src/cuBdd/cuddHarwell.c File Reference

#include "util.h"
#include "cuddInt.h"
Include dependency graph for cuddHarwell.c:

Go to the source code of this file.

Functions

int Cudd_addHarwell (FILE *fp, DdManager *dd, DdNode **E, DdNode ***x, DdNode ***y, DdNode ***xn, DdNode ***yn_, int *nx, int *ny, int *m, int *n, int bx, int sx, int by, int sy, int pr)

Variables

static char rcsid[] DD_UNUSED = "$Id: cuddHarwell.c,v 1.9 2004/08/13 18:04:49 fabio Exp $"

Function Documentation

int Cudd_addHarwell ( FILE *  fp,
DdManager *  dd,
DdNode **  E,
DdNode ***  x,
DdNode ***  y,
DdNode ***  xn,
DdNode ***  yn_,
int *  nx,
int *  ny,
int *  m,
int *  n,
int  bx,
int  sx,
int  by,
int  sy,
int  pr
)

AutomaticStart AutomaticEnd Function********************************************************************

Synopsis [Reads in a matrix in the format of the Harwell-Boeing benchmark suite.]

Description [Reads in a matrix in the format of the Harwell-Boeing benchmark suite. The variables are ordered as follows: <blockquote> x\[0\] y\[0\] x\[1\] y\[1\] ... </blockquote> 0 is the most significant bit. On input, nx and ny hold the numbers of row and column variables already in existence. On output, they hold the numbers of row and column variables actually used by the matrix. m and n are set to the numbers of rows and columns of the matrix. Their values on input are immaterial. Returns 1 on success; 0 otherwise. The ADD for the sparse matrix is returned in E, and its reference count is > 0.]

SideEffects [None]

SeeAlso [Cudd_addRead Cudd_bddRead]

Definition at line 120 of file cuddHarwell.c.

00137 {
00138     DdNode *one, *zero;
00139     DdNode *w;
00140     DdNode *cubex, *cubey, *minterm1;
00141     int u, v, err, i, j, nv;
00142     double val;
00143     DdNode **lx, **ly, **lxn, **lyn;    /* local copies of x, y, xn, yn_ */
00144     int lnx, lny;                       /* local copies of nx and ny */
00145     char title[73], key[9], mxtype[4], rhstyp[4];
00146     int totcrd, ptrcrd, indcrd, valcrd, rhscrd,
00147         nrow, ncol, nnzero, neltvl,
00148         nrhs, nrhsix;
00149     int *colptr, *rowind;
00150 #if 0
00151     int nguess, nexact;
00152     int *rhsptr, *rhsind;
00153 #endif
00154
00155     if (*nx < 0 || *ny < 0) return(0);
00156
00157     one = DD_ONE(dd);
00158     zero = DD_ZERO(dd);
00159
00160     /* Read the header */
00161     err = fscanf(fp, "%72c %8c", title, key);
00162     if (err == EOF) {
00163         return(0);
00164     } else if (err != 2) {
00165         return(0);
00166     }
00167     title[72] = (char) 0;
00168     key[8] = (char) 0;
00169
00170     err = fscanf(fp, "%d %d %d %d %d", &totcrd, &ptrcrd, &indcrd,
00171     &valcrd, &rhscrd);
00172     if (err == EOF) {
00173         return(0);
00174     } else if (err != 5) {
00175         return(0);
00176     }
00177
00178     err = fscanf(fp, "%3s %d %d %d %d", mxtype, &nrow, &ncol,
00179     &nnzero, &neltvl);
00180     if (err == EOF) {
00181         return(0);
00182     } else if (err != 5) {
00183         return(0);
00184     }
00185
00186     /* Skip FORTRAN formats */
00187     if (rhscrd == 0) {
00188         err = fscanf(fp, "%*s %*s %*s \n");
00189     } else {
00190         err = fscanf(fp, "%*s %*s %*s %*s \n");
00191     }
00192     if (err == EOF) {
00193         return(0);
00194     } else if (err != 0) {
00195         return(0);
00196     }
00197
00198     /* Print out some stuff if requested to be verbose */
00199     if (pr>0) {
00200         (void) fprintf(dd->out,"%s: type %s, %d rows, %d columns, %d entries\n", key,
00201         mxtype, nrow, ncol, nnzero);
00202         if (pr>1) (void) fprintf(dd->out,"%s\n", title);
00203     }
00204
00205     /* Check matrix type */
00206     if (mxtype[0] != 'R' || mxtype[1] != 'U' || mxtype[2] != 'A') {
00207         (void) fprintf(dd->err,"%s: Illegal matrix type: %s\n",
00208                        key, mxtype);
00209         return(0);
00210     }
00211     if (neltvl != 0) return(0);
00212
00213     /* Read optional 5-th line */
00214     if (rhscrd != 0) {
00215         err = fscanf(fp, "%3c %d %d", rhstyp, &nrhs, &nrhsix);
00216         if (err == EOF) {
00217             return(0);
00218         } else if (err != 3) {
00219             return(0);
00220         }
00221         rhstyp[3] = (char) 0;
00222         if (rhstyp[0] != 'F') {
00223             (void) fprintf(dd->err,
00224             "%s: Sparse right-hand side not yet supported\n", key);
00225             return(0);
00226         }
00227         if (pr>0) (void) fprintf(dd->out,"%d right-hand side(s)\n", nrhs);
00228     } else {
00229         nrhs = 0;
00230     }
00231
00232     /* Compute the number of variables */
00233
00234     /* row and column numbers start from 0 */
00235     u = nrow - 1;
00236     for (i=0; u > 0; i++) {
00237         u >>= 1;
00238     }
00239     lnx = i;
00240     if (nrhs == 0) {
00241         v = ncol - 1;
00242     } else {
00243         v = 2* (ddMax(ncol, nrhs) - 1);
00244     }
00245     for (i=0; v > 0; i++) {
00246         v >>= 1;
00247     }
00248     lny = i;
00249
00250     /* Allocate or reallocate arrays for variables as needed */
00251     if (*nx == 0) {
00252         if (lnx > 0) {
00253             *x = lx = ALLOC(DdNode *,lnx);
00254             if (lx == NULL) {
00255                 dd->errorCode = CUDD_MEMORY_OUT;
00256                 return(0);
00257             }
00258             *xn = lxn =  ALLOC(DdNode *,lnx);
00259             if (lxn == NULL) {
00260                 dd->errorCode = CUDD_MEMORY_OUT;
00261                 return(0);
00262             }
00263         } else {
00264             *x = *xn = NULL;
00265         }
00266     } else if (lnx > *nx) {
00267         *x = lx = REALLOC(DdNode *, *x, lnx);
00268         if (lx == NULL) {
00269             dd->errorCode = CUDD_MEMORY_OUT;
00270             return(0);
00271         }
00272         *xn = lxn =  REALLOC(DdNode *, *xn, lnx);
00273         if (lxn == NULL) {
00274             dd->errorCode = CUDD_MEMORY_OUT;
00275             return(0);
00276         }
00277     } else {
00278         lx = *x;
00279         lxn = *xn;
00280     }
00281     if (*ny == 0) {
00282         if (lny >0) {
00283             *y = ly = ALLOC(DdNode *,lny);
00284             if (ly == NULL) {
00285                 dd->errorCode = CUDD_MEMORY_OUT;
00286                 return(0);
00287             }
00288             *yn_ = lyn = ALLOC(DdNode *,lny);
00289             if (lyn == NULL) {
00290                 dd->errorCode = CUDD_MEMORY_OUT;
00291                 return(0);
00292             }
00293         } else {
00294             *y = *yn_ = NULL;
00295         }
00296     } else if (lny > *ny) {
00297         *y = ly = REALLOC(DdNode *, *y, lny);
00298         if (ly == NULL) {
00299             dd->errorCode = CUDD_MEMORY_OUT;
00300             return(0);
00301         }
00302         *yn_ = lyn = REALLOC(DdNode *, *yn_, lny);
00303         if (lyn == NULL) {
00304             dd->errorCode = CUDD_MEMORY_OUT;
00305             return(0);
00306         }
00307     } else {
00308         ly = *y;
00309         lyn = *yn_;
00310     }
00311
00312     /* Create new variables as needed */
00313     for (i= *nx,nv=bx+(*nx)*sx; i < lnx; i++,nv+=sx) {
00314         do {
00315             dd->reordered = 0;
00316             lx[i] = cuddUniqueInter(dd, nv, one, zero);
00317         } while (dd->reordered == 1);
00318         if (lx[i] == NULL) return(0);
00319         cuddRef(lx[i]);
00320         do {
00321             dd->reordered = 0;
00322             lxn[i] = cuddUniqueInter(dd, nv, zero, one);
00323         } while (dd->reordered == 1);
00324         if (lxn[i] == NULL) return(0);
00325         cuddRef(lxn[i]);
00326     }
00327     for (i= *ny,nv=by+(*ny)*sy; i < lny; i++,nv+=sy) {
00328         do {
00329             dd->reordered = 0;
00330             ly[i] = cuddUniqueInter(dd, nv, one, zero);
00331         } while (dd->reordered == 1);
00332         if (ly[i] == NULL) return(0);
00333         cuddRef(ly[i]);
00334         do {
00335             dd->reordered = 0;
00336             lyn[i] = cuddUniqueInter(dd, nv, zero, one);
00337         } while (dd->reordered == 1);
00338         if (lyn[i] == NULL) return(0);
00339         cuddRef(lyn[i]);
00340     }
00341
00342     /* Update matrix parameters */
00343     *nx = lnx;
00344     *ny = lny;
00345     *m = nrow;
00346     if (nrhs == 0) {
00347         *n = ncol;
00348     } else {
00349         *n = (1 << (lny - 1)) + nrhs;
00350     }
00351
00352     /* Read structure data */
00353     colptr = ALLOC(int, ncol+1);
00354     if (colptr == NULL) {
00355         dd->errorCode = CUDD_MEMORY_OUT;
00356         return(0);
00357     }
00358     rowind = ALLOC(int, nnzero);
00359     if (rowind == NULL) {
00360         dd->errorCode = CUDD_MEMORY_OUT;
00361         return(0);
00362     }
00363
00364     for (i=0; i<ncol+1; i++) {
00365         err = fscanf(fp, " %d ", &u);
00366         if (err == EOF){
00367             FREE(colptr);
00368             FREE(rowind);
00369             return(0);
00370         } else if (err != 1) {
00371             FREE(colptr);
00372             FREE(rowind);
00373             return(0);
00374         }
00375         colptr[i] = u - 1;
00376     }
00377     if (colptr[0] != 0) {
00378         (void) fprintf(dd->err,"%s: Unexpected colptr[0] (%d)\n",
00379                        key,colptr[0]);
00380         FREE(colptr);
00381         FREE(rowind);
00382         return(0);
00383     }
00384     for (i=0; i<nnzero; i++) {
00385         err = fscanf(fp, " %d ", &u);
00386         if (err == EOF){
00387             FREE(colptr);
00388             FREE(rowind);
00389             return(0);
00390         } else if (err != 1) {
00391             FREE(colptr);
00392             FREE(rowind);
00393             return(0);
00394         }
00395         rowind[i] = u - 1;
00396     }
00397
00398     *E = zero; cuddRef(*E);
00399
00400     for (j=0; j<ncol; j++) {
00401         v = j;
00402         cubey = one; cuddRef(cubey);
00403         for (nv = lny - 1; nv>=0; nv--) {
00404             if (v & 1) {
00405                 w = Cudd_addApply(dd, Cudd_addTimes, cubey, ly[nv]);
00406             } else {
00407                 w = Cudd_addApply(dd, Cudd_addTimes, cubey, lyn[nv]);
00408             }
00409             if (w == NULL) {
00410                 Cudd_RecursiveDeref(dd, cubey);
00411                 FREE(colptr);
00412                 FREE(rowind);
00413                 return(0);
00414             }
00415             cuddRef(w);
00416             Cudd_RecursiveDeref(dd, cubey);
00417             cubey = w;
00418             v >>= 1;
00419         }
00420         for (i=colptr[j]; i<colptr[j+1]; i++) {
00421             u = rowind[i];
00422             err = fscanf(fp, " %lf ", &val);
00423             if (err == EOF || err != 1){
00424                 Cudd_RecursiveDeref(dd, cubey);
00425                 FREE(colptr);
00426                 FREE(rowind);
00427                 return(0);
00428             }
00429             /* Create new Constant node if necessary */
00430             cubex = cuddUniqueConst(dd, (CUDD_VALUE_TYPE) val);
00431             if (cubex == NULL) {
00432                 Cudd_RecursiveDeref(dd, cubey);
00433                 FREE(colptr);
00434                 FREE(rowind);
00435                 return(0);
00436             }
00437             cuddRef(cubex);
00438
00439             for (nv = lnx - 1; nv>=0; nv--) {
00440                 if (u & 1) {
00441                     w = Cudd_addApply(dd, Cudd_addTimes, cubex, lx[nv]);
00442                 } else {
00443                     w = Cudd_addApply(dd, Cudd_addTimes, cubex, lxn[nv]);
00444                 }
00445                 if (w == NULL) {
00446                     Cudd_RecursiveDeref(dd, cubey);
00447                     Cudd_RecursiveDeref(dd, cubex);
00448                     FREE(colptr);
00449                     FREE(rowind);
00450                     return(0);
00451                 }
00452                 cuddRef(w);
00453                 Cudd_RecursiveDeref(dd, cubex);
00454                 cubex = w;
00455                 u >>= 1;
00456             }
00457             minterm1 = Cudd_addApply(dd, Cudd_addTimes, cubey, cubex);
00458             if (minterm1 == NULL) {
00459                 Cudd_RecursiveDeref(dd, cubey);
00460                 Cudd_RecursiveDeref(dd, cubex);
00461                 FREE(colptr);
00462                 FREE(rowind);
00463                 return(0);
00464             }
00465             cuddRef(minterm1);
00466             Cudd_RecursiveDeref(dd, cubex);
00467             w = Cudd_addApply(dd, Cudd_addPlus, *E, minterm1);
00468             if (w == NULL) {
00469                 Cudd_RecursiveDeref(dd, cubey);
00470                 FREE(colptr);
00471                 FREE(rowind);
00472                 return(0);
00473             }
00474             cuddRef(w);
00475             Cudd_RecursiveDeref(dd, minterm1);
00476             Cudd_RecursiveDeref(dd, *E);
00477             *E = w;
00478         }
00479         Cudd_RecursiveDeref(dd, cubey);
00480     }
00481     FREE(colptr);
00482     FREE(rowind);
00483
00484     /* Read right-hand sides */
00485     for (j=0; j<nrhs; j++) {
00486         v = j + (1<< (lny-1));
00487         cubey = one; cuddRef(cubey);
00488         for (nv = lny - 1; nv>=0; nv--) {
00489             if (v & 1) {
00490                 w = Cudd_addApply(dd, Cudd_addTimes, cubey, ly[nv]);
00491             } else {
00492                 w = Cudd_addApply(dd, Cudd_addTimes, cubey, lyn[nv]);
00493             }
00494             if (w == NULL) {
00495                 Cudd_RecursiveDeref(dd, cubey);
00496                 return(0);
00497             }
00498             cuddRef(w);
00499             Cudd_RecursiveDeref(dd, cubey);
00500             cubey = w;
00501             v >>= 1;
00502         }
00503         for (i=0; i<nrow; i++) {
00504             u = i;
00505             err = fscanf(fp, " %lf ", &val);
00506             if (err == EOF || err != 1){
00507                 Cudd_RecursiveDeref(dd, cubey);
00508                 return(0);
00509             }
00510             /* Create new Constant node if necessary */
00511             if (val == (double) 0.0) continue;
00512             cubex = cuddUniqueConst(dd, (CUDD_VALUE_TYPE) val);
00513             if (cubex == NULL) {
00514                 Cudd_RecursiveDeref(dd, cubey);
00515                 return(0);
00516             }
00517             cuddRef(cubex);
00518
00519             for (nv = lnx - 1; nv>=0; nv--) {
00520                 if (u & 1) {
00521                    w = Cudd_addApply(dd, Cudd_addTimes, cubex, lx[nv]);
00522                 } else {
00523                     w = Cudd_addApply(dd, Cudd_addTimes, cubex, lxn[nv]);
00524                 }
00525                 if (w == NULL) {
00526                     Cudd_RecursiveDeref(dd, cubey);
00527                     Cudd_RecursiveDeref(dd, cubex);
00528                     return(0);
00529                 }
00530                 cuddRef(w);
00531                 Cudd_RecursiveDeref(dd, cubex);
00532                 cubex = w;
00533                 u >>= 1;
00534             }
00535             minterm1 = Cudd_addApply(dd, Cudd_addTimes, cubey, cubex);
00536             if (minterm1 == NULL) {
00537                 Cudd_RecursiveDeref(dd, cubey);
00538                 Cudd_RecursiveDeref(dd, cubex);
00539                 return(0);
00540             }
00541             cuddRef(minterm1);
00542             Cudd_RecursiveDeref(dd, cubex);
00543             w = Cudd_addApply(dd, Cudd_addPlus, *E, minterm1);
00544             if (w == NULL) {
00545                 Cudd_RecursiveDeref(dd, cubey);
00546                 return(0);
00547             }
00548             cuddRef(w);
00549             Cudd_RecursiveDeref(dd, minterm1);
00550             Cudd_RecursiveDeref(dd, *E);
00551             *E = w;
00552         }
00553         Cudd_RecursiveDeref(dd, cubey);
00554     }
00555
00556     return(1);
00557
00558 } /* end of Cudd_addHarwell */

Variable Documentation

char rcsid [] DD_UNUSED = "$Id: cuddHarwell.c,v 1.9 2004/08/13 18:04:49 fabio Exp $" [static]

CFile***********************************************************************

FileName [cuddHarwell.c]

PackageName [cudd]

Synopsis [Function to read a matrix in Harwell format.]

Description [External procedures included in this module:

]

Author [Fabio Somenzi]

Copyright [Copyright (c) 1995-2004, Regents of the University of Colorado

All rights reserved.

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

Neither the name of the University of Colorado nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.]

Definition at line 74 of file cuddHarwell.c.

Generated on Tue Jan 12 13:57:19 2010 for glu-2.2 by  doxygen 1.6.1
