SRC/ReadOptions.c File Reference

#include <stdio.h>
#include <string.h>
#include <assert.h>
#include "util.h"
#include "vpr_types.h"
#include "OptionTokens.h"
#include "ReadOptions.h"

Include dependency graph for ReadOptions.c:

Go to the source code of this file.

Functions
static const char *const *	ReadBaseToken (IN const char *const *Args, OUT enum e_OptionBaseToken *Token)
static void	Error (IN const char *Token)
static void	ErrorOption (IN const char *Option)
static const char *const *	ProcessOption (IN const char *const *Args, INOUT t_options *Options)
static const char *const *	ReadFloat (IN const char *const *Args, OUT float *Val)
static const char *const *	ReadInt (IN const char *const *Args, OUT int *Val)
static const char *const *	ReadOnOff (IN const char *const *Args, OUT boolean *Val)
static const char *const *	ReadFixPins (IN const char *const *Args, OUT char **PinFile)
static const char *const *	ReadPlaceAlgorithm (IN const char *const *Args, OUT enum e_place_algorithm *Algo)
static const char *const *	ReadPlaceCostType (IN const char *const *Args, OUT enum place_c_types *Type)
static const char *const *	ReadRouterAlgorithm (IN const char *const *Args, OUT enum e_router_algorithm *Algo)
static const char *const *	ReadBaseCostType (IN const char *const *Args, OUT enum e_base_cost_type *BaseCostType)
static const char *const *	ReadRouteType (IN const char *const *Args, OUT enum e_route_type *Type)
static const char *const *	ReadString (IN const char *const *Args, OUT char **Val)
void	ReadOptions (IN int argc, IN char **argv, OUT t_options *Options)
static const char *const *	ReadToken (IN const char *const *Args, OUT enum e_OptionArgToken *Token)

---

Function Documentation

static void Error

(

IN const char *

Token

)

[static]

Definition at line 282 of file ReadOptions.c.

{
    if(Token)
        {
            printf(ERRTAG "Unexpected token '%s' on command line\n", Token);
        }
    else
        {
            printf(ERRTAG "Missing token at end of command line\n");
        }
    exit(1);
}

Here is the caller graph for this function:

static void ErrorOption

(

IN const char *

Option

)

[static]

Definition at line 297 of file ReadOptions.c.

{
    printf(ERRTAG "Unexpected option '%s' on command line\n", Option);
    exit(1);
}

Here is the caller graph for this function:

static const char *const * ProcessOption	(	IN const char *const *	Args,
		INOUT t_options *	Options
	)			[static]

Definition at line 112 of file ReadOptions.c.

{
    enum e_OptionBaseToken Token;
    const char *const *PrevArgs;

    PrevArgs = Args;
    Args = ReadBaseToken(Args, &Token);

    if(Token < OT_BASE_UNKNOWN)
        {
            ++Options->Count[Token];
        }

    switch (Token)
        {
        /* General Options */
    case OT_NODISP:
                return Args;
        case OT_AUTO:
            return ReadInt(Args, &Options->GraphPause);
        case OT_ROUTE_ONLY:
        case OT_PLACE_ONLY:
            return Args;
        case OT_TIMING_ANALYZE_ONLY_WITH_NET_DELAY:
                return ReadFloat(Args, &Options->constant_net_delay);
        case OT_FAST:
        case OT_FULL_STATS:
            return Args;
        case OT_TIMING_ANALYSIS:
            return ReadOnOff(Args, &Options->TimingAnalysis);
        case OT_OUTFILE_PREFIX:
            return ReadString(Args, &Options->OutFilePrefix);

        /* Placer Options */
        case OT_PLACE_ALGORITHM:
            return ReadPlaceAlgorithm(Args, &Options->PlaceAlgorithm);
        case OT_INIT_T:
            return ReadFloat(Args, &Options->PlaceInitT);
        case OT_EXIT_T:
            return ReadFloat(Args, &Options->PlaceExitT);
        case OT_ALPHA_T:
            return ReadFloat(Args, &Options->PlaceAlphaT);
        case OT_INNER_NUM:
            return ReadFloat(Args, &Options->PlaceInnerNum);
        case OT_SEED:
            return ReadInt(Args, &Options->Seed);
        case OT_PLACE_COST_EXP:
                return ReadFloat(Args, &Options->place_cost_exp);
        case OT_PLACE_COST_TYPE:
            return ReadPlaceCostType(Args, &Options->PlaceCostType);
        case OT_PLACE_CHAN_WIDTH:
            return ReadInt(Args, &Options->PlaceChanWidth);
        case OT_NUM_REGIONS:
            return ReadInt(Args, &Options->PlaceNonlinearRegions);
        case OT_FIX_PINS:
            return ReadFixPins(Args, &Options->PinFile);
        case OT_ENABLE_TIMING_COMPUTATIONS:
                return ReadOnOff(Args, &Options->ShowPlaceTiming);
        case OT_BLOCK_DIST:
                return ReadInt(Args, &Options->block_dist);

        /* Placement Options Valid Only for Timing-Driven Placement */
        case OT_TIMING_TRADEOFF:
            return ReadFloat(Args, &Options->PlaceTimingTradeoff);
        case OT_RECOMPUTE_CRIT_ITER:
            return ReadInt(Args, &Options->RecomputeCritIter);
        case OT_INNER_LOOP_RECOMPUTE_DIVIDER:
                return ReadInt(Args, &Options->inner_loop_recompute_divider);
        case OT_TD_PLACE_EXP_FIRST:
                return ReadFloat(Args, &Options->place_exp_first);
        case OT_TD_PLACE_EXP_LAST:
                return ReadFloat(Args, &Options->place_exp_last);

        /* Router Options */
        case OT_MAX_ROUTER_ITERATIONS:
                return ReadInt(Args, &Options->max_router_iterations);
        case OT_BB_FACTOR:
                return ReadInt(Args, &Options->bb_factor);
        case OT_INITIAL_PRES_FAC:
                return ReadFloat(Args, &Options->initial_pres_fac);
        case OT_PRES_FAC_MULT:
                return ReadFloat(Args, &Options->pres_fac_mult);
        case OT_ACC_FAC:
                return ReadFloat(Args, &Options->acc_fac);
        case OT_FIRST_ITER_PRES_FAC:
                return ReadFloat(Args, &Options->first_iter_pres_fac);
        case OT_BEND_COST:
                return ReadFloat(Args, &Options->bend_cost);
        case OT_ROUTE_TYPE:
            return ReadRouteType(Args, &Options->RouteType);
        case OT_VERIFY_BINARY_SEARCH:
                return Args;
        case OT_ROUTE_CHAN_WIDTH:
            return ReadInt(Args, &Options->RouteChanWidth);
        case OT_ROUTER_ALGORITHM:
            return ReadRouterAlgorithm(Args, &Options->RouterAlgorithm);
        case OT_BASE_COST_TYPE:
                return ReadBaseCostType(Args, &Options->base_cost_type);

        /* Routing options valid only for timing-driven routing */
        case OT_ASTAR_FAC:
                return ReadFloat(Args, &Options->astar_fac);
        case OT_MAX_CRITICALITY:
                return ReadFloat(Args, &Options->max_criticality);
        case OT_CRITICALITY_EXP:
                return ReadFloat(Args, &Options->criticality_exp);
        default:
            ErrorOption(*PrevArgs);
        }
    return NULL;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadBaseCostType	(	IN const char *const *	Args,
		OUT enum e_base_cost_type *	BaseCostType
	)			[static]

Definition at line 332 of file ReadOptions.c.

{
    enum e_OptionArgToken Token;
    const char *const *PrevArgs;

    PrevArgs = Args;
    Args = ReadToken(Args, &Token);
    switch (Token)
        {
        case OT_INTRINSIC_DELAY:
            *BaseCostType = INTRINSIC_DELAY;
            break;
        case OT_DELAY_NORMALIZED:
            *BaseCostType = DELAY_NORMALIZED;
            break;
        case OT_DEMAND_ONLY:
            *BaseCostType = DEMAND_ONLY;
            break;
        default:
            Error(*PrevArgs);
        }

    return Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadBaseToken	(	IN const char *const *	Args,
		OUT enum e_OptionBaseToken *	Token
	)			[static]

Definition at line 227 of file ReadOptions.c.

{
    const struct s_TokenPair *Cur;

    /* Empty string is end of tokens marker */
    if(NULL == *Args)
        Error(*Args);

    /* Linear search for the pair */
    Cur = OptionBaseTokenList;
    while(Cur->Str)
        {
            if(strcmp(*Args, Cur->Str) == 0)
                {
                    *Token = Cur->Enum;
                    return ++Args;
                }
            ++Cur;
        }

    *Token = OT_BASE_UNKNOWN;
    return ++Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadFixPins	(	IN const char *const *	Args,
		OUT char **	PinFile
	)			[static]

Definition at line 437 of file ReadOptions.c.

{
    enum e_OptionArgToken Token;
    int Len;
        const char *const *PrevArgs = Args;

    Args = ReadToken(Args, &Token);
    if(OT_RANDOM != Token)
        {
            Len = 1 + strlen(*PrevArgs);
            *PinFile = (char *)my_malloc(Len * sizeof(char));
            memcpy(*PinFile, *PrevArgs, Len);
        }
    return Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadFloat	(	IN const char *const *	Args,
		OUT float *	Val
	)			[static]

Definition at line 495 of file ReadOptions.c.

{
    if(NULL == *Args)
        {
            Error(*Args);
        }

    if((**Args != '-') &&
       (**Args != '.') && ((**Args > '9') || (**Args < '0')))
        {
            Error(*Args);
        }

    *Val = atof(*Args);

    return ++Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadInt	(	IN const char *const *	Args,
		OUT int *	Val
	)			[static]

Definition at line 480 of file ReadOptions.c.

{
    if(NULL == *Args)
        Error(*Args);
    if((**Args > '9') || (**Args < '0'))
        Error(*Args);

    *Val = atoi(*Args);

    return ++Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadOnOff	(	IN const char *const *	Args,
		OUT boolean *	Val
	)			[static]

Definition at line 456 of file ReadOptions.c.

{
    enum e_OptionArgToken Token;
    const char *const *PrevArgs;

    PrevArgs = Args;
    Args = ReadToken(Args, &Token);
    switch (Token)
        {
        case OT_ON:
            *Val = TRUE;
            break;
        case OT_OFF:
            *Val = FALSE;
            break;
        default:
            Error(*PrevArgs);
        }
    return Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void ReadOptions	(	IN int	argc,
		IN char **	argv,
		OUT t_options *	Options
	)

Definition at line 44 of file ReadOptions.c.

{
    char **Args, **head;

    /* Clear values and pointers to zero */
    memset(Options, 0, sizeof(t_options));

    /* Alloc a new pointer list for args with a NULL at end.
     * This makes parsing the same as for archfile for consistency.
     * Skips the first arg as it is the program image path */
    --argc;
    ++argv;
    head = Args = (char **)my_malloc(sizeof(char *) * (argc + 1));
    memcpy(Args, argv, (sizeof(char *) * argc));
    Args[argc] = NULL;

    /* Go through the command line args. If they have hyphens they are
     * options. Otherwise assume they are part of the four mandatory
     * arguments */
    while(*Args)
        {
            if(strncmp("--", *Args, 2) == 0)
                {
                    *Args += 2; /* Skip the prefix */
                    Args =
                        (char **)ProcessOption((const char *const *)Args,
                                               Options);
                }
            else if(strncmp("-", *Args, 1) == 0)
                {
                    *Args += 1; /* Skip the prefix */
                    Args =
                        (char **)ProcessOption((const char *const *)Args,
                                               Options);
                }
            else if(NULL == Options->NetFile)
                {
                    Options->NetFile = my_strdup(*Args);
                    ++Args;
                }
            else if(NULL == Options->ArchFile)
                {
                    Options->ArchFile = my_strdup(*Args);
                    ++Args;
                }
            else if(NULL == Options->PlaceFile)
                {
                    Options->PlaceFile = my_strdup(*Args);
                    ++Args;
                }
            else if(NULL == Options->RouteFile)
                {
                    Options->RouteFile = my_strdup(*Args);
                    ++Args;
                }
            else
                {
                    /* Not an option and arch and net already specified so fail */
                    Error(*Args);
                }
        }
        free(head);
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadPlaceAlgorithm	(	IN const char *const *	Args,
		OUT enum e_place_algorithm *	Algo
	)			[static]

Definition at line 410 of file ReadOptions.c.

{
    enum e_OptionArgToken Token;
    const char *const *PrevArgs;

    PrevArgs = Args;
    Args = ReadToken(Args, &Token);
    switch (Token)
        {
        case OT_BOUNDING_BOX:
            *Algo = BOUNDING_BOX_PLACE;
            break;
        case OT_NET_TIMING_DRIVEN:
            *Algo = NET_TIMING_DRIVEN_PLACE;
            break;
        case OT_PATH_TIMING_DRIVEN:
            *Algo = PATH_TIMING_DRIVEN_PLACE;
            break;
        default:
            Error(*PrevArgs);
        }

    return Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadPlaceCostType	(	IN const char *const *	Args,
		OUT enum place_c_types *	Type
	)			[static]

Definition at line 385 of file ReadOptions.c.

{
    enum e_OptionArgToken Token;
    const char *const *PrevArgs;

    PrevArgs = Args;
    Args = ReadToken(Args, &Token);
    switch (Token)
        {
        case OT_LINEAR:
            *Type = LINEAR_CONG;
            break;
        case OT_NONLINEAR:
            *Type = NONLINEAR_CONG;
            break;
        default:
            Error(*PrevArgs);
        }

    return Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadRouterAlgorithm	(	IN const char *const *	Args,
		OUT enum e_router_algorithm *	Algo
	)			[static]

Definition at line 305 of file ReadOptions.c.

{
    enum e_OptionArgToken Token;
    const char *const *PrevArgs;

    PrevArgs = Args;
    Args = ReadToken(Args, &Token);
    switch (Token)
        {
        case OT_BREADTH_FIRST:
            *Algo = BREADTH_FIRST;
            break;
        case OT_DIRECTED_SEARCH:
            *Algo = DIRECTED_SEARCH;
            break;
        case OT_TIMING_DRIVEN:
            *Algo = TIMING_DRIVEN;
            break;
        default:
            Error(*PrevArgs);
        }

    return Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadRouteType	(	IN const char *const *	Args,
		OUT enum e_route_type *	Type
	)			[static]

Definition at line 360 of file ReadOptions.c.

{
    enum e_OptionArgToken Token;
    const char *const *PrevArgs;

    PrevArgs = Args;
    Args = ReadToken(Args, &Token);
    switch (Token)
        {
        case OT_GLOBAL:
            *Type = GLOBAL;
            break;
        case OT_DETAILED:
            *Type = DETAILED;
            break;
        default:
            Error(*PrevArgs);
        }

    return Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char *const * ReadString	(	IN const char *const *	Args,
		OUT char **	Val
	)			[static]

Definition at line 516 of file ReadOptions.c.

{
    if(NULL == *Args)
        {
            Error(*Args);
        }

    *Val = my_strdup(*Args);

    return ++Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:

static const char* const* ReadToken	(	IN const char *const *	Args,
		OUT enum e_OptionArgToken *	Token
	)			[static]

Definition at line 254 of file ReadOptions.c.

{
    const struct s_TokenPair *Cur;

    /* Empty string is end of tokens marker */
    if(NULL == *Args)
        Error(*Args);

    /* Linear search for the pair */
    Cur = OptionArgTokenList;
    while(Cur->Str)
        {
            if(strcmp(*Args, Cur->Str) == 0)
                {
                    *Token = Cur->Enum;
                    return ++Args;
                }
            ++Cur;
        }

    *Token = OT_ARG_UNKNOWN;
    return ++Args;
}

Here is the call graph for this function:

Here is the caller graph for this function:
