SRC/place_stats.c File Reference

#include <stdio.h>
#include <math.h>
#include "util.h"
#include "vpr_types.h"
#include "globals.h"

Include dependency graph for place_stats.c:

Go to the source code of this file.

Data Structures
struct	relapos_rec_s
Defines
#define	ABS_DIFF(X, Y)   (((X) > (Y))? ((X) - (Y)):((Y) - (X)))
#define	MAX_X   50
#define	MAX_LEN   MAX_X*2
Typedefs
typedef struct relapos_rec_s	relapos_rec_t
Functions
void	print_relative_pos_distr (void)

---

Define Documentation

#define ABS_DIFF	(	X,
		Y		)	(((X) > (Y))? ((X) - (Y)):((Y) - (X)))

Definition at line 7 of file place_stats.c.

#define MAX_LEN   MAX_X*2

Definition at line 9 of file place_stats.c.

#define MAX_X   50

Definition at line 8 of file place_stats.c.

---

Typedef Documentation

typedef struct relapos_rec_s relapos_rec_t

---

Function Documentation

void print_relative_pos_distr

(

void

)

Definition at line 18 of file place_stats.c.

{

/* Prints out the probability distribution of the relative locations of *
 * input pins on a net -- i.e. simulates 2-point net distance probability *
 * distribution.                                                        */
#ifdef PRINT_REL_POS_DISTR
    FILE *out_bin_file;
    relapos_rec_t rp_rec;
#endif /* PRINT_REL_POS_DISTR */

    int inet, len, rp, src_x, src_y, dst_x, dst_y, del_x, del_y, min_del,
        sink_pin, sum;
    int *total_conn;
    int **relapos;
    double **relapos_distr;

    total_conn = (int *)my_malloc((nx + ny + 1) * sizeof(int));
    relapos = (int **)my_malloc((nx + ny + 1) * sizeof(int *));
    relapos_distr = (double **)my_malloc((nx + ny + 1) * sizeof(double *));
    for(len = 0; len <= nx + ny; len++)
        {
            relapos[len] = (int *)my_calloc(len / 2 + 1, sizeof(int));
            relapos_distr[len] =
                (double *)my_calloc((len / 2 + 1), sizeof(double));
        }


    for(inet = 0; inet < num_nets; inet++)
        {
            if(net[inet].is_global == FALSE)
                {

                    src_x = block[net[inet].node_block[0]].x;
                    src_y = block[net[inet].node_block[0]].y;

                    for(sink_pin = 1; sink_pin <= net[inet].num_sinks;
                        sink_pin++)
                        {
                            dst_x = block[net[inet].node_block[sink_pin]].x;
                            dst_y = block[net[inet].node_block[sink_pin]].y;

                            del_x = ABS_DIFF(dst_x, src_x);
                            del_y = ABS_DIFF(dst_y, src_y);

                            len = del_x + del_y;

                            min_del = (del_x < del_y) ? del_x : del_y;

                            if(!(min_del <= (len / 2)))
                                {
                                    printf
                                        ("Error in calculating relative location min_del = %d, len = %d\n",
                                         min_del, len);
                                    exit(1);
                                }
                            else
                                {
                                    relapos[len][min_del]++;
                                }
                        }
                }
        }

#ifdef PRINT_REL_POS_DISTR
    out_bin_file =
        fopen("/jayar/b/b5/fang/vpr_test/wirelength/relapos2.bin", "rb+");
#endif /* PRINT_REL_POS_DISTR */

    for(len = 0; len <= nx + ny; len++)
        {
            sum = 0;
            for(rp = 0; rp <= len / 2; rp++)
                {
                    sum += relapos[len][rp];
                }
            if(sum != 0)
                {
#ifdef PRINT_REL_POS_DISTR
                    fseek(out_bin_file, sizeof(relapos_rec_t) * len,
                          SEEK_SET);
                    fread(&rp_rec, sizeof(relapos_rec_t), 1, out_bin_file);
#endif /* PRINT_REL_POS_DISTR */

                    for(rp = 0; rp <= len / 2; rp++)
                        {

                            relapos_distr[len][rp] =
                                (double)relapos[len][rp] / (double)sum;

                            /* updating the binary record at "len" */
#ifdef PRINT_REL_POS_DISTR
                            fprintf(stderr, "old %d increase by %d\n",
                                    rp_rec.num_rp[rp], relapos[len][rp]);
                            rp_rec.num_rp[rp] += relapos[len][rp];
                            fprintf(stderr, "becomes %d\n",
                                    rp_rec.num_rp[rp]);
#endif /* PRINT_REL_POS_DISTR */
                        }
#ifdef PRINT_REL_POS_DISTR
                    /* write back the updated record at "len" */
                    fseek(out_bin_file, sizeof(relapos_rec_t) * len,
                          SEEK_SET);
                    fwrite(&rp_rec, sizeof(relapos_rec_t), 1, out_bin_file);
#endif /* PRINT_REL_POS_DISTR */

                }
            total_conn[len] = sum;
        }

    fprintf(stdout, "Source to sink relative positions:\n");
    for(len = 1; len <= nx + ny; len++)
        {
            if(total_conn[len] != 0)
                {
                    fprintf(stdout, "Of 2-pin distance %d exists %d\n\n", len,
                            total_conn[len]);
                    for(rp = 0; rp <= len / 2; rp++)
                        {
                            fprintf(stdout, "\trp%d\t%d\t\t(%.5f)\n", rp,
                                    relapos[len][rp], relapos_distr[len][rp]);
                        }
                    fprintf(stdout, "----------------\n");
                }
        }

    free((void *)total_conn);
    for(len = 0; len <= nx + ny; len++)
        {
            free((void *)relapos[len]);
            free((void *)relapos_distr[len]);
        }
    free((void *)relapos);
    free((void *)relapos_distr);

#ifdef PRINT_REL_POS_DISTR
    fclose(out_bin_file);
#endif /* PRINT_REL_POS_DISTR */
}

Here is the call graph for this function:

Here is the caller graph for this function:
