SRC/CheckSetup.c File Reference

#include "util.h"
#include "vpr_types.h"
#include "globals.h"
#include "OptionTokens.h"
#include "ReadOptions.h"
#include "xml_arch.h"
#include "SetupVPR.h"

Include dependency graph for CheckSetup.c:

Go to the source code of this file.

Functions
void	CheckSetup (IN enum e_operation Operation, IN struct s_placer_opts PlacerOpts, IN struct s_annealing_sched AnnealSched, IN struct s_router_opts RouterOpts, IN struct s_det_routing_arch RoutingArch, IN t_segment_inf *Segments, IN t_timing_inf Timing, IN t_subblock_data Subblocks, IN t_chan_width_dist Chans)

---

Function Documentation

void CheckSetup	(	IN enum e_operation	Operation,
		IN struct s_placer_opts	PlacerOpts,
		IN struct s_annealing_sched	AnnealSched,
		IN struct s_router_opts	RouterOpts,
		IN struct s_det_routing_arch	RoutingArch,
		IN t_segment_inf *	Segments,
		IN t_timing_inf	Timing,
		IN t_subblock_data	Subblocks,
		IN t_chan_width_dist	Chans
	)

Definition at line 11 of file CheckSetup.c.

{
    int i;
    int Tmp;

    if((NONLINEAR_CONG == PlacerOpts.place_cost_type) &&
       (Operation != PLACE_AND_ROUTE) &&
       (PLACE_ALWAYS == PlacerOpts.place_freq))
        {
            printf(ERRTAG "Replacing using the nonlinear congestion option "
                   "for each channel width makes sense only for full "
                   "place and route.\n");
            exit(1);
        }

    if((NONLINEAR_CONG == PlacerOpts.place_cost_type) &&
       (BOUNDING_BOX_PLACE != PlacerOpts.place_algorithm))
        {

            /* Note that this may work together, but I have not tested it */
            printf(ERRTAG
                   "Cannot use non-linear placement only supported with "
                   "bounding box placement\n");
            exit(1);
        }

    if((GLOBAL == RouterOpts.route_type) &&
       (TIMING_DRIVEN == RouterOpts.router_algorithm))
        {

            printf(ERRTAG "The global router does not support timing-drvien "
                   "routing.\n");
            exit(1);
        }

    if((GLOBAL == RouterOpts.route_type) &&
       (BOUNDING_BOX_PLACE != PlacerOpts.place_algorithm))
        {

            /* Works, but very weird.  Can't optimize timing well, since you're
             * not doing proper architecture delay modelling. */
            printf(WARNTAG
                   "Using global routing with timing-driven placement. "
                   "This is allowed, but strange, and circuit speed will suffer.\n");
        }

    if((FALSE == Timing.timing_analysis_enabled) &&
       ((PlacerOpts.place_algorithm == NET_TIMING_DRIVEN_PLACE) ||
        (PlacerOpts.place_algorithm == PATH_TIMING_DRIVEN_PLACE)))
        {

            /* May work, not tested */
            printf(ERRTAG
                   "Timing analysis must be enabled for timing-driven placement\n");
            exit(1);
        }

    if((ROUTE_ONLY == Operation) && (USER == PlacerOpts.pad_loc_type))
        {
            printf(ERRTAG "You cannot specify both a full placement file and "
                   "a pad location file.\n");
            exit(1);
        }

    if((ROUTE_ONLY == Operation) || (PLACE_AND_ROUTE == Operation))
        {
            if((TIMING_DRIVEN == RouterOpts.router_algorithm) &&
               (FALSE == Timing.timing_analysis_enabled))
                {
                    printf(ERRTAG
                           "Cannot perform timing-driven routing when timing "
                           "analysis is disabled.\n");
                    exit(1);
                }

            if((FALSE == Timing.timing_analysis_enabled) &&
               (DEMAND_ONLY != RouterOpts.base_cost_type))
                {
                    printf(ERRTAG
                           "base_cost_type must be demand_only when timing "
                           "analysis is disabled.\n");
                    exit(1);
                }
        }

    if((TIMING_ANALYSIS_ONLY == Operation) &&
       (FALSE == Timing.timing_analysis_enabled))
        {
            printf(ERRTAG
                   "-timing_analyze_only_with_net_delay option requires "
                   "that timing analysis not be disabled.\n");
            exit(1);
        }

    if((NONLINEAR_CONG == PlacerOpts.place_cost_type) &&
       ((PlacerOpts.num_regions > nx) || (PlacerOpts.num_regions > ny)))
        {
            printf(ERRTAG "Cannot use more regions than clbs in "
                   "placement cost function.\n");
            exit(1);
        }

    if(DETAILED == RouterOpts.route_type)
        {
            if((Chans.chan_x_dist.type != UNIFORM) ||
               (Chans.chan_y_dist.type != UNIFORM) ||
               (Chans.chan_x_dist.peak != Chans.chan_y_dist.peak) ||
               (Chans.chan_x_dist.peak != Chans.chan_width_io))
                {
                    printf(ERRTAG "Detailed routing currently only supported "
                           "on FPGAs with all channels of equal width.\n");
                    exit(1);
                }
        }

    for(i = 0; i < RoutingArch.num_segment; ++i)
        {
            Tmp = Segments[i].opin_switch;
            if(FALSE == switch_inf[Tmp].buffered)
                {
                    printf(ERRTAG "opin_switch (#%d) of segment type #%d "
                           "is not buffered.\n", Tmp, i);
                    exit(1);
                }
        }

    if(UNI_DIRECTIONAL == RoutingArch.directionality)
        {
            if((RouterOpts.fixed_channel_width != NO_FIXED_CHANNEL_WIDTH) &&
               (RouterOpts.fixed_channel_width % 2 > 0))
                {
                    printf(ERRTAG
                           "Routing channel width must be even for unidirectional\n");
                    exit(1);
                }
            if((PlacerOpts.place_chan_width != NO_FIXED_CHANNEL_WIDTH) &&
               (PlacerOpts.place_chan_width % 2 > 0))
                {
                    printf(ERRTAG
                           "Place channel width must be even for unidirectional\n");
                    exit(1);
                }
        }
}

Here is the caller graph for this function:
