this function:

ast_node_t* create_tree_node_number	(	char *	number,
		int	line_number,
		int	file_number
	)

Definition at line 192 of file ast_util.c.

{
        ast_node_t* new_node = create_node_w_type(NUMBERS, line_number, current_parse_file);
        char *string_pointer = number;
        int index_string_pointer = 0;
        char *temp_string;
        short flag_constant_decimal = FALSE;

        /* find the ' character if it's a base */
        for (string_pointer=number; *string_pointer; string_pointer++)
        {
                if (*string_pointer == '\'')
                {
                        break;
                }
                index_string_pointer++;
        }

        if (index_string_pointer == strlen(number))
        {
                flag_constant_decimal = TRUE;
                /* this is base d */
                new_node->types.number.base = DEC;
                /* reset to the front */
                string_pointer = number;

                /* size is the rest of the string */
                new_node->types.number.size = strlen((string_pointer));
                /* assign the remainder of the number to a string */
                new_node->types.number.number = strdup((string_pointer));
        }
        else
        {
                /* there is a base in the form: number[bhod]'number */
                switch(tolower(*(string_pointer+1)))
                {
                        case 'd':
                                new_node->types.number.base = DEC;
                                break;
                        case 'h':
                                new_node->types.number.base = HEX;
                                break;
                        case 'o':
                                new_node->types.number.base = OCT;
                                break;
                        case 'b':
                                new_node->types.number.base = BIN;
                                break;
                        default:
                                printf("Not a number\n");
                                oassert(FALSE);
                }

                /* check if the size matches the design specified size */
                temp_string = strdup(number);
                temp_string[index_string_pointer] = '\0';
                /* size is the rest of the string */
                new_node->types.number.size = atoi(temp_string);
                free(temp_string);

                /* move to the digits */
                string_pointer += 2;

                /* assign the remainder of the number to a string */
                new_node->types.number.number = strdup((string_pointer));
        }

        /* check for decimal numbers without the formal 2'd... format */
        if (flag_constant_decimal == FALSE)
        {
                /* size describes how may bits */
                new_node->types.number.binary_size = new_node->types.number.size;
        }
        else
        {
                /* size is for a constant that needs */
                if (strcmp(new_node->types.number.number, "0") != 0)
                {
                        new_node->types.number.binary_size = ceil((log(convert_dec_string_of_size_to_long(new_node->types.number.number, new_node->types.number.size)+1))/log(2));
                }
                else
                {
                        new_node->types.number.binary_size = 1;
                }
        }
        /* add in the values for all the numbers */
        switch (new_node->types.number.base)
        {
                case(DEC):
                        new_node->types.number.value = convert_dec_string_of_size_to_long(new_node->types.number.number, new_node->types.number.size);
                        new_node->types.number.binary_string = convert_long_to_bit_string(new_node->types.number.value, new_node->types.number.binary_size);
                        break;
                case(HEX):
                        new_node->types.number.value = convert_hex_string_of_size_to_long(new_node->types.number.number, strlen(new_node->types.number.number));
                        new_node->types.number.binary_string = convert_long_to_bit_string(new_node->types.number.value, new_node->types.number.binary_size);
                        break;
                case(OCT):
                        new_node->types.number.value = convert_oct_string_of_size_to_long(new_node->types.number.number, strlen(new_node->types.number.number));
                        new_node->types.number.binary_string = convert_long_to_bit_string(new_node->types.number.value, new_node->types.number.binary_size);
                        break;
                case(BIN):
                        new_node->types.number.value = convert_binary_string_of_size_to_long(new_node->types.number.number,  strlen(new_node->types.number.number));// a -1 is in case of x or z's
                        new_node->types.number.binary_string = convert_long_to_bit_string(new_node->types.number.value, new_node->types.number.binary_size);
                        break;
        }

        return new_node;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void free_ast_node

(

ast_node_t *

child

)

Definition at line 108 of file ast_util.c.

{
        int i;

        if ((child == NULL) || (child->shared_node == TRUE))
                return;

        /* free all it's children .... and so on recursively */
        for (i = 0; i < child->num_children; i++)
        {
                free_child_in_tree(child, i);
        }

        if (child->children != NULL)
                free(child->children);

        switch(child->type)
        {
                case IDENTIFIERS:
                        if (child->types.identifier != NULL)
                                free(child->types.identifier);
                        break;
                case NUMBERS:
                        if (child->types.number.number != NULL)
                                free(child->types.number.number);
                        break;
                default:
                        break;
        }

        free(child);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void free_ast_node_only

(

ast_node_t *

child

)

Definition at line 144 of file ast_util.c.

{
        if (child->children != NULL)
                free(child->children);

        switch(child->type)
        {
                case IDENTIFIERS:
                        if (child->types.identifier != NULL)
                                free(child->types.identifier);
                        break;
                case NUMBERS:
                        if (child->types.number.number != NULL)
                                free(child->types.number.number);
                        break;
                default:
                        break;
        }

        free(child);
}

void free_child_in_tree	(	ast_node_t *	from,
		int	idx_removal
	)

Definition at line 70 of file ast_util.c.

{
        ast_node_t *child = from->children[idx_removal];
        int i;

        if ((child == NULL) || (child->shared_node == TRUE))
                return;

        /* free all it's children .... and so on recursively */
        for (i = 0; i < child->num_children; i++)
        {
                free_child_in_tree(child->children[i], i);
        }

        if (child->children != NULL)
                free(child->children);

        switch(child->type)
        {
                case IDENTIFIERS:
                        if (child->types.identifier != NULL)
                                free(child->types.identifier);
                        break;
                case NUMBERS:
                        if (child->types.number.number != NULL)
                                free(child->types.number.number);
                        break;
                default:
                        break;
        }

        free(child);
        from->children[idx_removal] = NULL;
}

Here is the call graph for this function:

Here is the caller graph for this function:

char* get_name_of_pin_at_bit	(	ast_node_t *	var_node,
		int	bit
	)

Definition at line 489 of file ast_util.c.

{
        char *return_string;

        if (var_node->type == ARRAY_REF)
        {
                return_string = make_full_ref_name(NULL, NULL, NULL, var_node->children[0]->types.identifier, (int)var_node->children[1]->types.number.value);
        }
        else if (var_node->type == RANGE_REF)
        {
                oassert((var_node->children[2]->types.number.value+bit <= var_node->children[1]->types.number.value) && (var_node->children[2]->types.number.value+bit >= var_node->children[2]->types.number.value));
                return_string = make_full_ref_name(NULL, NULL, NULL, var_node->children[0]->types.identifier, var_node->children[2]->types.number.value+bit);
        }
        else if ((var_node->type == IDENTIFIERS) && (bit == -1))
        {
                return_string = make_full_ref_name(NULL, NULL, NULL, var_node->types.identifier, -1);
        }
        else if (var_node->type == IDENTIFIERS)
        {
                long sc_spot;
                int pin_index;

                if ((sc_spot = sc_lookup_string(local_symbol_table_sc, var_node->types.identifier)) == -1)
                {
                        error_message(NETLIST_ERROR, var_node->line_number, var_node->file_number, "Missing declaration of this symbol %s\n", var_node->types.identifier);
                }

                if (((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[1] == NULL)
                {
                        pin_index = bit;
                }
                else if (((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[3] == NULL)
                {
                        pin_index = ((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[2]->types.number.value + bit;
                }
                else
                        oassert(FALSE);

                return_string = make_full_ref_name(NULL, NULL, NULL, var_node->types.identifier, pin_index);
        }
        else if (var_node->type == NUMBERS)
        {
                if (bit == -1)
                        bit = 0;

                oassert(bit < var_node->types.number.binary_size);
                if (var_node->types.number.binary_string[var_node->types.number.binary_size-bit-1] == '1')
                {
                        return_string = (char*)malloc(sizeof(char)*11+1); // ONE_VCC_CNS
                        sprintf(return_string, "ONE_VCC_CNS");
                }
                else if (var_node->types.number.binary_string[var_node->types.number.binary_size-bit-1] == '0')
                {
                        return_string = (char*)malloc(sizeof(char)*13+1); // ZERO_GND_ZERO
                        sprintf(return_string, "ZERO_GND_ZERO");
                }
                else
                {
                        oassert(FALSE);
                }
        }
        else if (var_node->type == CONCATENATE)
        {
                if (var_node->types.concat.num_bit_strings == 0)
                {
                        oassert(FALSE);
                }
                else
                {
                        if (var_node->types.concat.num_bit_strings == -1)
                        {
                                /* If this hasn't been made into a string list then do it */
                                make_concat_into_list_of_strings(var_node);
                        }

                        return_string = (char*)malloc(sizeof(char)*strlen(var_node->types.concat.bit_strings[bit])+1);
                        sprintf(return_string, "%s", var_node->types.concat.bit_strings[bit]);
                }
        }
        else
        {
                oassert(FALSE);
        }

        return return_string;
}

Here is the call graph for this function:

Here is the caller graph for this function:

char_list_t* get_name_of_pins

(

ast_node_t *

var_node

)

Definition at line 581 of file ast_util.c.

{
        char **return_string;
        char_list_t *return_list = (char_list_t*)malloc(sizeof(char_list_t));

        int i;
        int width;

        if (var_node->type == ARRAY_REF)
        {
                width = 1;
                return_string = (char**)malloc(sizeof(char*));
                return_string[0] = make_full_ref_name(NULL, NULL, NULL, var_node->children[0]->types.identifier, (int)var_node->children[1]->types.number.value);
        }
        else if (var_node->type == RANGE_REF)
        {
                width = (var_node->children[1]->types.number.value - var_node->children[2]->types.number.value+1);
                return_string = (char**)malloc(sizeof(char*)*width);
                for (i = 0; i < width; i++)
                {
                        return_string[i] = make_full_ref_name(NULL, NULL, NULL, var_node->children[0]->types.identifier, var_node->children[2]->types.number.value+i);
                }
        }
        else if (var_node->type == IDENTIFIERS)
        {
                /* need to look in the symbol table for details about this identifier (i.e. is it a port) */
                long sc_spot;
                char *temp_string = make_full_ref_name(NULL, NULL, NULL, var_node->types.identifier, -1);

                if ((sc_spot = sc_lookup_string(local_symbol_table_sc, temp_string)) == -1)
                {
                        error_message(NETLIST_ERROR, var_node->line_number, var_node->file_number, "Missing declaration of this symbol %s\n", temp_string);
                }
                free(temp_string);

                if (((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[1] == NULL)
                {
                        width = 1;
                        return_string = (char**)malloc(sizeof(char*)*width);
                        return_string[0] = make_full_ref_name(NULL, NULL, NULL, var_node->types.identifier, -1);
                }
                else if (((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[3] == NULL)
                {
                        int index = 0;
                        width = ((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[1]->types.number.value - ((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[2]->types.number.value + 1;
                        return_string = (char**)malloc(sizeof(char*)*width);
                        for (i = 0; i < width; i++)
//                      for (i = 0; i < ((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[2]->types.number.value; i < ((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[1]->types.number.value+1; i++)
                        {
                                return_string[index] = make_full_ref_name(NULL, NULL, NULL, var_node->types.identifier, i+((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[2]->types.number.value);
                                index++;
                        }
                }
                else if (((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[3] != NULL)
                {
                        oassert(FALSE);
                }
        }
        else if (var_node->type == NUMBERS)
        {
                width = var_node->types.number.binary_size;
                return_string = (char**)malloc(sizeof(char*)*width);
                for (i = 0; i < width; i++)
                {
                        /* strings are msb is 0th index in string, reverse access */
                        if (var_node->types.number.binary_string[var_node->types.number.binary_size-i-1] == '1')
                        {
                                return_string[i] = (char*)malloc(sizeof(char)*11+1); // ONE_VCC_CNS
                                sprintf(return_string[i], "ONE_VCC_CNS");
                        }
                        else if (var_node->types.number.binary_string[var_node->types.number.binary_size-i-1] == '0')
                        {
                                return_string[i] = (char*)malloc(sizeof(char)*13+1); // ZERO_GND_ZERO
                                sprintf(return_string[i], "ZERO_GND_ZERO");
                        }
                        else
                        {
                                oassert(FALSE);
                        }
                }
        }
        else if (var_node->type == CONCATENATE)
        {
                if (var_node->types.concat.num_bit_strings == 0)
                {
                        oassert(FALSE);
                }
                else
                {
                        if (var_node->types.concat.num_bit_strings == -1)
                        {
                                /* If this hasn't been made into a string list then do it */
                                make_concat_into_list_of_strings(var_node);
                        }

                        width = var_node->types.concat.num_bit_strings;
                        return_string = (char**)malloc(sizeof(char*)*width);
                        for (i = 0; i < width; i++) // 0th bit is MSB so need to access reverse
                        {
                                return_string[i] = (char*)malloc(sizeof(char)*strlen(var_node->types.concat.bit_strings[var_node->types.concat.num_bit_strings-i-1])+1);
                                sprintf(return_string[i], "%s", var_node->types.concat.bit_strings[var_node->types.concat.num_bit_strings-i-1]);
                        }
                }
        }
        else
        {
                oassert(FALSE);
        }

        return_list->strings = return_string;
        return_list->num_strings = width;

        return return_list;
}

Here is the call graph for this function:

Here is the caller graph for this function:

char_list_t* get_name_of_pins_with_prefix	(	ast_node_t *	var_node,
		char *	instance_name_prefix
	)

Definition at line 699 of file ast_util.c.

{
        int i;
        char_list_t *return_list;

        /* get the list */
        return_list = get_name_of_pins(var_node);

        for (i = 0; i < return_list->num_strings; i++)
        {
                return_list->strings[i] = make_full_ref_name(instance_name_prefix, NULL, NULL, return_list->strings[i], -1);
        }

        return return_list;
}

Here is the call graph for this function:

Here is the caller graph for this function:

char* get_name_of_var_declare_at_bit	(	ast_node_t *	var_declare,
		int	bit
	)

Definition at line 462 of file ast_util.c.

{
        char *return_string;

        /* calculate the port details */
        if (var_declare->children[1] == NULL)
        {
                oassert(bit == 0);
                return_string = make_full_ref_name(NULL, NULL, NULL, var_declare->children[0]->types.identifier, -1);
        }
        else if (var_declare->children[3] == NULL)
        {
                return_string = make_full_ref_name(NULL, NULL, NULL, var_declare->children[0]->types.identifier, var_declare->children[2]->types.number.value+bit);
        }
        else if (var_declare->children[3] != NULL)
        {
                /* MEMORY output */
                oassert(FALSE);
        }

        return return_string;
}

Here is the call graph for this function:

Here is the caller graph for this function:

int get_range

(

ast_node_t *

first_node

)

Definition at line 336 of file ast_util.c.

{
        long temp_value;
        /* look at the first item to see if it has a range */
        if (first_node->children[1] != NULL)
        {
                /* IF the first element in the list has a second element...that is the range */
                oassert(first_node->children[2] != NULL); // the third element should be a value
                oassert((first_node->children[1]->type == NUMBERS) && (first_node->children[2]->type == NUMBERS)); // should be numbers
                if(first_node->children[1]->types.number.value < first_node->children[2]->types.number.value)
                {
                        /* swap them around */
                        temp_value = first_node->children[1]->types.number.value;
                        first_node->children[1]->types.number.value = first_node->children[2]->types.number.value;
                        first_node->children[2]->types.number.value = temp_value;
                }

                return abs(first_node->children[1]->types.number.value - first_node->children[2]->types.number.value + 1); // 1:0 is 2 spots
        }
        return -1; // indicates no range
}

Here is the caller graph for this function:

void make_concat_into_list_of_strings

(

ast_node_t *

concat_top

)

Definition at line 362 of file ast_util.c.

{
        int i, j;

        concat_top->types.concat.num_bit_strings = 0;
        concat_top->types.concat.bit_strings = NULL;

        /* recursively do all embedded concats */
        for (i = 0; i < concat_top->num_children; i++)
        {
                if (concat_top->children[i]->type == CONCATENATE)
                {
                        make_concat_into_list_of_strings(concat_top->children[i]);
                }
        }

        for (i = 0; i < concat_top->num_children; i++)
        {
                if (concat_top->children[i]->type == IDENTIFIERS)
                {
                        char *temp_string = make_full_ref_name(NULL, NULL, NULL, concat_top->children[i]->types.identifier, -1);
                        long sc_spot;

                        if ((sc_spot = sc_lookup_string(local_symbol_table_sc, temp_string)) == -1)
                        {
                                error_message(NETLIST_ERROR, concat_top->line_number, concat_top->file_number, "Missing declaration of this symbol %s\n", temp_string);
                        }
                        free(temp_string);

                        if (((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[1] == NULL)
                        {
                                concat_top->types.concat.num_bit_strings ++;
                                concat_top->types.concat.bit_strings = (char**)realloc(concat_top->types.concat.bit_strings, sizeof(char*)*(concat_top->types.concat.num_bit_strings));
                                concat_top->types.concat.bit_strings[concat_top->types.concat.num_bit_strings-1] = get_name_of_pin_at_bit(concat_top->children[i], -1);
                        }
                        else if (((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[3] == NULL)
                        {
                                /* reverse thorugh the range since highest bit in index will be lower in the string indx */
                                for (j = ((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[1]->types.number.value - ((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[2]->types.number.value; j >= 0; j--)
                                {
                                        concat_top->types.concat.num_bit_strings ++;
                                        concat_top->types.concat.bit_strings = (char**)realloc(concat_top->types.concat.bit_strings, sizeof(char*)*(concat_top->types.concat.num_bit_strings));
                                        concat_top->types.concat.bit_strings[concat_top->types.concat.num_bit_strings-1] = get_name_of_pin_at_bit(concat_top->children[i], j);
                                }
                        }
                        else if (((ast_node_t*)local_symbol_table_sc->data[sc_spot])->children[3] != NULL)
                        {
                                oassert(FALSE);
                        }

                }
                else if (concat_top->children[i]->type == ARRAY_REF)
                {
                        concat_top->types.concat.num_bit_strings ++;
                        concat_top->types.concat.bit_strings = (char**)realloc(concat_top->types.concat.bit_strings, sizeof(char*)*(concat_top->types.concat.num_bit_strings));
                        concat_top->types.concat.bit_strings[concat_top->types.concat.num_bit_strings-1] = get_name_of_pin_at_bit(concat_top->children[i], 0);
                }
                else if (concat_top->children[i]->type == RANGE_REF)
                {
                        oassert(concat_top->children[i]->children[1]->types.number.value >= concat_top->children[i]->children[2]->types.number.value);
                        /* reverse thorugh the range since highest bit in index will be lower in the string indx */
                        for (j = concat_top->children[i]->children[1]->types.number.value - concat_top->children[i]->children[2]->types.number.value; j >= 0; j--)
                        {
                                concat_top->types.concat.num_bit_strings ++;
                                concat_top->types.concat.bit_strings = (char**)realloc(concat_top->types.concat.bit_strings, sizeof(char*)*(concat_top->types.concat.num_bit_strings));
                                concat_top->types.concat.bit_strings[concat_top->types.concat.num_bit_strings-1] = get_name_of_pin_at_bit(concat_top->children[i], ((concat_top->children[i]->children[1]->types.number.value - concat_top->children[i]->children[2]->types.number.value))-j);
                        }
                }
                else if (concat_top->children[i]->type == NUMBERS)
                {
                        if(concat_top->children[i]->types.number.base == DEC)
                        {
                                error_message(NETLIST_ERROR, concat_top->line_number, concat_top->file_number, "Concatenation can't include decimal numbers due to conflict on bits\n");
                        }

                        /* forward through list since 0th bit of a number (get_name_of_pin) is the msb */
                        for (j = 0; j < concat_top->children[i]->types.number.binary_size; j++)
                        {
                                concat_top->types.concat.num_bit_strings ++;
                                concat_top->types.concat.bit_strings = (char**)realloc(concat_top->types.concat.bit_strings, sizeof(char*)*(concat_top->types.concat.num_bit_strings));
                                concat_top->types.concat.bit_strings[concat_top->types.concat.num_bit_strings-1] = get_name_of_pin_at_bit(concat_top->children[i], j);
                        }
                }
                else if (concat_top->children[i]->type == CONCATENATE)
                {
                        /* forward through list since we build concatenate list in idx order of MSB at index 0 and LSB at index list_size */
                        for (j = 0; j < concat_top->children[i]->types.concat.num_bit_strings; j++)
                        {
                                concat_top->types.concat.num_bit_strings ++;
                                concat_top->types.concat.bit_strings = (char**)realloc(concat_top->types.concat.bit_strings, sizeof(char*)*(concat_top->types.concat.num_bit_strings));
                                concat_top->types.concat.bit_strings[concat_top->types.concat.num_bit_strings-1] = get_name_of_pin_at_bit(concat_top->children[i], j);
                        }
                }
        }
}

Here is the call graph for this function:

Here is the caller graph for this function:
