s_pb_type Struct Reference

#include <physical_types.h>

Collaboration diagram for s_pb_type:

Data Fields
char *	name
int	num_pb
char *	blif_model
t_model *	model
enum e_pb_type_class	class_type
t_mode *	modes
int	num_modes
t_port *	ports
int	num_ports
int	num_clock_pins
int	num_input_pins
int	num_output_pins
t_mode *	parent_mode
int	depth
float	max_internal_delay
t_pin_to_pin_annotation *	annotations
int	num_annotations
struct s_linked_vptr *	models_contained

---

Detailed Description

Describes a physical block type

• name: name of the physical block type
• num_pb: maximum number of instances of this physical block type sharing one parent
• blif_model: the string in the blif circuit that corresponds with this pb type
• class_type: Special library name
• modes: Different modes accepted
• ports: I/O and clock ports
• num_clock_pins: A count of the total number of clock pins
• int num_input_pins: A count of the total number of input pins
• int num_output_pins: A count of the total number of output pins
• timing: Timing matrix of block [0..num_inputs-1][0..num_outputs-1]
• parent_mode: mode of the parent block

Definition at line 340 of file physical_types.h.

---

Field Documentation

t_pin_to_pin_annotation* s_pb_type::annotations

[0..num_annotations-1]

Definition at line 361 of file physical_types.h.

char* s_pb_type::blif_model

Definition at line 344 of file physical_types.h.

enum e_pb_type_class s_pb_type::class_type

Definition at line 346 of file physical_types.h.

int s_pb_type::depth

depth of pb_type

Definition at line 358 of file physical_types.h.

float s_pb_type::max_internal_delay

Definition at line 360 of file physical_types.h.

t_model* s_pb_type::model

Definition at line 345 of file physical_types.h.

struct s_linked_vptr* s_pb_type::models_contained

Definition at line 364 of file physical_types.h.

t_mode* s_pb_type::modes

[0..num_modes-1]

Definition at line 348 of file physical_types.h.

char* s_pb_type::name

Definition at line 342 of file physical_types.h.

int s_pb_type::num_annotations

Definition at line 362 of file physical_types.h.

int s_pb_type::num_clock_pins

Definition at line 353 of file physical_types.h.

int s_pb_type::num_input_pins

inputs not including clock pins

Definition at line 354 of file physical_types.h.

int s_pb_type::num_modes

Definition at line 349 of file physical_types.h.

int s_pb_type::num_output_pins

Definition at line 355 of file physical_types.h.

int s_pb_type::num_pb

Definition at line 343 of file physical_types.h.

int s_pb_type::num_ports

Definition at line 351 of file physical_types.h.

t_mode* s_pb_type::parent_mode

Definition at line 357 of file physical_types.h.

t_port* s_pb_type::ports

[0..num_ports]

Definition at line 350 of file physical_types.h.

---

The documentation for this struct was generated from the following file:

• libvpr/include/physical_types.h
