verilog_preprocessor.c File Reference

#include <ctype.h>
#include <stdio.h>
#include <string.h>
#include <stdlib.h>
#include <sys/stat.h>
#include <unistd.h>
#include "verilog_preprocessor.h"
#include "types.h"

Include dependency graph for verilog_preprocessor.c:

Go to the source code of this file.

Functions
int	init_veri_preproc ()
int	cleanup_veri_preproc ()
void	clean_veri_define (veri_define *current)
void	clean_veri_include (veri_include *current)
int	add_veri_define (char *symbol, char *value, int line, veri_include *defined_in)
veri_include *	add_veri_include (char *path, int line, veri_include *included_from)
char *	ret_veri_definedval (char *symbol)
int	veri_is_defined (char *symbol)
FILE *	open_source_file (char *filename)
FILE *	veri_preproc (FILE *source)
void	veri_preproc_bootstraped (FILE *source, FILE *preproc_producer, veri_include *current_include)
char *	trim (char *string)
int	top (veri_flag_stack *stack)
int	pop (veri_flag_stack *stack)
void	push (veri_flag_stack *stack, int flag)
Variables
struct veri_Includes	veri_includes
struct veri_Defines	veri_defines

---

Function Documentation

int add_veri_define	(	char *	symbol,
		char *	value,
		int	line,
		veri_include *	defined_in
	)

Definition at line 114 of file verilog_preprocessor.c.

{
        int i;
        veri_define *def_iterator = veri_defines.defined_constants[0];
        veri_define *new_def = (veri_define *)malloc(sizeof(veri_define));
        if (new_def == NULL)
        {
                perror("new_def : malloc ");
                return -1;
        }

        /* Check to see if there's enough space in our lookup table and reallocate if not. */
        if (veri_defines.current_index == veri_defines.current_size)
        {
                veri_defines.defined_constants = (veri_define **)realloc(veri_defines.defined_constants, (size_t)(veri_defines.current_size * 2) * sizeof(veri_define *));
                //In a perfect world there is a check here to make sure realloc succeded
                veri_defines.current_size *= 2;
        }

        /* Check previously defined values for collisions. */
        for (i = 0; i < veri_defines.current_index && i < veri_defines.current_size; def_iterator = veri_defines.defined_constants[++i])
        {
                if (0 == strcmp(def_iterator->symbol, symbol))
                {
                        fprintf(stderr, "Warning: The constant %s defined on line %d in %s was previously defined on line %d in %s\n",
                                symbol, line, defined_in->path, def_iterator->line, def_iterator->defined_in->path);

                        if (value == NULL || (value[0] == '/' && value[1] == '/'))
#ifndef BLOCK_EMPTY_DEFINES
                        {
                                fprintf(stderr, "\tWarning: The new value of %s is empty\n\n", symbol);
                                free(def_iterator->value);
                                def_iterator->value =NULL;
                        }
#else
                        {
                                fprintf(stderr, "\tWarning: The new value of %s is empty, doing nothing\n\n", symbol);
                                return 0;
                        }
#endif
                        else if (0 != strcmp(def_iterator->value, value))
                        {
                                fprintf(stderr, "\tWarning: The value of %s has been redefined to %s, the prvious value was %s\n\n",
                                        symbol, value, def_iterator->value);
                                free(def_iterator->value);
                                def_iterator->value = (char *)strdup(value);
                        }

                        free(new_def);
                        return 0;
                }
        }

        /* Create the new define and initalize it. */
        new_def->symbol = (char *)strdup(symbol);
        new_def->value = (value == NULL)? NULL : (char *)strdup(value);
        new_def->line = line;
        new_def->defined_in = defined_in;

        veri_defines.defined_constants[veri_defines.current_index] = new_def;
        veri_defines.current_index++;

        return 0;
}

Here is the caller graph for this function:

veri_include* add_veri_include	(	char *	path,
		int	line,
		veri_include *	included_from
	)

Definition at line 183 of file verilog_preprocessor.c.

{
        int i;
        veri_include *inc_iterator = veri_includes.included_files[0];
        veri_include *new_inc = (veri_include *)malloc(sizeof(veri_include));
        if (new_inc == NULL)
        {
                perror("new_inc : malloc ");
                return NULL;
        }

        /* Check to see if there's enough space in our lookup table and reallocate if not. */
        if (veri_includes.current_index == veri_includes.current_size)
        {
                veri_includes.included_files = (veri_include **)realloc(veri_includes.included_files, (size_t)(veri_includes.current_size * 2) * sizeof(veri_include *));
                //In a perfect world there is a check here to make sure realloc succeded
                veri_includes.current_size *= 2;
        }

        /* Scan previous includes to make sure the file wasn't included previously. */
        for (i = 0; i < veri_includes.current_index && i < veri_includes.current_size && inc_iterator != NULL; inc_iterator = veri_includes.included_files[++i])
        {
                if (0 == strcmp(path, inc_iterator->path))
                {
                        free(new_inc);
                        return NULL;
                }
        }

        new_inc->path = (char *)strdup(path);
        new_inc->included_from = included_from;
        new_inc->line = line;

        veri_includes.included_files[veri_includes.current_index] = new_inc;
        veri_includes.current_index++;

        return new_inc;
}

Here is the caller graph for this function:

void clean_veri_define

(

veri_define *

current

)

Definition at line 77 of file verilog_preprocessor.c.

{
        if (current != NULL)
        {
                fprintf(stderr, "\tCleaning Symbol: %s, ", current->symbol);
                free(current->symbol);
                fprintf(stderr, "Value: %s ", current->value);
                free(current->value);

                current->defined_in = NULL;

                free(current);
                current=NULL;
                fprintf(stderr, "...done\n");
        }
}

Here is the caller graph for this function:

void clean_veri_include

(

veri_include *

current

)

Definition at line 97 of file verilog_preprocessor.c.

{
        if (current != NULL)
        {
                fprintf(stderr, "\tCleaning Include: %s ", current->path);
                free(current->path);

                free(current);
                current = NULL;
                fprintf(stderr, "...done\n");
        }
}

Here is the caller graph for this function:

int cleanup_veri_preproc

(

)

Definition at line 43 of file verilog_preprocessor.c.

{
        fprintf(stderr, "Cleaning up the verilog preprocessor\n");

        veri_define *def_iterator = veri_defines.defined_constants[0];
        veri_include *inc_iterator = veri_includes.included_files[0];
        int i;

        for (i = 0; i < veri_defines.current_index && i < veri_defines.current_size; def_iterator = veri_defines.defined_constants[++i])
        {
                clean_veri_define(def_iterator);
        }
        def_iterator = NULL;
        veri_defines.current_index = 0;
        veri_defines.current_size = 0;
        free(veri_defines.defined_constants);

        for (i = 0; i < veri_includes.current_index && i < veri_includes.current_size; inc_iterator = veri_includes.included_files[++i])
        {
                clean_veri_include(inc_iterator);
        }
        inc_iterator = NULL;
        veri_includes.current_index = 0;
        veri_includes.current_size = 0;
        free(veri_includes.included_files);

        fprintf(stderr, " --- Finished\n");

        return 0;
}

Here is the call graph for this function:

Here is the caller graph for this function:

int init_veri_preproc

(

)

Definition at line 18 of file verilog_preprocessor.c.

{
        veri_includes.included_files = (veri_include **) calloc(DefaultSize, sizeof(veri_include *));
        if (veri_includes.included_files == NULL)
        {
                perror("veri_includes.included_files : calloc ");
                return -1;
        }
        veri_includes.current_size = DefaultSize;
        veri_includes.current_index = 0;

        veri_defines.defined_constants = (veri_define **) calloc(DefaultSize, sizeof(veri_define *));
        if (veri_defines.defined_constants == NULL)
        {
                perror("veri_defines.defined_constants : calloc ");
                return -1;
        }
        veri_defines.current_size = DefaultSize;
        veri_defines.current_index = 0;
        return 0;
}

Here is the caller graph for this function:

FILE* open_source_file

(

char *

filename

)

Definition at line 261 of file verilog_preprocessor.c.

{
        extern global_args_t global_args;
        extern config_t configuration;
        extern int current_parse_file;


        FILE* src_file = fopen(filename, "r"); //Look for the file in the PWD
        if (src_file != NULL)
        {
                return src_file;
        }

        char* path;
        if (global_args.verilog_file != NULL) //ODIN_II was called with the -V option.
        {
                path = (char *) strdup(global_args.verilog_file);
        }
        else if(global_args.config_file != NULL) //ODIN_II was called with the -c option.
        {
                path = (char *) strdup(configuration.list_of_file_names[current_parse_file]);
        }

        char* last_slash = strrchr(path, '/') + 1;
        *last_slash = '\0';
        strcat(path, filename);

        src_file = fopen(path, "r");
        if (src_file != NULL)
        {
                fprintf(stderr, "Warning: Unable to find %s in the present working directory, opening %s instead\n",
                                filename, path);
                free(path);
                return src_file;
        }

        return NULL;
}

Here is the caller graph for this function:

int pop

(

veri_flag_stack *

stack

)

Definition at line 614 of file verilog_preprocessor.c.

{
        if(stack != NULL && stack->top != NULL)
        {
                veri_flag_node *top = stack->top;
                int flag = top->flag;

                stack->top = top->next;
                free(top);

                return flag;
        }
        return 0;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void push	(	veri_flag_stack *	stack,
		int	flag
	)

Definition at line 628 of file verilog_preprocessor.c.

{
        if(stack != NULL)
        {
                veri_flag_node *new_node = (veri_flag_node *)malloc(sizeof(veri_flag_node));
                new_node->next = stack->top;
                new_node->flag = flag;

                stack->top = new_node;
        }
}

Here is the caller graph for this function:

char* ret_veri_definedval

(

char *

symbol

)

Definition at line 226 of file verilog_preprocessor.c.

{
        int is_defined = veri_is_defined(symbol);
        if(0 <= is_defined)
        {
                return veri_defines.defined_constants[is_defined]->value;
        }
        return NULL;

}

Here is the call graph for this function:

Here is the caller graph for this function:

int top

(

veri_flag_stack *

stack

)

Definition at line 604 of file verilog_preprocessor.c.

{
        if(stack != NULL && stack->top != NULL)
        {
                return stack->top->flag;
        }
        return 0;

}

Here is the caller graph for this function:

char* trim

(

char *

string

)

Definition at line 577 of file verilog_preprocessor.c.

{
        int i = 0;
        if (string != NULL)
        {
                // advance past all spaces at the beginning
                while( isspace( *string ) ) string++ ;
                // trim all spaces at the end
                for(i = strlen(string)-1; i >= 0 ; i--)
                {
                        if(isspace(string[i]) > 0)
                        {
                                string[i] = '\0';
                        }
                        else
                                break ;
                }
        }
        return string;
}

Here is the caller graph for this function:

int veri_is_defined

(

char *

symbol

)

Definition at line 240 of file verilog_preprocessor.c.

{
        int i;
        veri_define *def_iterator = veri_defines.defined_constants[0];

        for (i = 0; (i < veri_defines.current_index) && (i < veri_defines.current_size) && (def_iterator != NULL); def_iterator = veri_defines.defined_constants[++i])
        {
                if (0 == strcmp(symbol, def_iterator->symbol))
                {
                        return i;
                }
        }
        return -1;
}

Here is the caller graph for this function:

FILE* veri_preproc

(

FILE *

source

)

Definition at line 303 of file verilog_preprocessor.c.

{
        extern global_args_t global_args;
        extern config_t configuration;
        extern int current_parse_file;
        FILE *preproc_producer = NULL;

        /* Was going to use filename to prevent duplication but the global var isn't used in the case of a config value */
        char* current_file = (global_args.verilog_file != NULL) ? global_args.verilog_file : configuration.list_of_file_names[current_parse_file];
        veri_include *veri_initial = add_veri_include(current_file, 0, NULL);
        if (veri_initial == NULL)
        {
                fprintf(stderr, "Unable to store include information returning original FILE pointer\n\n");
                return source;
        }

        preproc_producer = tmpfile();
        preproc_producer = freopen(NULL, "r+", preproc_producer);



        if (preproc_producer == NULL)
        {
                perror("preproc_producer : fdopen - returning original FILE pointer");
                exit(-1);
                return source;
        }

        /* to thread or not to thread, that is the question. Wether yac will block when waitin */
        fprintf(stderr, "\tpreprocessing ...\n\n");
        veri_preproc_bootstraped(source, preproc_producer, veri_initial);

        rewind(preproc_producer);
        return preproc_producer;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void veri_preproc_bootstraped	(	FILE *	source,
		FILE *	preproc_producer,
		veri_include *	current_include
	)

Definition at line 339 of file verilog_preprocessor.c.

{
        int line_number = 1;
        veri_flag_stack *skip = (veri_flag_stack *)calloc(1, sizeof(veri_flag_stack));;
        char line[MaxLine];
        char *token, *p;
        FILE *included_file = NULL;
        veri_include *new_include = NULL;

        while (NULL != fgets(line, MaxLine, source))
        {
                //fprintf(stderr, "%s:%d\t%s", current_include->path,line_number, line);

                char proc_line[MaxLine] ;
                char symbol[MaxLine] ;
                char *value ;
                char *p_proc_line = proc_line ;
                char *last_pch, *pch, *pch_end ;
                // advance past all whitespace
                last_pch = trim(line) ;
                // start searching for backtick
                pch = strchr( last_pch, '`' ) ;
                while ( pch ) {
                        // if symbol found, copy everything from end of last_pch to here
                        strncpy( p_proc_line, last_pch, pch - last_pch ) ;
                        p_proc_line += pch - last_pch ;
                        *p_proc_line = '\0' ;
                        // find the end of the symbol
                        pch_end = pch+1 ;
                        while ( ( *pch_end >= '0' && *pch_end <= '9' ) ||
                                ( *pch_end >= 'A' && *pch_end <= 'Z' ) ||
                                ( *pch_end >= 'a' && *pch_end <= 'z' ) ||
                                *pch_end == '_' )
                                pch_end++ ;
                        // copy symbol into array
                        strncpy( symbol, pch+1, pch_end - (pch+1) ) ;
                        *(symbol + (pch_end - (pch+1))) = '\0' ;
                        value = ret_veri_definedval( symbol ) ;
                        if ( value ) {
                                strcpy( p_proc_line, value ) ;
                                p_proc_line += strlen( value ) ;
                        }
                        else {
                                // symbol not found, just pass it through
                                *p_proc_line++ = '`' ;
                                strcpy( p_proc_line, symbol ) ;
                                p_proc_line += strlen( symbol ) ;
                        }
                        last_pch = pch_end ;
                        pch = strchr( last_pch+1, '`' ) ;
                }
                pch = strchr( last_pch, '\0' ) ;
                strncpy( p_proc_line, last_pch, pch - last_pch ) ;
                p_proc_line += pch - last_pch ;
                *p_proc_line = '\0' ;

                strcpy( line, proc_line ) ;

                //fprintf(stderr, "%s:%d\t%s\n", current_include->path,line_number, line);

                /* Preprocessor directives have a backtick on the first coloumn. */
                if (line[0] == '`')
                {
                        token = trim((char *)strtok(line, " \t"));
                        //printf("preproc first token: %s\n", token);
                        /* If we encounter an `included directive we want to recurse using included_file and
                         * new_include in place of source and current_include
                         */
                        if (top(skip) < 1 && strcmp(token, "`include") == 0)
                        {
                                token = trim((char *)strtok(NULL, "\""));

                                included_file = open_source_file(token);

                                /* If we failed to open the included file handle the error */
                                if (included_file == NULL)
                                {
                                        fprintf(stderr, "Warning: Unable to open file %s included on line %d of %s\n",
                                                token, line_number, current_include->path);
                                        perror("included_file : fopen");
                                        /*return erro or exit ? */
                                }
                                else if (NULL != (new_include = add_veri_include(token, line_number, current_include)))
                                {
                                        veri_preproc_bootstraped(included_file, preproc_producer, new_include);
                                }
                                fclose(included_file);
                                /* If last included file has no newline an error could result so we add one. */
                                fputc('\n', preproc_producer);
                        }
                        /* If we encounter a `define directive we want to add it and its value if any to our
                         * symbol table.
                         */
                        else if (top(skip) < 1 && strcmp(token, "`define") == 0)
                        {
                                char *value = NULL;

                                /* strtok is destructive to the original string which we need to retain unchanged, this fixes it. */
                                fprintf(preproc_producer, "`define %s\n", line + 1 + strlen(line));
                                //printf("\tIn define: %s", token + 1 + strlen(token));

                                token = trim(strtok(NULL, " \t"));
                                //printf("token is: %s\n", token);

                                // symbol value can potentially be to the end of the line!
                                value = trim(strtok(NULL, "\r\n"));
                                //printf("value is: %s\n", value);

                                // however, be aware of "`define SYMBOL 1 + 2 + 3 + 4 // comment!"
                                // if a comment is found, terminate string there
                                // fortunately, we don't need to worry about /* */ style comments
                                // because they shouldn't comment out the rest of the line,
                                // unless it dangles past one line
                                if ( value ) {
                                        p = value ;
                                        while (*p) {
                                                if (*p == '/')
                                                        if ( *(p+1) == '/' ) {
                                                                *p = '\0' ;
                                                                break;
                                                        }
                                                p++ ;
                                        }
                                        // trim it again just in case
                                        value = trim(value) ;
                                }

                                add_veri_define(token, value, line_number, current_include);
                        }
                        /* If we encounter a `undef preprocessor directive we want to remove the corresponding
                         * symbol from our lookup table.
                         */
                        else if (top(skip) < 1 && strcmp(token, "`undef") == 0)
                        {
                                int is_defined = 0;
                                /* strtok is destructive to the original string which we need to retain unchanged, this fixes it. */
                                fprintf(preproc_producer, "`undef %s", line + 1 + strlen(line));

                                token = trim(strtok(NULL, " \t"));

                                is_defined = veri_is_defined(token);

                                if(is_defined >= 0)
                                {
                                        clean_veri_define(veri_defines.defined_constants[is_defined]);
                                        veri_defines.defined_constants[is_defined] = veri_defines.defined_constants[veri_defines.current_index];
                                        veri_defines.defined_constants[veri_defines.current_index--] = NULL;
                                }
                        }
                        else if (strcmp(token, "`ifdef") == 0)
                        {
                                // if parent is not skipped
                                if ( top(skip) < 1 ) {
                                        int is_defined = 0;

                                        token = trim(strtok(NULL, " \t"));
                                        is_defined = veri_is_defined(token);
                                        if(is_defined < 0) //If we are unable to locate the symbol in the table
                                        {
                                                push(skip, 1);
                                        }
                                        else
                                        {
                                                push(skip, 0);
                                        }
                                }
                                // otherwise inherit skip from parent (use 2)
                                else {
                                        push( skip, 2 ) ;
                                }
                        }
                        else if (strcmp(token, "`ifndef") == 0)
                        {
                                // if parent is not skipped
                                if ( top(skip) < 1 ) {
                                        int is_defined = 0;

                                        token = trim(strtok(NULL, " \t"));
                                        is_defined = veri_is_defined(token);
                                        if(is_defined >= 0) //If we are able to locate the symbol in the table
                                        {
                                                push(skip, 1);
                                        }
                                        else
                                        {
                                                push(skip, 0);
                                        }
                                }
                                // otherwise inherit skip from parent (use 2)
                                else {
                                        push( skip, 2 ) ;
                                }
                        }
                        else if (strcmp(token, "`else") == 0)
                        {
                                // if skip was 0 (prev. ifdef was 1)
                                if(top(skip) < 1)
                                {
                                        // then set to 0
                                        pop(skip) ;
                                        push(skip, 1);
                                }
                                // only when prev skip was 1 do we set to 0 now
                                else if (top(skip) == 1)
                                {
                                        pop(skip) ;
                                        push(skip, 0);
                                }
                                // but if it's 2 (parent ifdef is 1)
                                else {
                                        // then do nothing
                                }
                        }
                        else if (strcmp(token, "`endif") == 0)
                        {
                                pop(skip);
                        }
                        /* Leave unhandled preprcessor directives in place. */
                        else if (top(skip) < 1)
                        {
                                fprintf(preproc_producer, "%s %s\n", line, line + 1 + strlen(line));
                        }
                }
                else if(top(skip) < 1)
                {
                        if (fprintf(preproc_producer, "%s\n", line) < 0)//fputs(line, preproc_producer))
                        {
                                /* There was an error writing to the stream */
                        }
                }
                line_number++;
                token = NULL;
        }
        free(skip);
}

Here is the call graph for this function:

Here is the caller graph for this function:

---

Variable Documentation

struct veri_Defines veri_defines

Definition at line 12 of file verilog_preprocessor.c.

struct veri_Includes veri_includes

Definition at line 11 of file verilog_preprocessor.c.
